Giant CYPHER 1 Datasheet

150
CypHer 1
Specifications
SIZES XS,S,M,L
COLORS White
ALUXX SL-Grade Aluminum,
FRAME
5" Maestro Suspension
Fox 32 F120RL FIT w/ 15QR Thru Axle,
FORK
120mm travel
SHOCK Fox Float RP2
HANDLEBAR Giant Connect SL, low rise 31.8
STEM Giant Connect SL
SEATPOST Giant Connect SL, 30.9
SADDLE Fi'zi:k Vitesse w/ K:ium rails
PEDALS Wellgo LU895N
SHIFTERS Shimano Deore XT
FRONT DERAILLEUR Shimano SLX
REAR DERAILLEUR Shimano Deore XT
BRAKES Shimano Deore XT, 180F/160R
BRAKE LEVERS Shimano Deore XT
CASSETTE SRAM PG980 11x34, 9-speed
CHAIN KMC HG-73
CRANKSET Shimano Deore XT, 22/32/44
BOTTOM BRACKET
Shimano Deore XT, External
RIMS WTB Laser Disc Trail
[F] Giant Tracker w/ 15mm Axle, [R] WTB
HUBS
Laser Disc Lite, 32h
SPOKES DT Competition, 14/15g
TIRES
Kenda Nevegal, 26x2.1 Folding
EXTRAS
Specifications and availability subject to change without notice.
UNLOCK THE SECRET TO MORE CONfiDENT TRAIL
RIDING. TACKLE NEW LINES AND RIDE LONGER AND
STRONGER WITH CYPHER.
Frame Technology
Perfectly balanced to improve both your climbing and descending. 5 inches of plush Maestro
travel combined with a lightweight, easy-handling ALUXX SL frame makes this the ultimate bike
for tackling all types of singletrack. All-day epics or short, fast trail rides—Cypher is your ride.
Key Upgrades (over Cypher 2)
— Fox 32 FIT F120RL, 120mm suspension fork
w/ 15QR thru-axle, Fox Float RP2 rear shock
— Shimano Deore XT hydraulic disc brakes
— Giant Connect SL handlebar, stem and seatpost
— WTB LaserDisc Trail rim/Giant Tracker (f) hub/
WTB (r) hub/DT Competition spokes, wheelset
frame geometry
Actual Part Head Seat
Frame Size Number Angle Angle*
inches degrees degrees
XS 14.5 349452 69.5 74.0
S 16 349453 69.5 73.5
M 18 349454 69.5 73.5
L 20 349455 69.5 73.5
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Toptube** Headtube Chainstay Wheelbase
inches inches inches inches
21.1 4.9 17.1 41.8
21.7 5.3 17.1 42.2
22.2 5.9 17.1 42.8
23.0 6.7 17.1 43.7
Standover
Height***
inches
30.9
31.1
31.8
32.0
