Instruction Manual
Manual Ver.: 1.2
Software Ver.: FC-BP103-V1.0
Issuing Date:
Please read this instruction manual carefully before
using your unit.
Please keep this instruction manual well for future use.
Thanks for choosing the Digital Blood Pressure Monitor.
The PATIENT is an intended OPERATOR.
Upper Arm Electronic
Blood Pressure Monitor
Model No.: FC-BP103
2023/06/09
Advertisement
Table of Contents
Related Manuals for Finicare FC-BP103
Summary of Contents for Finicare FC-BP103
- Page 1 Instruction Manual Upper Arm Electronic Blood Pressure Monitor Model No.: FC-BP103 Manual Ver.: 1.2 Software Ver.: FC-BP103-V1.0 Issuing Date: 2023/06/09 Please read this instruction manual carefully before using your unit. Please keep this instruction manual well for future use. Thanks for choosing the Digital Blood Pressure Monitor.
-
Page 2: Revision Record
Revision Record Document No. Description Software REV Date FRN-FC-BP103-001 First established FC-BP103-V1.0 2022/03/18 FRN-FC-BP103-001 Update 1.1,1.2,1.3,3.5.1 FC-BP103-V1.0 2023/04/06 FRN-FC-BP103-001 Update 1.2 FC-BP103-V1.0 2023/06/09... -
Page 3: Table Of Contents
Contents Contents..................2 1. Before Using the Unit............2 1.1 Introduction.................2 1.2 Important safety notices..........3 1.3 Warning and safety notices..........4 2. Operating Instruction.............4 2.1 Introduction of machine..........4 2.2 Battery Installation / Replacement......6 2.3 Settings................7 2.4 Proper Use of the Arm Cu ...........7 2.5 Considerations for measuring........10 2.6 Function................11 2.7 Take a Measurement............11... -
Page 4: Contents
1. Before Using the Unit 1.1 Introduction Thank you for purchasing Upper Arm Electronic Blood Pressure Monitor. The unit uses the oscillometric method of blood pressure measurement. It means the unit detects the movement of your blood through your brachial artery, and converts your blood pressure into a digital reading. -
Page 5: Important Safety Notices
1.2 Important safety notices To assure the correct use of the product basic safety measures should always be followed including the precautions listed as below: ■ Please read all information in the instruction manual and any other literature included in the box before using the unit. -
Page 6: Warning And Safety Notices
1.3 Warning and safety notices ■ Regarding the application of the CUFF and its pressurization on any limb where vascular access or therapy, or an arteriole-venous (A-V) shunt, is present because of temporary interference to blood ow and could result in injury to the PATIENT; ■... - Page 7 Display Blood pressure Classi cation Systolic pressure Diastolic pressure Arrhythmia Pulse detected Pulse rate Average icon Memory icon User number Wireless icon Sound icon Low battery Sleeve with Body motion self-check icon detection icon Arm Cu Air Plug(Insert to Air Socket) Fit for 9-17 inches (22cm~42cm) range of upper arm perimeter...
-
Page 8: Battery Installation / Replacement
Power 4 AA Alkaline Batteries Do not use rechargeable batteries. Instruction Manual ● Please keep the instruction manual well after using. 2.2 Battery Installation / Replacement 2.2.1Remove the battery covers from the battery compartment. 2.2.2 Install 4 “AA” size batteries to match the + (positive) and - (negative) polarities with the polarities of the battery compartment as indicated. -
Page 9: Settings
2.3 Settings 2.3.1 To set voice Long press the " " button when power o , you can see the " " icon appears and flashes, then press the " " button to adjust the sound on or o . When the screen shows " ", Blood Pressure Monitor sound is on;... - Page 10 2.4.2 Remove all clothes from your upper arm allowing the cu to t directly on the skin. 2.4.3 Sit in a chair with your feet at on the oor. Place your arm on a table so as to level the cu to your heart.
- Page 11 2.4.6 The hose runs down the inside of your arm. The bottom of the cu should be approximately 0.4-0.8 inches (1~2cm) above your elbow. 0.4-0.8 inches (1 ~ 2cm) 2.4.7 Wrap the cu tightly around your upper arm by using the velcro strip. Make sure at least there should be 1-2 ngers space between arm and cu .
-
Page 12: Considerations For Measuring
2.5 Considerations for measuring 2.5.1 The correct using method (1) Elbow on the table; comfortably seated; Correct measurement Take o the thick posture clothes like sweater legs uncrossed; back and arm supported; to measure Keep the (2) Keep the center of the cu body straight Keep the center of the cu and heart at the same height... -
Page 13: Function
2.6 Function 2.6.1. The device has the WHO warning strip “ ” symbol display function, with the blood pressure value change, the higher blood pressure value “ ” symbol will appear relatively in the higher position (refer to WHO de nition of high blood pressure levels-reference table). 2.6.2. -
Page 14: Use The Memory Function
2.7.2 Measurement start. When pressurized to stop blood ow, the Blood Pressure Monitor stops pressure before automatically leaking air and automatically measuring blood pressure. The heartbeat symbol flashes once a pulse is detected. When the heart beat symbol appears and ashes, the Blood Pressure Monitor detects the pulse and begins to calculate the pulse automatically. - Page 15 2.8.1 To enter the memory mode & to read the average value Press the “ ” button while the unit is o , the unit enters the memory mode and the average value of the latest 3 times measurement values of the current user will be displayed. 2.8.2 To read the measurement value Press the “...
