01865 767676
sales@unicol.com
www.unicol.com
RH200-UHD
Screen Size: 71-98"
Guide Max. Weight: 200kg
Revised 21/05/25
*Please check model specific details before installing*
WARNING
Please carefully inspect the product before assembling. If you notice any apparent damage, call your
carrier claims agent and do not continue the installation until it has been reviewed. Please watch for pinch
points. Do not put your fingers between moveable parts. Do not tamper with or disassemble any spring
loaded parts. Before installing, make sure that the supporting surface will support five times the combined
load of the solution and the hardware. Never exceed the maximum load capacity. Please also layout all
components to ensure that you have all of the required parts before proceeding (see BOM list on following
page). Use of this product for anything other than its specified use may result in failure or personal
injury. This product is intended for indoor use only. We recommend using a qualified trades person for
installation. Use an assistant or lifting equipment to lift and position products.
For support, please call: +44 (0)1865 767676 or email: sales@unicol.com
Advertisement
Related Manuals for Unicol RH200-UHD
Summary of Contents for Unicol RH200-UHD
- Page 1 Use of this product for anything other than its specified use may result in failure or personal injury. This product is intended for indoor use only. We recommend using a qualified trades person for installation. Use an assistant or lifting equipment to lift and position products. For support, please call: +44 (0)1865 767676 or email: sales@unicol.com...
-
Page 2: Tools Required
01865 767676 sales@unicol.com www.unicol.com TOOLS REQUIRED INSTALLERS REQUIRED Pozi Head Screwdriver 4mm & 5mm Allen Keys 19mm Spanner 17mm Spanner COMPONENTS DESCRIPTION RH200UHD Heavy Duty Mast Heavy Duty Mount Arms Universal Screen Arms Stabilisation Arms Two Part Base Cover Heavy Duty Stand Base... - Page 3 01865 767676 sales@unicol.com www.unicol.com STEP 2 STEP 1 Unlock and lift out front cabinet door. Remove lower Connect base to mast as shown. For a trolley front panel by unscrewing 8x M6 screws and put version, tap castors with the rubber mallet until they aside.
- Page 4 01865 767676 sales@unicol.com www.unicol.com STEP 5 STEP 6 **This must be done before fitting either screen and should remain in the support position (shown Thread any cabling through the highlighted holes in above) until both screens are fitted.** the top front panel. Screw the panel back into place as shown and tighten.
- Page 5 01865 767676 sales@unicol.com www.unicol.com STEP 9 STEP 10 When screens are fully secure, undo the handwheel Once centered, adjust the level of the screen with and fold the stabilisation arm back up. Reattach to the two top screws on the mount arms. Once the back of the mount arm.
-
Page 6: Sound Bar
01865 767676 sales@unicol.com www.unicol.com SOUND BAR SBM & SBT GENERAL ASSEMBLY INSTRUCTIONS The SBT fixes to the 4x 150x150mm centre holes on Connect your device to mount plate . Each mount the mast of some stands/trolleys. In some cases, this is dedicated to your device so may vary from the may include a span bar unit. - Page 7 01865 767676 sales@unicol.com www.unicol.com VCTST VCTS SOUND BAR & VIDEO CAMERA VCSS GENERAL ASSEMBLY INSTRUCTIONS Connect your device to mount plate . Each mount Connect the mount plate to the bottom of the rails is dedicated to your devices so may vary from the image above.
- Page 8 Any Questions? +44 (0)1865 767676 sales@unicol.com unicol.com/instructions...
