Giant TCR ADVANCED 1 - DATASHEET 2 Datasheet

TCR ADVANCED 1
Specifications
siZes XS,S,M,M/L,L,XL
CoLour Composite / White / Red
FrAme Advanced-grade composite
Advanced-grade composite w/
Fork
composite OverDrive steerer
shoCk N/A
hAnDLeBAr Giant Contact 31.8mm
stem Giant Contact
seAtpost Giant Vector Advanced composite
sADDLe Fi'zi:k Arione w/ MG rails
peDALs Not included
shiFters Shimano Ultegra
Front DerAiLLeur Shimano Ultegra
reAr DerAiLLeur Shimano Ultegra
BrAkes Shimano Ultegra
BrAke Levers Shimano Ultegra
CAssette Shimano Ultegra 12-25T 10SPD
ChAin Shimano Ultegra
CrAnkset Shimano Ultegra 39/53T
Bottom BrACket Shimano internal press fit
DT Swiss TRICON R 1700
rims
tubeless-compatible
huBs DT Swiss TRICON
spokes DT Swiss TRICON
tires Michelin Pro3 Light 700x23c
extrAs
Specifications and availability subject to change without notice.
$
Spec Features
— Complete Shimano Ultegra 6700-series component group
— Giant Contact handlebar & stem, Vector Advanced composite seatpost
— Wheelset: DT Swiss TRICON R 1700 tubeless-compatible
frame geometry
A B C
Actual part head seat
Frame size number Angle Angle*
centimeters degrees degrees
XS 43.0 2119910 71.0 74.5
S 46.5 2119911 72.0 73.5
M 50.0 2119912 73.0 73.0
M/L 53.5 2119913 73.0 72.0
L 55.5 2119914 73.0 72.0
XL 58.5 2119915 73.0 72.0
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
D E F G
toptube** headtube Chainstay wheelbase
centimeters centimeters centimeters centimeters
52.0 12.0 40.5 97.7
53.5 13.5 40.5 97.4
55.5 15.0 40.5 98.0
57.0 17.0 40.5 98.6
58.5 18.5 40.5 100.1
60.5 20.0 40.5 102.1
25
H
standover
height***
inches
28.5
29.2
30.1
31.0
31.7
32.4
