Finicare FC-BP100 Manual

Upper arm electronic blood pressure monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction Manual
Upper Arm Electronic Blood
Manual Ver.: 1.0
Software Ver.: FC-BP100-V1.0
Issuing Date: 2021/09/28
Please read this instruction manual carefully before
using your unit.
Please keep this instruction manual well for future use.
Thanks for choosing the Digital Blood Pressure Monitor.
The PATIENT is an intended OPERATOR.
Pressure Monitor
Model No.: FC-BP100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FC-BP100 and is the answer not in the manual?

Questions and answers

Related Manuals for Finicare FC-BP100

Summary of Contents for Finicare FC-BP100

  • Page 1 Instruction Manual Upper Arm Electronic Blood Pressure Monitor Model No.: FC-BP100 Manual Ver.: 1.0 Software Ver.: FC-BP100-V1.0 Issuing Date: 2021/09/28 Please read this instruction manual carefully before using your unit. Please keep this instruction manual well for future use. Thanks for choosing the Digital Blood Pressure Monitor.

  • Page 2: Table Of Contents

    Contents Contents..................2 1. Before Using the Unit............2 1.1 Introduction.................2 1.2 Important safety notices..........3 1.3 Warning and safety notices..........3 2. Operating Instruction.............4 2.1 Know your unit..............4 2.2 Battery Installation / Replacement......6 2.3 Settings................6 2.4 Proper Use of the Arm Cuff...........9 2.5 Take a Measurement............12 2.6 Use the Memory function..........13 2.7 About Blood Pressure............15 2.8 About Blood Pressure............16...

  • Page 3: Contents

    1. Before Using the Unit 1.1 Introduction Thank you for purchasing Upper Arm Electronic Blood Pressure Monitor. The unit uses the oscillometric method of blood pressure measurement. It means the unit detects the movement of your blood through your brachial artery, and converts your blood pressure into a digital reading.

  • Page 4: Important Safety Notices

    1.2 Important safety notices To assure the correct use of the product basic safety measures should always be followed including the precautions listed as below: ■ Please read all information in the instruction manual and any other literature included in the box before using the unit.

  • Page 5: Operating Instruction

    1.3 Warning and safety notices ■ Regarding the application of the CUFF and its pressurization on any limb where vascular access or therapy, or an arteriole-venous (A-V) shunt, is present because of temporary interference to blood flow and could result in injury to the PATIENT; ■...
  • Page 6 Display Time/ Date User number Low battery Blood pressure Classification Systolic pressure Temperature icon Diastolic pressure Sound icon Display icon Wireless icon Unit icon Body motion detection icon Average icon Sleeve with Memory icon self-check icon Arrhythmia Pulse detected Pulse rate Arm Cuff...

  • Page 7: Battery Installation / Replacement

    Power 4 AA Alkaline Batteries Do not use rechargeable batteries. Instruction Manual ● Please keep the instruction manual well after using. 2.2 Battery Installation / Replacement 2.2.1Remove the battery covers from the battery compartment. 2.2.2 Install 4 “AA” size batteries to match the + (positive) and - (negative) polarities with the polarities of the battery compartment as indicated.
  • Page 8 2.3.2 To set date and time Based on first step and press “ SET ” button again. The mark of month and date appears and flashes, press the “ MEM ” button to change the month and press the “ SET ” button to cotinue with next step. Then set the day, the hour and the minute by using the same way.
  • Page 9 Hour Setting Minute Setting 2.3.3 To set 12 or 24 hours Based on the second step and press the “ SET ” button, the “12 hours” appears and flashes, then press the “ MEM ” button to switch into “24 hours”. Presss the “...

  • Page 10: Proper Use Of The Arm Cuff

    2.3.5 To set voice Based on forth step, press the “SET” button again to adjust the sound “ ” or" " page. When the “ ” appears and flashes, press “ MEM ” button to change it. when the screen shows " "...
  • Page 11 2.4.2 Remove all clothes from your upper arm allowing the cuff to fit directly on the skin. 2.4.3 Sit in a chair with your feet flat on the floor. Place your arm on a table so as to level the cuff...
  • Page 12 2.4.6 The hose runs down the inside of your arm. The bottom of the cuff should be approximately 1~2cm above your elbow. 1 ~ 2cm 2.4.7 Wrap the cuff tightly around your upper arm by using the Velcro strip. Do not leave any spacing between the arm and the cuff.

  • Page 13: Take A Measurement

    1. The device has the WHO warning strip “ ” symbol display function, with the blood pressure value change, the higher blood pressure value “ ” symbol will appear relatively in the higher position (refer to WHO definition of high blood pressure levels-reference table). 2.

