IMER MIX 360 R PLUS Instruction Manual

Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
IMER INTERNATIONAL S.p.A.
IMER U.S.A. Inc.
IMER
U.S.A.
MIX 360 R PLUS
1194661 - HONDA OMOL
1194662 - 220V-60Hz SPH
1194663 - HONDA USA
ISTRUCTION MANUAL
For US and CANADA markets
Spare Parts Manual
www.imerglobalcustomercare.com
3238892_R01_(2023_05)
S/N:
IMER U.S.A.
US & Canada Headquarters
423 Bank Street , Suite 180
Southlake, TX 76092 - USA
Tel: +1 800 275.5463
www.imerusa.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MIX 360 R PLUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IMER MIX 360 R PLUS

Summary of Contents for IMER MIX 360 R PLUS

  • Page 1 IMER INTERNATIONAL S.p.A. IMER U.S.A. Inc. IMER U.S.A. MIX 360 R PLUS 1194661 - HONDA OMOL 1194662 - 220V-60Hz SPH 1194663 - HONDA USA ISTRUCTION MANUAL For US and CANADA markets Spare Parts Manual www.imerglobalcustomercare.com 3238892_R01_(2023_05) S/N: IMER U.S.A. US & Canada Headquarters...
  • Page 2 IMER INTERNATIONAL S.p.A. IMER U.S.A. Inc. Thank you for purchasing a MIX 360 R PLUS from an IMER U.S.A dealer. Your decision is an intelligent one. There is no other mortar mixer in the world which delivers the benefits and features of the MIX 360 R PLUS: - Revolutionary horizonal mixing action.
  • Page 3 Fig.1 MIN. 1300 MAX. 1740 MIN. 465.5 MAX. 865.5 2695,5 FIG.1 TELESCOPIC SUPPORT FRAME MIXING TANK JACK SUPPORT LEG CENTRIFUGAL FOOT EXTENSION ELECTRIC MOTOR OUTLET PROTECTION CLUTCH (OPTIONAL) REDUCTION GEAR MOTOR CASING ENDOTERMIC MOTOR OUTLET PULLEY START AND STOP WASH-DOWN HOUSE REDUCTION GEAR HANDLE / TOW BAR BUTTON...
  • Page 4 IMER INTERNATIONAL S.p.A. IMER U.S.A. Inc. IMPORTANT MIXING INSTRUCTIONS AGGREGATE BIGGER THAN 1/8" WILL DAMAGE MIXER SAND SILO PRE - MIX 60 lb SILO LIME SPEC - MIX 80 lb CEMENT Set up mixer Set up mixer Set up mixer...

  • Page 5: Installation

    9.1 START-UP 4. SAFETY MEASURES 9.1.1 ELECTRICAL CONNECTION -The IMER cement mixer can only function if all the safety devices with -Check that the supply voltage is the same as dataplate specifications. which it is equipped are in perfect condition.

  • Page 6: Maintenance

    IMER INTERNATIONAL S.p.A. IMER U.S.A. Inc. -Allow the motor to warm up at reduced rpm. . WARNING -Increase the rpm to maximum using the accelerator lever mounted on Check that the machine stops when the tank protection cover is the frame.
  • Page 7 IMER INTERNATIONAL S.p.A. IMER U.S.A. Inc. DANGER INHALATION POWDER - The sealing gasket - Replace the rubber ALWAYS avoid inhalation of and skin contact is worn The discharge outlet with silica dust and/or mist. Provide proper leaks water - The spring is broken dust removal.
  • Page 8 IMER INTERNATIONAL S.p.A. IMER U.S.A. Inc. PRESA 200V / 50-60Hz CEE 200V - 50/60HZ 16A h6 FINECORSA ESTERNO AL QUADRO (CABLARE CONTATTO NC) U< INTERRUTTORE SALVAMOTORE Nota: 20-25A Il salvamotore deve essere tarato a 25A mmq. MOTORE DISCO mmq. SPINA MOBILE...
  • Page 9 Tel: +1 800 275.5463 www.imerusa.com We warrant to the original purchaser that the IMER equipment described herein (the "equi- pment") shall be free from defects in material and workmanship under normal use and service for which it was intended for period of one (1) year from the delivery date to final user and however no more than 30 (thirty) months from shipping date by IMER.
