Installation and Operating Manual This manual contains the 003A01, 061A01 installation and operating manuals that comprise a Model 907A07 **Please contact The Modal Shop for Product Information on K9907C** Simplified Aronson pressure step generator, 1000 psi, w/1 digital ref. gage & plumbing, 3- valve design kit.
Assistance is needed to safely operate equipment PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
Page 3
CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
(supplied by the user). The gage should be of sufficient quality (such as Heise) to meet the precision requirements of the user. Model 907A07 includes a precision digital Heise gage. Manual Number: 21280...
SHOCKLESS PRESSURE STEP GENERATOR Model 907A02 WITH OUT GAGES & CABINET MODEL 907A07 WITH GAGES & CABINET GENERAL DESCRIPTION The shockless pressure-step generator is a precision device which is used in the dynamic calibration of pressure sensors. Referring to Figure 2, the main parts of...
Page 8
12 inches max diameter; 21 inches max height Weight 80 pounds NOTE Not furnished with the Model 907A02 generator but required with its use: gas pressure and vacuum sources; 1 static type pressure gage and/or manometers(Model 907A07 includes 1 Heise digital pressure gage)
Page 9
P1 is used for making connections to the user-supplied (for 907A02) or Heise (for 907A07) reference gages used to monitor the static pressure within the system. When connections are being made to these rear ports, it is essential that the port fitting be prevented from turning with an open-end wrench while the Swagelok connecting nut is tightened.
Page 10
SHOCKLESS PRESSURE STEP GENERATOR MODEL 907A02 WITH OUT GAGES & CABINET MODEL 907A07 WITH GAGES & CABINET...
Page 11
SHOCKLESS PRESSURE STEP GENERATOR MODEL 907A02 WITH OUT GAGES & CABINET MODEL 907A07 WITH GAGES & CABINET...
Page 12
SHOCKLESS PRESSURE STEP GENERATOR MODEL 907A02 WITH OUT GAGES & CABINET MODEL 907A07 WITH GAGES & CABINET...
Page 13
SHOCKLESS PRESSURE STEP GENERATOR MODEL 907A02 WITH OUT GAGES & CABINET MODEL 907A07 WITH GAGES & CABINET...
Page 14
SHOCKLESS PRESSURE STEP GENERATOR MODEL 907A02 WITH OUT GAGES & CABINET MODEL 907A07 WITH GAGES & CABINET Otherwise, pressure leakage and possible damage to the Between individual calibrations the impact weight is tubing contained within the lower compartment can result.
Page 15
SHOCKLESS PRESSURE STEP GENERATOR MODEL 907A02 WITH OUT GAGES & CABINET MODEL 907A07 WITH GAGES & CABINET When the impact weight strikes the impact plate (figure 2, compressing the poppet return spring and screwing the K), multiple electrical signals are generated by the impact head in a clockwise direction.
Page 16
SHOCKLESS PRESSURE STEP GENERATOR MODEL 907A02 WITH OUT GAGES & CABINET MODEL 907A07 WITH GAGES & CABINET The introduction of gas pressure or vacuum to the initial slow or hesitant return of the stem. This reservoir occurs through the reservoir pressure valve V2.
Page 17
SHOCKLESS PRESSURE STEP GENERATOR MODEL 907A02 WITH OUT GAGES & CABINET MODEL 907A07 WITH GAGES & CABINET Using the reservoir vent valve V3 (or the Close the poppet-valve by rotating the poppet reservoir pressure valve V2) set the pressure in...
Assistance is needed to safely operate equipment PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
Page 22
CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
PCB Piezotronics Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others DESCRIPTION without the written consent of PCB Piezotronics Inc. RELEASED TO DRAFTING 50133 LENGTH .24 [ 6.1]...
Page 26
Mounting adaptor, 3/8-24 external thd to 5/16-24 internal thd, 17-4 SS (for Series 111, 112 & 113) Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 716-684-0001 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com...
Page 27
Assistance is needed to safely operate equipment PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
Page 28
CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
Page 30
Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
Page 31
PCB Piezotronics Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others DESCRIPTION without the written consent of PCB Piezotronics Inc. UPDATED NOTES 54569 ABLATIVE INSTALLATION ELECTRICAL CONNECTOR 10-32 UNF - 2A...
