- Page 1 Manual No: 577014-365 • Revision: F The Red Jacket ® Submersible Turbine Pump ® FE Petro Conversion Kit Installation & Parts Lists...
-
Page 2: Return Shipping
Notice Veeder-Root makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Veeder-Root shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this publication. -
Page 3: Table Of Contents
Table of Contents Introduction Manuals Required ......................1 Installers ...........................1 Safety Precautions ......................1 FCC Information .......................2 Warnings and Instructions ....................3 Preliminary Precautions....................3 Requirements For Use .....................4 Operating Precautions....................4 Conversion Kits List ......................5 UMP Model List ........................5 Fuel Compatibilities ......................6 UMP Electrical Service Information ..................6 UMP Model Dimensions ....................6 Installation UMP &... -
Page 4: Manuals Required
Veeder-Root term in parentheses. Example: electrical connector (pigtail). When changing-out an FE Petro variable speed motor with a Veeder-Root fixed speed motor, be sure to check the length (see tables on page 6) so that proper clearance off the tank bottom is maintained (4 to 5 in [100 to 125mm] for standard and Trapper™... -
Page 5: Fcc Information
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Any changes or modifications to this equipment not expressly approved by Veeder-Root could void your authority to operate the equipment. -
Page 6: Warnings And Instructions
Introduction Warnings and Instructions Warnings and Instructions This section introduces the hazards and safety precautions associated with installing, WARNING inspecting, maintaining or servicing this product. Before performing any task on this product, read this safety information and the applicable sections in this manual, where additional hazards and safety precautions for your task will be found. -
Page 7: Requirements For Use
• The Red Jacket is designed for use only at facilities dispensing motor fuels. • Application of The Red Jacket must be consistent with NFPA Code 30A, OSHA regulations, and federal, state and local fire codes, and other applicable local regulations. -
Page 8: Conversion Kits List
Introduction Conversion Kits List Conversion Kits List The correct conversion kit to order is determined by the required dispense enable voltage (120V or 240V), control box preference (Standard or IQ2) to replace the FE Petro® MagVFC, and capacitor location preference (installed in manifold or control box). -
Page 9: Fuel Compatibilities
Fuel Compatibilities Fuel Compatibilities The Red Jacket UMP is designed to be compatible with 100 percent gasoline, or diesel and 80 percent gasoline with 20 percent methanol, ethanol, TAME, ETBE, MTBE. BioDiesel B5. Maximum Specific Gravity of the fuel pumped by the UMP is 0.87 and the Maximum Viscosity is 70 SSU at 60°F (15°C). -
Page 10: Installation
Installation UMP & Electrical Connector (Pigtail) Removal/Replacement Disconnect, lock out, and tag power at the panel before servicing the WARNING pump. 1. Refer to FE Petro® manual 400289002 for FE Pump Motor Assembly (PMA) removal instructions. 2. Remove the manifold discharge head (packer) wiring compartment cover (See FE Petro® Manual 400604005). -
Page 11: Capacitor Installation - Single Phase Umps Only
Installation Capacitor Installation - Single Phase UMPs Only Capacitor Installation - Single Phase UMPs Only These instructions apply to kits 410983-001, -002, -005, -006 and 410893-012 only. Disconnect, lock out, and tag power at the panel before servicing the WARNING pump. -
Page 12: Identification Plate Installation
Disconnect, lock out, and tag power at the panel before servicing the WARNING pump. For IQ Control Box installation and wiring, refer to Veeder-Root manual D051-330 provided with the IQ Control Box. Refer to Figure 2 through Figure 7 below for example installation and wiring diagrams. -
Page 13: Figure 3. 230 Vac Remote Control Box With 230 Vac Coil (Capacitor Installed In Manifold) - Model 880-042-5
Installation Control Box Installation LOAD CENTER PILOT LIGHT 220 OR 240 VOLT 3P S.T. TOGGLE 1 PHASE, 2 WIRE SWITCH 15A-2P SWITCHED LINE NEUTRAL BREAKER STARTER PHASE NEUTRAL EXTERNAL PILOT PILOT S3 S2 PILOT LIGHT LIGHT LIGHT (240 VOLTS) 25 WATT MAX. WIRING 15A-2P SWITCHED TROUGH... -
Page 14: Figure 4. 240 Vac Remote Control Box With 120 Vac Coil And Capacitor
Installation Control Box Installation 115 volt 25 watt WARNING Disconnect, lock out, Line starter max. and tag power at the PILOT LIGHT power panel before wiring the pump. Pilot light 3 P.S.T. toggle switch Load center 208 or 230 volt Capacitor L2 L1 S1 S2 S3... -
Page 15: Figure 5. 240 Vac Remote Control Box With 240 Vac Coil And Capacitor
Installation Control Box Installation 240 VOLT WARNING Disconnect, lock out, LINE STARTER 25 WATT MAX. and tag power at the PILOT LIGHT power panel before wiring the pump. PILOT LIGHT 3 P.S.T. TOGGLE SWITCH LOAD CENTER PH N 220 OR 240 VOLT CAPACITOR Dispenser Make ground... -
Page 16: Start Up Of The Pumping System
AC C ORDANC E W IT H L OCAL C ODES Figure 7. IQ2 Control Box Three-Phase System Connections Start Up Of The Pumping System Refer to FE Petro® manual 400289002 to re-engage the pumping system. For help or assistance call Veeder-Root Technical Support 1-800-323-1799. -
Page 17: Parts Lists
Parts Lists Capacitor Kits For capacitor located in the STP junction box, the capacitor kit is 410901-001. Pump Parts • 4” pigtail, 20 ft kit, P/N 410156-001 • UMP w/fastener kit, UMP200U1-3, P/N 852-221-5 • 60 Hz UMP w/fastener kit, UMP400U4-3, P/N 411003-001 •... -
Page 18: Iq Control Boxes
Parts Lists IQ Control Boxes 365- 7 Figure 9. Standard Control Box w/Capacitor Figure 9 Item Part Number Description 410861-001 Control box 2HP, 120V Coil 410860-001 Control box 2HP, 240V Coil 014-723-1 Pilot light assy., 120V Coil 014-720-1 Pilot light assy., 240V Coil 247-001-5 Line contractor relay 080-858-1... -
Page 19: Iq2 Control Box
Parts Lists IQ2 Control Box IQ2 Control Box Single/Three Phase 50/60 Hz 120V/240V P/N 411075-001 IQ2 Kits Part No. Title Description This is a complete kit for creating a network containing a TLS-450 Plus and up to 31 IQ2’s. The adapter is a short 24cm (9.45”) cable with an RJ-45 connector on one end for connecting to a TLS-450 Plus and an RJ-45 0411066-001 Kit –... - Page 20 Ver.: F.4, 06/03/2025...
