Instruction Manual
Manual Ver.: 1.2
Software Ver.: FC-BP120-V1.0
Issuing Date:
Please read this instruction manual carefully before
using your unit.
Please keep this instruction manual well for future use.
Thanks for choosing the Digital Blood Pressure Monitor.
The PATIENT is an intended OPERATOR.
Upper Arm Electronic
Blood Pressure Monitor
Model No.: FC-BP120
2023/06/09
Advertisement
Table of Contents
Related Manuals for Finicare FC-BP120
Summary of Contents for Finicare FC-BP120
- Page 1 Instruction Manual Upper Arm Electronic Blood Pressure Monitor Model No.: FC-BP120 Manual Ver.: 1.2 Software Ver.: FC-BP120-V1.0 Issuing Date: 2023/06/09 Please read this instruction manual carefully before using your unit. Please keep this instruction manual well for future use. Thanks for choosing the Digital Blood Pressure Monitor.
-
Page 2: Revision Record
Revision Record Document No. Description Software REV Date FRN-FC-BP120-001 First established FC-BP120-V1.0 2022/03/18 FRN-FC-BP120-001 Update 1.1,1.2,1.3,3.5.1 FC-BP120-V1.0 2023/04/06 FRN-FC-BP120-001 Update 1.2 FC-BP120-V1.0 2023/06/09... -
Page 3: Table Of Contents
Contents Contents..................2 1. Before Using the Unit............2 1.1 Introduction.................2 1.2 Important safety notices..........3 1.3 Warning and safety notices..........4 2. Operating Instruction.............4 2.1 Know your unit..............4 2.2 Battery Installation / Replacement......6 2.3 Settings................6 2.4 Proper Use of the Arm Cu ...........9 2.5 Considerations for measuring........12 2.6 Function................13 2.7 Take a Measurement............13... -
Page 4: Contents
1. Before Using the Unit 1.1 Introduction Thank you for purchasing Upper Arm Electronic Blood Pressure Monitor. The unit uses the oscillometric method of blood pressure measurement. It means the unit detects the movement of your blood through your brachial artery, and converts your blood pressure into a digital reading. -
Page 5: Important Safety Notices
1.2 Important safety notices To assure the correct use of the product basic safety measures should always be followed including the precautions listed as below: ■ Please read all information in the instruction manual and any other literature included in the box before using the unit. -
Page 6: Warning And Safety Notices
1.3 Warning and safety notices ■ Regarding the application of the CUFF and its pressurization on any limb where vascular access or therapy, or an arteriole-venous (A-V) shunt, is present because of temporary interference to blood ow and could result in injury to the PATIENT; ■... - Page 7 Display Time/ Date User number Low battery Blood pressure Classi cation Systolic pressure Temperature icon Diastolic pressure Display icon Wireless icon Unit icon Body motion detection icon Average icon Sleeve with Memory icon self-check icon Arrhythmia Pulse detected Pulse rate Arm Cu Air Plug(Insert to Air Socket) Fit for 22cm~42cm...
-
Page 8: Battery Installation / Replacement
Power 4 AAA Alkaline Batteries Do not use rechargeable batteries. Instruction Manual ● Please keep the instruction manual well after using. 2.2 Battery Installation / Replacement 2.2.1Remove the battery covers from the battery compartment. 2.2.2 Install 4 “AAA” size batteries to match the + (positive) and - (negative) polarities with the polarities of the battery compartment as indicated. - Page 9 2.3.2 To set date and time Based on first step and press “ SET ” button again. The mark of month and date appears and flashes, press the “ MEM ” button to change the month and press the “ SET ” button to cotinue with next step. Then set the day, the hour and the minute by using the same way.
- Page 10 Hour Setting Minute Setting 2.3.3 To set 12 or 24 hours Based on the second step and press the “ SET ” button, the “24 hours” appears and ashes, then press the “ MEM ” button to switch into “12 hours”. Presss the “...
-
Page 11: Proper Use Of The Arm Cu
2.3.5 To set user Press the "SET" button when power o to switch User 1 or User 2. The operation of setting can be stopped at any time by pressing “START/STOP” button. 2.4 Proper Use of the Arm Cu 2.4.1 Make sure the air plug is inserted properly in the main unit. - Page 12 2.4.2 Remove all clothes from your upper arm allowing the cu to t directly on the skin. 2.4.3 Sit in a chair with your feet at on the oor. Place your arm on a table so as to level the cu to your heart.
- Page 13 2.4.6 The hose runs down the inside of your arm. The bottom of the cu should be approximately 1~2cm above your elbow. 1 ~ 2cm 2.4.7 Wrap the cu tightly around your upper arm by using the Velcro strip. Do not leave any spacing between the arm and the cu .
