USER
MANUAL
Series
Artic / Artic Plus /
Artic Lite / Alisios
Edition
May 2025
Models
DS-9KTP
DS-12KTP
APD-07FX
DS-18KTP
APD-09FX
DS-24KTP
APD-09FX2
DS-9KTP-4
APD-12FX
DS-12KTP-4
APD-12FCX
DS-18KTP-4
DS-9KTP-5
DS-24KTP-4
DS-12KTP-5
DS-9KLF
DS-18KTP-5
DS-12KLF
DS-24KTP-5
DS-18KLF
DS-9KTP-6
DS-24KLF
DS-12KTP-6
UM
En
DS-18KTP-6
DU-9KTP
DS-24KTP-6
DU-12KTP
DC-9KTP
DU-18KTP
DC-12KTP
DG-9KTP
DC-18KTP
DG-12KTP
DC-24KTP
DG-18KTP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Artic Plus Series and is the answer not in the manual?

Questions and answers

Related Manuals for Daitsu Artic Plus Series

Summary of Contents for Daitsu Artic Plus Series

  • Page 1 USER MANUAL Series Models DS-9KTP DS-18KTP-4 DS-9KTP-5 DS-18KTP-6 DU-9KTP DS-12KTP DS-24KTP-4 DS-12KTP-5 DS-24KTP-6 DU-12KTP Artic / Artic Plus / APD-07FX DS-18KTP DS-9KLF DS-18KTP-5 DC-9KTP DU-18KTP Artic Lite / Alisios APD-09FX DS-24KTP DS-12KLF DS-24KTP-5 DC-12KTP DG-9KTP APD-09FX2 Edition DS-9KTP-4 DS-18KLF DS-9KTP-6 DC-18KTP DG-12KTP APD-12FX...
  • Page 2 Statements...

  • Page 3: Table Of Contents

    CONTENTS Wi-Fi Module specification and Operation guideline .........4 .........5 Download and Install the App ...............6 Registration .......................7 Login ........................8 ......................11 Add device ..................14 Air conditioner control Account management ...................31 Trouble Shooting ................34...

  • Page 4: Wi-Fi Module Specification And Operation Guideline

    Wi-Fi Module specification and Operation guideline 1. Minimum specifications on a Smart phone: Android 5.0 version or higher IOS 9.0 version or higher 2. Basic parameters for Wi-Fi module Parameters Details 2.400 - 2.4835GHz Network frequency IEEE 802.11 b/g/n Standards of WLAN (channels 1-14,channels 1-13 for EU/AU,channels 1-11 for US/CA) Protocol stack support IPv4/TCP/UDP/HTTPS/TLS/DNS...
  • Page 5 1. Open the panel of indoor unit.

  • Page 6: Download And Install The App

    For Android smart phone e Google "Play Store" on your smart phone and search "Daitsu Connect", Open the Google "Play Store" on your smart phone and search "Daitsu Connect", d and install the APP. download and install the APP.

  • Page 7: Registration

    Registration 1. If you don't have any account please tap button "Register". 2. Read the Privacy Policy and tap "Agree". Notice We understandthe importance of privacy. Inorder to morefully present our collection and useof your personal information, we haverevised our privacy policy and user agreementin detail in accordance with the latest laws and regulations.

  • Page 8: Login

    Registration 6. Enter the verification code you received fr o m e-mail. 7. Set the Password with 6-20 character s including characters and numbers. 8. Tap "Done". < < Enter verification Set Password code * * * * * * * * * * * * 6-20 characters for password, including character, numbers Verification code is sent to your email:...
  • Page 9 Kitchen Recommended Study Room Living Room Master Bedroom Add Room Dining Room Second Bedroom Allow Daitsu Connect to access this You can change the room settings anytime device's location? Kitchen Study Room Porch ALLOW ONLY WHILE IN USE Balcony Kids Room...
  • Page 10 Login Forgot the password If you forgot the password or you want to reset the password, operate as below: 1. Tap "Forgot password". 2. Enter your account(e-mail address) and tap button "Obtain verification code". 3. Enter the verification code received by your e-mail. 4.

  • Page 11: Add Device

    Add device There are 3 methods to add the device. 1-CF mode 1. Power on the indoor unit, no need to launch the air conditioner. Work office 2. Click "+" in the upper right corner of the "Home" screen Welcome Home or tap "Add device"...
  • Page 12 No devices 6. Read the instruction carefully and tap "Connect now". Add Device < 7. In the network setting screen, select "Daitsu Connect", and tap" ". 8. You can see the percent rate of connecting process, at the same time "PP","SA","AP"...
  • Page 13 Add device There are 3 methods to add the device. 3-Blue tooth mode Work office 1.Power on the indoor unit, no need to launch the air conditioner. Welcome Home 2.Click "+" in the upper right corner of the "Home" screen Set your home location for more information or tap "Add device"...