-
Page 16: About Blood Pressure
2.9 About Blood Pressure 2.9.1 Irregular Heartbeat Symbol IHB When the unit detects an irregular rhythm two or more times during the measurement, the irregular heartbeat Symbol will appear on the display with the measurement values. An irregular heartbeat rhythm is defined as a rhythm that is more than 25% slower or 25% faster from the average rhythm which detected while the monitor is measuring the systolic blood pressure and the diastolic blood pressure. - Page 17 2.9.3 Health and Blood Pressure The incidence of hypertension increases with age. In addition, if lack of exercise, excess body fat and high levels of cholesterol(LDL), would sticks to the inside of blood vessels, which reduces elastictity of these vessels. Hypertension accelerated arterialsclerosis which can lead to serious conditions such as stroke and myocardial infarction.
-
Page 18: Care And Maintenance
2.9.5 Symptoms of High Blood Pressure High blood pressure can go unnoticed for a long time, since it doesn’t cause noticeable symptoms. The following are possible causes of abnormally high blood pressure: ●Overweight; ●High cholesterol level; ●Smoking; ●Excessive alcohol consumption; ●Stress and emotional upset;... -
Page 19: Calibration And Service
3.1.8 Do not repair or open the machine by yourself. If a defect occurs, Please contact the local distributor.18 3.1.9 We will provide circuit diagrams, component part lists, descriptions, calibration instructions, or other information to assist service personnel who is trained by the manufacturer and has got the relevant qualification certificate. -
Page 20: Technical Data
3.5 Technical Data 3.5.1 Specifications Model FC-BP103 Measurement Method Oscillographic measurement method Display LED Digital Display Blood Pressure range: 0~299mmHg (0 kPa - 39.9 kPa) Measurement Range Pulse: 40 to 180 beats/min Accuracy of the Static Pressure: ±3mmHg(±0.4 kPa) cu pressure Pulse rate: Within ±5% of reading... - Page 21 3.5.2 Statement • The unit is intended to be used to measure blood pressure (systolic and diastolic) and heart rate from the upper arm by using the oscillometric method. • The unit is intended for using in only adult population, not applied to the other populations such as neonatal baby •It can’t be used while the wirst (arm) has bleeding or wound to avoid the blood flowing from the wound when pressurzing.
-
Page 22: Technical Description
3.6 Technical description 3.6.1 All necessary instructions for maintaining BASIC SAFETY and ESSENTIAL PERFORMANCE with regard to electromagnetic disturbances for the excepted service life. 3.6.2 Guidance and manufacturer’s declaration -electromagnetic emissions and Immunity Table 1 Guidance and manufacturer’s declaration - electromagnetic emissions Emissions test Compliance RF emissions... - Page 23 Radiated RF 10 V/m 80 MHz – 2,7 GHz 10 V/m 80 MHz – 2,7 GHz IEC61000-4-3 80 % AM at 1 kHz 80 % AM at 1 kHz NOTE UT is the a.c. mians voltage prior to application of the test level. Table 3 Guidance and manufacturer’s declaration - electromagnetic Immunity Test...
- Page 24 GSM 1800; 1720 CDMA 1900; GSM 1900; Pulse 1700 – 1845 DECT; modulation 1990 LTE Band 217 Hz 1, 3,4, 1970 25; UMTS Bluetooth, WLAN, Pulse 2400 – 2450 802.11 b/g/n, modulation 2570 RFID 2450, 217 Hz LTE Band 7 5240 5100 –...
-
Page 25: Warranty Information
4. Warranty Information ■ The unit, excluding the unit cuff, is guaranteed to be free of defects in workmanship and materials for a period of two years from the date listed on the purchase record, when used in accordance with the instructions provided with the unit. The unit cuff is warranted to be free from defects in materials and workmanship appearing with in one year from the date listed on the purchase record when the unit is used in accordance with the instructions provided with the unit. - Page 26 EC REP RIOMAVIX S.L. Calle de Almansa 55, 1D, Madrid, 28039 Spain Manufacturer: Shenzhen Finicare Co., Ltd 201, No.50, the 3rd Industrial Park, Houting Community, Shajing Street, Bao'an District, Shenzhen 518104 China E-mail: info@finicare.com Website: https://www. nicare.com/ Made in China...
