Giant TWIST EXPRESS RS 2 W Datasheet

136
twist
EXPRESS RS 2 W

Specifications

siZes
S,M
CoLour Anthracite/Blue

FrAme

ALUXX-grade aluminum
Fork Rigid allloy
shoCk N/A
hAnDLeBAr Alloy high-rise
stem Alloy adjustable
seAtpost Suspension 27.2mm
sADDLe Giant Comfort Groove
peDALs Comfort platform
shiFters SRAM MRX Pro twist
Front DerAiLLeur N/A
reAr DerAiLLeur Shimano Altus
BrAkes Alloy direct pull v-brake
BrAke Levers Tektro Alloy
CAssette Shimano 11-28 7SPD
ChAin KMC Z51
CrAnkset Alloy 3PC 46T
Bottom BrACket Cartridge
rims Alloy double wall 36H
huBs F:SyncDrive Motor / R:Alloy QR
spokes Stainless Steel 14g
tires Kenda 700x35c w/ Slime tubes
Lithium Ion 36V EnergyPak w/ charger,

extrAs

rear alloy rack w/storage case &
EnergyPak lock, fenders, kickstand, bell
Specifications and availability subject to change without notice.
$
Spec Features
— SRAM MRX Pro 7-speed twist shifters w/ Shimano Altus rear derailleur
— Powered by a single 36V lithium-ion battery EnergyPak
— Includes: battery charger, fenders, rear rack w/ storage case, & kickstand
frame geometry
A B C
Actual part head seat
Frame size number Angle Angle*
inches degrees degrees
Small 15 2109900 70.0 74.0
Med 17.5 2109901 70.0 73.0
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
D E F G
toptube** headtube Chainstay wheelbase
inches inches inches inches
21.7 5.7 19.2 42.2
22.1 6.5 19.2 43.0
H
standover
height***
inches
24.5
25.0
