- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Coleman 9995B750 Owner's Manual Shop genuine replacement parts for Coleman 9995B750 Find Your Coleman Grill Parts - Select From 255 Models -------- Manual continues below --------...
- Page 2 Event Grill 9995B Series INSTRUCTIONS FOR USE © 2005 The Coleman Company, Inc. www.coleman.com IMPORTANT The handling, storage and The owner shall post in a Read this manual carefully before transportation of gas cylinders prominent location instructions assembling, using or servicing this grill.
-
Page 3: Table Of Contents
Contents FOR YOUR SAFETY If you smell gas: General Safety Information 1. Shut off gas to the appliance. General Installation Portable L.P. Gas Barbecue Cylinders 2. Extinguish any open flame. L.P. Gas Cylinder 3. Open lid. Hose and Regulator 4. If odor continues, immediately call your Transporting the Cylinder Filling and Purging Type 1 L.P. -
Page 4: General Installation
General Safety Information cont. 24" General Installation • Installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1 (USA), CAN/CGA-B149.1, Natural Gas and Propane Installation Code 24" Clear (Canada). -
Page 5: Portable L.p. Gas Barbecue Cylinders
Portable L.P. Gas Barbecue Cylinders L.P. Gas Cylinder DANGER WARNING A liquid propane tank, not connected for use with this gas barbecue, • DO NOT insert any foreign objects into the valve outlet. shall not be stored in the vicinity of this or any other appliance. You may damage the valve. -
Page 6: Hose And Regulator
• A Type 1 compatible cylinder with a Type 1 cylinder valve has hose and regulator assembly other than the one supplied with the a back-check valve which does not permit gas flow, until a pos- grill or a Coleman ® replacement pressure regulator assembly. The itive seal has been obtained. -
Page 7: Filling And Purging Type 1 L.p. Gas Cylinders
Transporting the Cylinder Filling and Purging Type 1 cont. L.P. Gas Cylinders cont. WARNING Handle a full cylinder with care. Gas is under high pressure. CGA-510 POL DANGER • NEVER store a spare L.P. gas supply cylinder under the grill body or inside grill enclosure or in the vicinity of any heat producing appliance. -
Page 8: To Set Up
Event Grill. CAUTION Because of its size and weight, it is recommended that there are at ® least two (2) people available to set up your Coleman Event Grill. ■ Remove components from carton. (Fig. 15 & 16) Fig. 18 Fig. - Page 9 To Set Up continued Step 6 Step 4 LEFT LID (SHELF) ■ Place a 20 lb. CENTER LID RIGHT LID (SHELF) propane cylinder in the right tank mount and secure as shown. (Fig. 23 & 24) Fig. 30 ■ Unlock Right Lid. NOTE: Point cylinder valves NOTE: Undo latches on...
-
Page 10: Leak Testing
3. Stop a leak by tightening the loose joint, or by replacing the faulty part with a replacement part recommended by Coleman. DO NOT attempt to repair the cylinder valve if it should become damaged; the cylinder MUST be replaced. -
Page 11: Lighting The Grill
Lighting the Grill Lighting the Grill continued Step 3 WARNING ■ Turn right side burner valve to THE FOLLOWING RULES MUST ALWAYS BE “High.” (Fig. 39) FOLLOWED IN THIS ORDER : ■ Press igniter button to light. (Fig. 40) 1. Check that the Burner Control Knobs are turned to “OFF.” NOTE: If the flame doesn’t 2. - Page 12 Tear Down/Clean Tear Down/Clean continued continued Step 6 ■ Center Lid goes on first. (Fig. 49) Step 3 ■ Remove Regulators from Propane Cylinder Connection. (Fig. 44) Fig. 49 Fig. 44 Step 7 ■ Lift up on Right Side Shelf to remove from grill and fold in flaps as shown.
-
Page 13: General Use And Correct Burner Flames
General Use and Correct Burner Flames Good Yellow WARNING Blue Yellow • Keep grill area clean and free from combustible materials, gasoline and other flammable vapors, liquids, and spare L.P. cylinders. • DO NOT obstruct the flow of combustion and ventilation air. Blue •... -
Page 14: Storage
• For more complicated maintenance or to obtain repairs, please contact To enjoy years of outstanding performance from your grill, perform the fol- The Coleman Company, Inc. lowing maintenance activities on a regular basis: • Keep exterior surfaces clean. -
Page 15: Replacement Parts List
Replacement Parts 9995B Series Event Grill Parts List Part No. Description 9995A2181 Center Lid Assembly - Black 9995A1511 Cooking Grate (1 pk) 9995-2411 Spacer w/hardware (1 pk) 9995-1191 Heat Tent w/hardware 9995-2021 Burner w/hardware (1 pk) 9995-1571 Bumper w/hardware (1 pk) 9995A2051 End Lid Assembly - Black (1 pk) 9995A5601... - Page 16 Accessories The following accessories are available: • Griddle • Cover 9995A350 9995-099 Visit us at www.coleman.com Call us at 1-800-835-3278...
-
Page 17: Warranty
TDD: 316-832-8707 to state or province to province. www.coleman.com ® The Coleman Company, Inc. • 3600 N. Hydraulic • Wichita, KS 67219 U.S.A. 1-800-835-3278 • TDD: 316-832-8707 © 2005 The Coleman Company, Inc. All rights reserved. Coleman ® and are registered trademarks of The Coleman Company, Inc.