  • Page 14: Air Conditioner Control

    Air conditioner control The device control screen will pop up automatically after adding the device. The device control screen will pop up manually by tapping the device name on the home screen. my home Welcome home Set your home location, get more information All Devices Living Room...
  • Page 15 Air conditioner control Control form1 The main control interface Device details Back to the < Sam p l e2 and management Home screen Turn ON/OFF the air conditioner Indicator of setting temperature Set T em p erature Selected Mode/Fan speed/ Functions indicator Increase the Decrease the...
  • Page 16 Air conditioner control Control form1-Mode setting Control form1-Select fan speed 1. Tap Mode to pop up the Mode screen. 1. Tap Fan to pop up the Fan screen. 2. Select one of the mode Feel/Cool/Heat/Dry/Fan. 2. Select one of the fan speed High/med/Low/Auto. 3.
  • Page 17 Air conditioner control Control form1-Timer adding 3. Select the time, select the repeat days and Timer on/off. 4. Select the Mode/Fan speed/Function and select the setting temperature for Timer on. 5. Tap Save to add the timer. Timer on Timer off T im er sub m it T im er cancel C ancel...
  • Page 18 Air conditioner control Control form2 The main control interface Back to the Sample1 Tips Home screen Name of thedevice Current mode Cool Increase the Decrease the setting temperatur e setting temperatur e Different backgr o und for different mode: Cool/Heat/Dry/Fan/Auto Selected Functions indicator Function Buttons...
  • Page 19 Air conditioner control Control form2-Mode setting 1. Tap the Mode button. 2. There are 5 modes on the Mode screen, tap one button to set the Air conditioner working mode. 3. Tap the X button to back the main control screen. 4.
  • Page 20 Air conditioner control Control form2-Air Flow control 1. Tap the Precision Air Flow button or S wing Flow button. 2. Choose your desired air flow and tap it. 3. Tap the X button to back to the main c o ntrol screen. 4.
  • Page 21 Air conditioner control Control form2-ECO function 1. For Eco function, just tap the button to activate the function, the button will be lighting and the indicator will appear on the screen. 2. Tap again to disable the function. 3. Temperature controlled for some air conditioner model: In Cooling mode, the new setting temperature will 26 .
  • Page 22 Air conditioner control Control form2-Sleep function 1. Tap the Sleep button. 2. Choose your desired sleep mode and tap it. 3. Tap the X button to back to the main c o ntrol screen. 4. The selected sleep mode indicator will appear on the screen. Mode Sleep enabled Sample1...
  • Page 23 Air conditioner control Control form2-Timer(on) setting 1. Tap the Timer button. 2. Tap + in the upper right corner of the Timer main screen. 3. Choose the Time/Repeat/Switch OFF then tap Save. 4. The timer(off) will appear on the Timer main screen. Sample1 <...
  • Page 24 Air conditioner control Control form2-Timer(off) setting 1. Tap the Timer button. 2. Tap + in the upper right corner of the Timer main screen. 3. Set the Time/Repeat Date/Switch(ON)/Temperature/Mode/ Fan speed/Air Flow as your desired and then tap Save. 4. The timer will appear on the Timer main screen. <...
  • Page 25 Air conditioner control Control form2-Timer management 1.Change the Timer setting: Tap anywhere of the timer list bar except the switch bar to get into the Timer setting screen, change the setting and then tap save. 2.Enable or Disable the Timer: Tap the left of the switch to disable the Timer.
  • Page 26 Air conditioner control Control form2-More functions 1.Tap the More button to operate additional functions if it appears on the screen. < More Sa m p l e1 Cool Display Buzzer Anti-Mildew GEN Mode Health Reservation Electricity Electricity Self-diagnosis Management Monitoring Mode Fan Speed Precision ON/OFF...
  • Page 27 Air conditioner control Control form2-More functions 7. Tap the "Electricity Monitoring" button if it is available on the screen. In this function, you can monitor the air conditioner electricity consumption. You can tap this button to Electricity monitoring Electricity monitoring pop up the calender then select the date.
  • Page 28 Air conditioner control Control form2-More functions 11. Tap the "Self-diagnosis " button, if it is available on the screen. The air conditioner will automatically diagnosis itself and indicate the Error code and the problem instructions if possible. Self-diagnosis Self-diagnosis Checking Complete Self-diagnosis Error code: E0...
  • Page 29 Air conditioner control Device details and management on control f o rm1 or tap ... on control form2 , get into the device det a ils screen. Here you can get some useful information and sharing the device t o other accounts. Check the following pictures and instructions carefully .
  • Page 30 Air conditioner control Device details and management How to share the devices to other accounts? 1. Tap "Device Sharing" and pop up Device Sharing screen. 2. Tap "Add Sharing". 3. Select the region and enter the account which you want to sharing. 4.

  • Page 31: Account Management

    Account management Account Profile setting Profile my home Nick name > Welcome home Account****** Set your home location, get more information Home Management > All Devices room Living Room Master Bed Message Center > Sample1 Help Center > Turned off More Services >...
  • Page 32 Account management Home(Family) management 1. Tap the name of home at the left upper corner of the Home Screen and select the Home Management. Or tap Me and tap Home Management. 2. Tap one of the families in the family list and get into Family Settings screen. <...
  • Page 33 2. Daitsu Connect can be altered without notice for quality improvement and also be deleted depending on the circumstances of manufacturing firms . 3. In case Wi-Fi signal strength is weakened, Daitsu Connect may be disconnected. So make sure the indoor unit near to wireless router.

  • Page 34: Trouble Shooting

    If you cannot control the app (air conditioner) even after power restored, you will need to connect the air conditioner by CF mode again. 1.Daitsu Connect display Air conditioner Device offline. Please check the following conditions. 1)The air conditioner has been reconfigured.
  • Page 35 Visita daitsu.es Eurofred S. A. Marquès de Sentmenat, 97 08029 Barcelona www.eurofred.com...
