- Page 1 D200 Instruction D200 Instruction...
-
Page 2: Table Of Contents
D200 Instruction CONTENT 1.About the Instruction ............................1 2.Outlook and size ............................. 2 2.1 Main material and color ........................... 2 2.2 Button definition ............................3 2.3 Installation method ........................... 4 3.Function outline .............................. 5 3.1 Headlight ..............................5 3.2 Speed display............................5 3.3 Units display ............................. - Page 3 D200 Instruction 4.3.1 Hardware version, Software version and Error Code ................ 7 4.4 Save & Exit .............................. 7 5.Definition of wire sequence ..........................8 6.Common questions and solutions ........................9 7.Warranty information and out-of-warranty terms ..................10 8. Error code table............................. 11...
-
Page 4: About The Instruction
D200 Instruction 1.About the Instruction Dear Users, to better operate your electric vehicle, please read the D200 user manual carefully before use. We will guide you through every aspect of the instrument's usage in the most concise language, including hardware installation, settings, and normal operation of the instrument. Additionally, we will assist... -
Page 5: Outlook And Size
2.1 Main material and color The D200 product is made of black ABS material, and its bracket is manufactured from nylon. The material of the casing allows for normal use within a temperature range of -20° C to 60° C, while ensuring excellent mechanical properties. -
Page 6: Button Definition
D200 Instruction 2.2 Button definition The D200 has four buttons, including ON/OFF、SET、UP and DOWN button. -
Page 7: Installation Method
D200 Instruction 2.3 Installation method ① Install the bracket and the instrument first ② Open the locking clamp of the instrument ③ Slide it onto the handlebar (use an M4 Allen key to fix and tighten the retaining screw, with a locking torque of 0.5 N.m.) -
Page 8: Function Outline
D200 Instruction 3.Function outline to toggle between TRIP/ODO (single mileage The D200 offers a variety of displays to /total mileage). meet your cycling needs. The display content of 3.6 Electricity display： the D200 includes: Display the remaining battery level of the current gauge in the form of a progress bar, with the bar flashing when the battery is low. -
Page 9: Settings Interface
D200 Instruction 4.Settings Interface Press and hold the SET button for 2 seconds to 4.1.2 Brightness(1 is the darkest, and enter the settings interface. Tap the SET button to 5 is the brightest.) confirm the setting item, and tap the "+" or "-"... -
Page 10: Unit
D200 Instruction 4.1.5 Unit(KMH/MPH) 4.2 Advanced Set 4.2.1 Password 4.1.6 Battery(24V/36V/48V/52V) 4.3 Information 4.3.1 Hardware version, Software version (non-selectable) ,and Error Code 4.1.7 Mode(ECO/NOR/POW) 4.4 Save & Exit ※The system will automatically enter sleep mode after the electric vehicle has been without any... -
Page 11: Definition Of Wire Sequence
D200 Instruction 5.Definition of wire sequence Figure 1 Figure 2 Figure 1： Wire Sequence Wire Color Function Blue K Weak lock Reception of instrument communication Green signals (RXD) Transmission of instrument communication Yellow signals (TXD) Black Battery - Battery + Figure 2：... -
Page 12: Common Questions And Solutions
D200 Instruction 6.Common questions and solutions Q：Why the display is not able to start up？ A：Checking the connector that between display and controller Q：How to deal with the error code? A： First, find out the corresponding problem according to the error code displayed. If you can't solve it by... -
Page 13: Warranty Information And Out-Of-Warranty Terms
D200 Instruction 7.Warranty information and out-of-warranty terms I. Warranty Information Under normal usage conditions, for faults caused by quality issues inherent in the product, our company will provide limited warranty service within the warranty period. The warranty period for the product begins from the date of purchase by the user and lasts for 18 months. -
Page 14: Error Code Table
D200 Instruction 8. Error code table The error code is corresponding with the fault definition.： Error Code Definition Normal Current error or MOSFET error Throttle error(Start detection) Motor no phase position Hall error Brake error(Start detection) Instrument communication reception is abnormal...
