IMPORTANT
Read this manual carefully before
assembling, using or servicing this grill.
Keep this manual for future reference. If
you have questions about assembly,
operation, servicing or repair of this grill,
please call Coleman at 1-800-835-3278
or TDD: 316-832-8707.
Event Grill
9995B Series
INSTRUCTIONS FOR USE
© 2005 The Coleman Company, Inc.
www.coleman.com
The handling, storage and
transportation of gas cylinders
must be in accordance with
ANSI/NFPA 58, Storage and
Handling of Liquified Gases, or
CSA B149.1, Natural Gas and
Propane Installation Code.
• 9-volt Battery included
• 20# L.P. gas cylinders
not included
For Outdoor Use Only
The owner shall post in a
prominent location instructions
to be followed in the event the
user smells gas. This informa-
tion shall be obtained by
consulting the local gas
supplier.
GAS BARBECUE
ANSI Z83.11 • CSA 1.8 (2002)
FOOD SERVICE EQUIPMENT
®
Advertisement
Table of Contents
Related Manuals for Coleman 9995B Series 9995B750
Summary of Contents for Coleman 9995B Series 9995B750
-
Page 1: Instructions For Use
Coleman at 1-800-835-3278 or TDD: 316-832-8707. Event Grill 9995B Series INSTRUCTIONS FOR USE © 2005 The Coleman Company, Inc. www.coleman.com The handling, storage and transportation of gas cylinders must be in accordance with ANSI/NFPA 58, Storage and Handling of Liquified Gases, or CSA B149.1, Natural Gas and... -
Page 2: Table Of Contents
• NEVER use charcoal briquettes or lighter fluid in a gas grill. (Fig. 6) • Grill is hot when in use; to avoid burns, DO NOT touch any hot grill • NEVER leave the grill unattended while it is in use. (Fig. 8) •... -
Page 3: General Safety Information
WARNING Keep any electrical supply cord away from any heated surface. During assembly of grill and when attaching or replacing the L.P. gas cylinder, insure that the gas supply hose is free of kinks and is at least 3" away from hot surfaces such as the grill housing. -
Page 4: Portable L.p. Gas Barbecue Cylinders
• If the grill is not in use, the gas must be turned off at the supply cylinder(s). • Cylinders must be stored outdoors out of the reach of children and must not be stored in a building, garage or any other enclosed area. -
Page 5: L.p. Gas Cylinder
The pressure regulator and hose assembly with the Type 1 fitting supplied with the appliance must be used. Do not use another hose and regulator assembly other than the one supplied with the grill or a Coleman ® replacement pressure regulator assembly. The pressure regulator and hose assembly provided is factory set at an outlet pressure of 11 inches water column (1/2 psi). -
Page 6: Transporting The Cylinder
Handle a full cylinder with care. Gas is under high pressure. DANGER • NEVER store a spare L.P. gas supply cylinder under the grill body or inside grill enclosure or in the vicinity of any heat producing appliance. (Fig. 12) • NEVER fill the cylinder beyond 80% full. -
Page 7: To Set Up
Coleman Event Grill. CAUTION Because of its size and weight, it is recommended that there are at least two (2) people available to set up your Coleman ■ Remove components from carton. (Fig. 15 & 16) Fig. 15 Fig. 16 Step 2 ■... - Page 8 Step 5 NOTE: Storage position for the regulator is above the grease pan. ■ Unlock the grease pan (located on the back side of the grill). (Fig. 25) ■ Slide the grease pan half way out. (Fig. 26) Fig. 25 ■...
-
Page 9: Leak Testing
3. Stop a leak by tightening the loose joint, or by replacing the faulty part with a replacement part recommended by Coleman. DO NOT attempt to repair the cylinder valve if it should become damaged; the cylinder MUST be replaced. -
Page 10: Lighting The Grill
OFF position. (Fig. 37) NOTE: Follow this Lighting Procedure to light Burners on one side of the grill then repeat to light the Burners on the other side of the grill. Step 2 ■ Turn on fuel supply on righthand L.P. - Page 11 ■ Center Lid goes on first. (Fig. 49) Fig. 44 Step 7 ■ Lift up on Right Side Shelf to remove from grill and fold in flaps as shown. (Fig. 50 & 51) Step 8 ■ Place folded up Right Lid (Shelf) on grill.
-
Page 12: General Use And Correct Burner Flames
WARNING After each time the grill is set up or moved, and before lighting the grill, verify that the Valve Orifices are properly located inside the six openings to the Burners. One View Port for each of the six Valve Orifices is located underneath the grill as shown in Fig. -
Page 13: Storage
■ Store grill in a dry, clean and safe place. Maintenance WARNING • BURN HAZARD • Do not touch or attempt any maintenance on grill for at least one hour after use. • Make sure all controls are off and propane tank has been removed before doing maintenance. -
Page 14: Replacement Parts List
Replacement Parts 9995B Series Event Grill Parts List Part No. Description 9995A2181 Center Lid Assembly - Black 9995A1511 Cooking Grate (1 pk) 9995-2411 Spacer w/hardware (1 pk) 9995-1191 Heat Tent w/hardware 9995-2021 Burner w/hardware (1 pk) 9995-1571 Bumper w/hardware (1 pk) - Page 15 Accessories The following accessories are available: • Griddle • Cover 9995A350 9995-099 Visit us at www.coleman.com Call us at 1-800-835-3278...
-
Page 16: Warranty
The Coleman Company, Inc. • 3600 N. Hydraulic • Wichita, KS 67219 U.S.A. Coleman ® and HOW TO OBTAIN WARRANTY SERVICE Take the product to an authorized Coleman service center.