-
Page 14: Considerations For Measuring
2.5 Considerations for measuring Correct measurement Take o the thick posture clothes like sweater 2.5.1 The correct using method to measure Keep the （1）Elbow on the table；comfortably seated； body straight Keep the center of the cu and heart at the same height legs uncrossed；back and arm supported；... -
Page 15: Function
2.6 Function 2.6.1. The device has the WHO warning strip “ ” symbol display function, with the blood pressure value change, the higher blood pressure value “ ” symbol will appear relatively in the higher position (refer to WHO de nition of high blood pressure levels-reference table). 2.6.2. -
Page 16: Use The Memory Function
2.7.2 Measurement start. When pressurized to stop blood ow, the Blood Pressure Monitor stops pressure before automatically leaking air and automatically measuring blood pressure. The heartbeat symbol flashes once a pulse is detected. When the heart beat symbol appears and ashes, the Blood Pressure Monitor detects the pulse and begins to calculate the pulse automatically. - Page 17 2.8.1 To enter the memory mode & to read the average value Press the “MEM” button while the unit is o , the unit enters the memory mode and the average value of the latest 3 times measurement values of the current user will be displayed. 2.8.2 To read the measurement value Press the “MEM”...
-
Page 18: About Blood Pressure
2.9 About Blood Pressure 2.9.1 Irregular Heartbeat Symbol IHB When the unit detects an irregular rhythm two or more times during the measurement, the irregular heartbeat Symbol will appear on the display with the measurement values. An irregular heartbeat rhythm is defined as a rhythm that is more than 25% slower or 25% faster from the average rhythm which detected while the monitor is measuring the systolic blood pressure and the diastolic blood pressure. - Page 19 2.9.3 Health and Blood Pressure The incidence of hypertension increases with age. In addition, if lack of exercise, excess body fat and high levels of cholesterol(LDL), would sticks to the inside of blood vessels, which reduces elastictity of these vessels. Hypertension accelerated arterialsclerosis which can lead to serious conditions such as stroke and myocardial infarction.
-
Page 20: Care And Maintenance
2.9.5 Symptoms of High Blood Pressure High blood pressure can go unnoticed for a long time, since it doesn’t cause noticeable symptoms. The following are possible causes of abnormally high blood pressure: ●Overweight; ●High cholesterol level; ●Smoking; ●Excessive alcohol consumption; ●Stress and emotional upset;... -
Page 21: Calibration And Service
3.1.7 We will provide circuit diagrams, component part lists, descriptions, calibration instructions, or other information to assist service personnel who is trained by the manufacturer and has got the relevant quali cation certi cate. 3.2 Calibration and Service The accuracy of this blood pressure monitor has been carefully tested and is designed for a long service life. -
Page 22: Technical Data
3.5 Technical Data 3.5.1 Specifications Model FC-BP120 Measurement Method Oscillographic measurement method Display LCD Digital Display Blood Pressure range: 0~299mmHg (0 kPa - 39.9 kPa) Measurement Range Pulse: 40 to 180 beats/min Accuracy of the Static Pressure: ±3mmHg(±0.4 kPa) cu pressure Pulse rate: Within ±5% of reading... - Page 23 3.5.2 Statement • The unit is intended to be used to measure blood pressure (systolic and diastolic) and heart rate from the upper arm by using the oscillometric method. • The unit is intended for using in only adult population, not applied to the other populations such as neonatal baby •It can’t be used while the wirst (arm) has bleeding or wound to avoid the blood flowing from the wound when pressurzing.
-
Page 24: Technical Description
3.6 Technical description 3.6.1 All necessary instructions for maintaining BASIC SAFETY and ESSENTIAL PERFORMANCE with regard to electromagnetic disturbances for the excepted service life. 3.6.2 Guidance and manufacturer’s declaration -electromagnetic emissions and Immunity Table 1 Guidance and manufacturer’s declaration - electromagnetic emissions Emissions test Compliance RF emissions... - Page 25 Radiated RF 10 V/m 80 MHz – 2,7 GHz 10 V/m 80 MHz – 2,7 GHz IEC61000-4-3 80 % AM at 1 kHz 80 % AM at 1 kHz NOTE UT is the a.c. mians voltage prior to application of the test level. Table 3 Guidance and manufacturer’s declaration - electromagnetic Immunity Test...
- Page 26 GSM 1800; 1720 CDMA 1900; GSM 1900; Pulse 1700 – 1845 DECT; modulation 1990 LTE Band 217 Hz 1, 3,4, 1970 25; UMTS Bluetooth, WLAN, Pulse 2400 – 2450 802.11 b/g/n, modulation 2570 RFID 2450, 217 Hz LTE Band 7 5240 5100 –...
-
Page 27: Warranty Information
4. Warranty Information ■ The unit, excluding the unit cuff, is guaranteed to be free of defects in workmanship and materials for a period of two years from the date listed on the purchase record, when used in accordance with the instructions provided with the unit. The unit cuff is warranted to be free from defects in materials and workmanship appearing with in one year from the date listed on the purchase record when the unit is used in accordance with the instructions provided with the unit. - Page 28 EC REP RIOMAVIX S.L. Calle de Almansa 55, 1D, Madrid, 28039 Spain Manufacturer: Shenzhen Finicare Co., Ltd 201, No.50, the 3rd Industrial Park, Houting Community, Shajing Street, Bao'an District, Shenzhen 518104 China E-mail: info@finicare.com Website: https://www. nicare.com/ Made in China...
