Summary of Contents for PCB Piezotronics 482C15/NP
- Page 1 Model 482C15/NP Four-Channel, ICP Sensor Signal Conditioner Installation and Operating Manual For assistance with the operation of this product, contact PCB Piezotronics, Inc. Toll-free: 800-828-8840 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com Web: www.pcb.com...
- Page 2 Assistance is needed to safely operate equipment PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
- Page 3 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
- Page 4 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
- Page 5 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
- Page 6 (482C15), of that series. MANUAL #: 38410 MANUAL REV: B ECO: 50033 10/31/2019 PCB PIEZOTRONICS, INC. 3425 WALDEN AVENUE DEPEW, NY 14043-2495 PHONE 716-684-0001 FAX 716-684-0987 ® ICP is a registered trademark of PCB Group, Inc. KS398...
-
Page 7: Table Of Contents
Table of Contents Table of Contents 1-1. Introduction 1-2. Safety Considerations 1-3. Equipment Rating 1-4. Model 482C15 System Description 1-5. Model 482C05 System Description 1-6. Installation 1-7. Grounding Techniques 1-8. Unit Power 1-9. Maintenance and Repair Appendix Specification Sheet Outline Drawing... -
Page 8: Introduction
WARNING 2: This equipment is designed with user safety in mind; however, the protection provided by the equipment may be impaired if the equipment is used in a manner not specified by PCB Piezotronics, Inc. CAUTION 1: Cables can kill your equipment. High voltage ElectroStatic Discharge (ESD) can damage electrical devices. -
Page 9: Equipment Rating
MULTICHANNEL SIGNAL CONDITIONER MODEL 482C GENERAL OPERATION MANUAL CAUTION 2: ESD considerations should be made prior to performing any internal adjustments on the equipment. Any piece of electronic equipment is vulnerable to ESD when opened for adjustments. Internal adjustments should therefore be done ONLY at an ESD-safe work area. - Page 10 MULTICHANNEL SIGNAL CONDITIONER MODEL 482C GENERAL OPERATION MANUAL indicates a signal level of +/-10V Peak has been detected and the signal may be in danger of clipping. These fault lights are active for all channels, at the same time. 1-4.4. Gain selection / Jumper definition The 482C15 has internal jumpers that are accessed by opening the top cover.
-
Page 11: Model 482C05 System Description
MULTICHANNEL SIGNAL CONDITIONER MODEL 482C GENERAL OPERATION MANUAL Model 482C05 System Description The Model 482C05 is a basic four channel signal conditioning unit designed to interface measurement signals to readout or recording devices. The following are features that come standard on every 482C05: ... -
Page 12: Unit Power
MULTICHANNEL SIGNAL CONDITIONER MODEL 482C GENERAL OPERATION MANUAL 2. Insure that the sensor does not pick up line noise from the body under test. The case of the sensor should be isolated from the body under (ground) using an isolation pad. The isolation pad breaks the loop formed by the signal path of the sensor to the unit and the return (ground) from the unit back to the sensor. - Page 13 Model Number Revision: J FOUR-CHANNEL, ICP SENSOR SIGNAL CONDITIONER ECN #: 47052 482C15 Performance ENGLISH OPTIONAL VERSIONS Channels Optional versions have identical specifications and accessories as listed for the standard model Sensor Input Type(s) ICP®, Voltage ICP®, Voltage except where noted below. More than one option may be used. Voltage Gain(±...
- Page 14 PCB Piezotronics Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others DESCRIPTION without the written consent of PCB Piezotronics Inc. UPDATED ARTWORK 37737 5.92 [150.3] 8.07 [205.0] 5.51 [140.0] 2.97 [75.4]...
