Delta Electronics SMT Power Inductor HAL1375 Product Specifications

SMT Power Inductor
HAL1375 Type
Features
RoHS compliant.
Low profile (7.5mm max. height) SMD type.
Magnetically shielded, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Ideal for power source circuits, DC-DC converter,
DC-AC inverters inductor application.
In addition to the standard versions shown here,
customized inductors are available to meet your exact requirements.
Mechanical Dimension:
B
A
Electrical Characteristics:
PART NO.
HAL1375-1R0
HAL1375-1R4
HAL1375-2R0
HAL1375-2R5
1. Lo is the initial inductance.
2. Isat is the DC current which cause the inductance drop to Li.
3. Operating temperature : -20
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
D
F
C
G
o
At 25 C: 100KHz, 1V
1
L
o
(uH)
1.0
1.4
2.0
2.5
O to 105 O ( including self-temperature rise ).
C C
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
RECOMMENDED PAD PA TTERNS
8.98
3.10
5.82
E
DCR
Li
(uH) 20%
(m ) MAX
0.80 1.20
1.10 1.50
1.60 2.80
2.00 3.20
105
4.10
UNIT : mm / inch
3.18
A = 12.5 0.4 / 0.492 0.016
B = 12.5 0.4 / 0.492 0.016
C = 7.50 / 0.295 Max.
D = 2.40 / 0.094
E = 7.75 / 0.305
F = 10.35 / 0.407
G = 3.75 / 0.148
2
Isat
(Adc)
30
30
25
25
