KASEI
OWNER/OPERATOR MANUAL
MULTI TOOL - BRUSH CUTTER
MODEL: KZ-4000MT-PRO-2S
With
Japan
Walbro
carburator
Original Instructions
CAUTION:
Thank you for purchasing a product. Before using our pole saw, please read
this manual carefully to understand the proper use of your unit.
4 2
