Giant TWIST FREEDOM DX - DATASHEET 2 Datasheet

Twist
freedom dx

Specifications

siZes Regular, Large
CoLour Silver Anthracite

FrAme

ALUXX-Grade aluminum
Fork SR Suntour suspension 63mm travel
shoCk N/A
hAnDLeBAr Alloy, high-rise
stem Alloy adjustable
seAtpost Suspension 27.2mm
sADDLe Unity Comfort Groove +
peDALs Comfort platform
shiFters Shimano Revo twist
Front DerAiLLeur N/A
reAr DerAiLLeur Shimano NEXUS 8SPD internal gearing
BrAkes Alloy direct pull v-brake
BrAke Levers Alloy Comfort
CAssette Shimano 18T
ChAin KMC Z51
CrAnkset Giant PedalPlus 46T
Bottom BrACket Cartridge
rims Alloy double wall 36H
huBs F:SyncDrive Motor / R:Shimano NEXUS
spokes Stainless Steel 14g
tires Kenda 700x35c w/ Slime tubes
2 Lithium Ion 24V EnergyPaks w/ charger

extrAs

rear rack w/ EnergyPak cover & lock,
fenders, kickstand, bell, rear LED light
Specifications and availability subject to change without notice.
$

Spec Features

— Shimano NEXUS 8-speed internal-geared shifting
— Powered by dual 24V lithium-ion battery EnergyPaks
— SR Suntour front suspension fork w/ 63mm travel
— Includes: battery charger, fenders, rear rack, kickstand, rear LED light

frame geometry

A B C
Actual part head seat
Frame size number Angle Angle*
inches degrees degrees
Reg. 17.5 299803 70.0 72.0
Large. 21.0 299804 70.0 72.0
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
D E F
toptube** headtube Chainstay wheelbase
inches inches inches inches
23.0 6.3 19.2 44.0
23.6 7.1 19.2 44.6
63
G H
standover
height***
inches
30.8
33.5