  • Page 14: Use The Memory Function

    2.5.2 Measurement start. When pressurized to stop blood flow, the Blood Pressure Monitor stops pressure before automatically leaking air and automatically measuring blood pressure. The heartbeat symbol flashes once a pulse is detected. When the heart beat symbol appears and flashes, the Blood Pressure Monitor detects the pulse and begins to calculate the pulse automatically.
  • Page 15 2.6.1 To enter the memory mode & to read the average value Press the “MEM” button while the unit is off, the unit enters the memory mode and the average value of the latest 3 times measurement values of the current user will be displayed. 2.6.2 To read the measurement value Press the “MEM”...

  • Page 16: About Blood Pressure

    2.7 About Blood Pressure 2.7.1 Irregular Heartbeat Symbol IHB When the unit detects an irregular rhythm two or more times during the measurement, the irregular heartbeat Symbol will appear on the display with the measurement values. An irregular heartbeat rhythm is defined as a rhythm that is more than 25% slower or 25% faster from the average rhythm which detected while the monitor is measuring the systolic blood pressure and the diastolic blood pressure.

  • Page 17: About Blood Pressure

    2.7.3 Health and Blood Pressure The incidence of hypertension increases with age. In addition, if lack of exercise, excess body fat and high levels of cholesterol(LDL), would sticks to the inside of blood vessels, which reduces elastictity of these vessels. Hypertension accelerated arteriosclerosis which can lead to serious conditions such as stroke and myocardial infarction.

  • Page 18: Care And Maintenance

    2.8.2 Symptoms of High Blood Pressure High blood pressure can go unnoticed for a long time, since it doesn’t cause noticeable symptoms. The following are possible causes of abnormally high blood pressure: ●Overweight; ●High cholesterol level; ●Smoking; ●Excessive alcohol consumption; ●Stress and emotional upset;...

  • Page 19: Calibration And Service

    3.1.7 We will provide circuit diagrams, component part lists, descriptions, calibration instructions, or other information to assist service personnel who is trained by the manufacturer and has got the relevant qualification certificate. 3.2 Calibration and Service The accuracy of this blood pressure monitor has been carefully tested and is designed for a long service life.

  • Page 20: Technical Data

    3.5 Technical Data 3.5.1 Specifications Model FC-BP100 Measurement Method Oscillographic measurement method Display LCD Digital Display Wireless transmission Bluetooth BLE4.2 module Blood Pressure range: 0~299mmHg (0 kPa - 39.9 kPa) Measurement Range Pulse: 40 to 180 beats/min Static Pressure: ±3mmHg(±0.4 kPa) Accuracy Pulse rate: Within ±5% of reading...
  • Page 21 30 cm (12 inches) to any part of the Upper Arm Electronic Blood Pressure Monitor (M/N: FC-BP100), including cables specified by the manufacturer. Otherwise, degradation of the performance of this equipment could result.
  • Page 22 Technical description 1.all necessary instructions for maintaining BASIC SAFETY and ESSENTIAL PERFORMANCE with regard to electromagnetic disturbances for the excepted service life. 2. Guidance and manufacturer’s declaration -electromagnetic emissions and Immunity Table 1 Guidance and manufacturer’s declaration - electromagnetic emissions Emissions test Compliance RF emissions...
  • Page 23 Radiated RF 10 V/m 80 MHz – 2,7 GHz 10 V/m 80 MHz – 2,7 GHz IEC61000-4-3 80 % AM at 1 kHz 80 % AM at 1 kHz NOTE UT is the a.c. mians voltage prior to application of the test level. Table 3 Guidance and manufacturer’s declaration - electromagnetic Immunity Test...
  • Page 24 GSM 1800; 1720 CDMA 1900; GSM 1900; Pulse 1700 – 1845 DECT; modulation 1990 LTE Band 217 Hz 1, 3,4, 1970 25; UMTS Bluetooth, WLAN, Pulse 2400 – 2450 802.11 b/g/n, modulation 2570 RFID 2450, 217 Hz LTE Band 7 5240 5100 –...

  • Page 25: Warranty Information

    State: Bluetooth connection and transmission function: search for "Device name XXX" to open the APP, turn on the blood pressure monitor, turn on the Bluetooth, connect to the Bluetooth, and start data transmission. The blood pressure monitor is turned off and Bluetooth is turned off. 3.6 Warranty Information ■...
  • Page 26 Correct Considerations for measuring measurement Take off the thick posture 1.The correct using method clothes like sweater to measure （1）Elbow on the table；comfortably seated； Keep the body straight Keep the center of the cuff legs uncrossed；back and arm supported； and heart at the same height （2）Keep the center of the cuff...
  • Page 27 ABMED SERVICE INC 1312 17th Street Suite 692 Denver, CO US 80202 Tel: 303 8000162 E-mail: info@abmed.com.cn Manufacturer: Shenzhen Finicare Co., Ltd 201, No.50, the 3rd Industrial Park, Houting Community, Shajing Street, Bao'an District, Shenzhen 518104 China FCC ID： 2A3QXFCBP100 Website: https://www.finicare.com/...
