- Page 1 OPERATOR'S MANUAL KZ-4000BP PRO-2S BRUSH CUTTER BACK PACK With Japan Walbro carburator Original Instructions CAUTION: - R e a d a l l p r e c a u t i o n s a n d instructions in this manual before using this product.
-
Page 2: Table Of Contents
CONTENTS FIGURE..................1 INTRODUCION…………………...........5 MEANINGS OF SYMBOLS............6 WARNINGS ＆ SAFETY INSTRUCTIONS........7 DESCRIPTION................9 ASSEMBLY..................10 OPERATING PROCEDURES............11 MAINTENANCE................13... -
Page 7: Introducion
,due to changes of specifications, all details of your machine may not agree with this manual.Please understand accordingly. The machine is only intended to be used to cut frutex, or soft vegetation. Model KZ 4000BP PRO 2S Engine Displacement (cm ) 39,8... -
Page 8: Meanings Of Symbols
MEANINGS OF SYMBOLS NOTE: Some units do not carry them. Symbols WARNING The following show symbols used for the machine. Be sure that you understand their meaning before use. It is important that you read, fully understand and observe the following G l o v e s s h o u l d b e w o r n safety precautions and warnings. -
Page 9: Operator Safety
WARNINGS ＆ SAFETY INSTRUCTIONS ○ Operator safety Replace parts that are cracked, chipped or ○ damaged in any way before using the unit/ Always wear a safety face shield or goggles. ○ machine. Always wear heavy, long pants, boots and ○... -
Page 10: Maintenance Safety
○ protection mask when cutting the grass after Clean and maintain the unit carefully and store it insecticide is scattered. in a dry place. ○ ○ Keep others including children, animals, Make sure engine switch is off when transporting bystanders and helpers outside the 15m or storing. -
Page 11: Description
DESCRIPTION Since this manual covers several models, there may be some difference between pictures and your unit. Use the instructions that apply to your unit. 1. Fuel cap 2. Throttle lever 3. Starter handle 4. Blade guard 5. Cutting attachment 6. -
Page 12: Installation Of Handle
ASSEMBLY Drive shaft to engine (Fig. 1) Installation of gear case cover (Fig. 8) Remove tube locking bolt (1). Attach the gear case cover (11) with the three Insert unholed end of fexible shaft (2) into joint screws, making sure to align the notch (12) in pipe of drive shaft (3) to the end and tighten the the gear case with the hole (13) in the gear case tube locking bolt by engaging the bolt to the slot... -
Page 13: Operating Procedures
○ Attach cutter holder (15) to the gear case. Insert Before operation, make sure the blade has been properly installed. (Fig. 13) an Allen wrench into the hole in the gear case to ○ attach winding protector (16) and attach nylon Before operation, check the cutter holder cap under the cutting blade for wear or cracks. - Page 14 WARNING 1. Slide ignition switch (18) to RUN position. (Fig. If cutting attachment should strike against * Push priming bulb (19) several times so that stones or other debris, stop the engine and fuel fl ows through return pipe. (Fig. 18) make sure that the attachment and related 2.
-
Page 15: Maintenance
MAINTENANCE MAINTENANCE, REPLACEMENT OR REPAIR ○ Engine power reduction OF THE EMISSION CONTROL DEVICES AND ○ Unnecessary wear on the engine parts SYSTEMS MAY BE PERFORMED BY ANY NON- ○ Abnormal fuel consumption ROAD ENGINE REPAIR ESTABLISHMENT OR INDIVIDUAL. Clean the air filter daily or more often if working in Carburetor adjustment (Fig. -
Page 16: Flexible Shaft
grease level about every 50 hours of operation blade, it can be used on either side. by removing the grease filler plug on the side of Use the correct blade for the type of work. ○ angle transmission. When replacing blades, use appropriate tools. ○... -
Page 17: Inspection And Maintenance
INSPECTION & MAINTENANCE For safety use, make sure the machine is cleaned every three-months. Before working, make sure to inspect the filter and the nozzle,and ensure there is no impurity. After working, make sure there is no water in the pump and the hose. If the machine needs to be repaired in the guarantee period, please return the machine to the shop. - Page 18 Warranty Card CUSTOMER COPY Purchaser’s Name & Address Date of Delivery Dealer’s Office Seal Product Name KZ-4000BP-PRO-2S BRUSH CUTTER BACK PACK Product Serial No. Dealer Sign Customer Sign. Invoice / DN No. I/We accept the terms and conditions of Warranty as in the Warranty Card.
- Page 19 1. LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defective part(s) by authorized dealer are free of charges. If found defective by reasons of defective material / poor workmanship, parts will be replaced and there will be no value re-imbursement.
- Page 20 1st Free Service Coupon ISO 9001-2008 CERTIFIED COMPANY FREE SERVICE COUPON (30 Days / 20 hrs (Which ever is earlier) Model Serial Number KZ-4000BP-PRO-2S BRUSH CUTTER BACK PACK PDI Date Service No. Operations: • Check and Test the Fuel Mixture. •...
- Page 21 Small Maintenance. Big Savings. Small Maintenance. Big Savings. Small Maintenance. Big Savings.
- Page 22 Multi-products, multi-applications Imported & Marketed by RATNAGIRI IMPEX PVT LTD Annapurna House, #1/1G, 7th Cross, New Guddadahalli Mysore Road, Bangalore-560 026 Customer Care: 1800-425-3036 email: marketing@ratnagiriimpex.com www.ratnagiriimpex.com AN ISO 9001:2008 CERTIFIED COMPANY...
