- Page 1 Operation manual APULSE x1F6 IoT Data Logger for Smart Water Metering Document version: 2025/03/27 www.aiuneo.com www.aiut.com AIUT Sp. z o.o. ul. Wyczółkowskiego 113, 44-109 Gliwice, Poland Tel.: (+48 32) 77 54 000 Fax: (+48 32) 77 54 001...
- Page 2 • power supply • dimensions All rights reserved. This document is the property of AIUT sp. z o.o. and may only be used for its intended purpose. Disclosure, copying, or distribution without the owner’s consent is prohibited. AIUT reserves the right to amend this document without prior notice.
-
Page 3: Safety Instructions
APULSE x1F6 OPERATION MANUAL v. 20250327 PRECAUTIONS We encourage you to read the user manual and familiarize yourself with the benefits of our device. Failure to follow the instructions provided in this document may result in the loss of warranty. If the manual describes different types of APULSE data loggers, any differences will be indicated in the relevant sections of the text. -
Page 4: General Information
APULSE x1F6 installed and data readout by Bluetooth 5.2 & data presentation in a location MANUFACTURER Designed and manufactured in Poland by: AIUNEO AIUT Sp. z o.o. Poland, 44-109 Gliwice, ul. Wyczółkowskiego 113 www.aiut.com•www.aiuneo.com tel.: +48 32 775 40 00, e-mail: biuro@aiut.com... -
Page 5: Device Structure
APULSE x1F6 OPERATION MANUAL v. 20250327 DEVICE STRUCTURE MAGNET BUTTONY the spot where the magnet should be placed to wake up the device IMR SEAL(S) protection against unauthorized use ANTENNA built-in whip antenna BATTERY COMPARTMENT for the version with a replaceable or dual battery OVERPRINT/LABEL order number and APULSE x1F6 serial number bar code (code 128) - Page 6 APULSE x1F6 OPERATION MANUAL v. 20250327 VARIANTS AND COMPATIBILITY To ensure proper integration of the APULSE with water meters, it is crucial to match the data logger model to the technical specifications of the water meter, including its type, series, and manufacturer. The table below provides a detailed list of compatible solutions, making it easier to choose the appropriate device for your water meter.
-
Page 7: Device Versions
APULSE x1F6 OPERATION MANUAL v. 20250327 DEVICE VERSIONS The table below provides a detailed overview of the available APULSE x1F6 data loggers, including technical parameters such as battery or antenna type. Choose the solution that best matches the characteristics of your infrastructure and operational needs. -
Page 8: Technical Parameters
APULSE x1F6 OPERATION MANUAL v. 20250327 TECHNICAL PARAMETERS LOW POWER COMMUNICATION LoRa Power +14dBm Protocol LoRa WAN, specification 1.0.2 Regional parameters EU868, IN865, AU915 Activation type OTAA i ABP Sigfox Power +14dBm Protocol Radio specification 1.5 Regional parameters RC1 / RC2 / RC4 / RC6 Moc +14dBm WMBUS T1 Power +14dB... -
Page 9: Device Installation
APULSE x1F6 OPERATION MANUAL v. 20250327 DEVICE INSTALLATION The installation procedure is highly intuitive and can be completed within minutes. The APULSE data logger is installed on the water meter in just a few simple steps, secured with plastic seals. The entire process is supported by the SITA mobile application,which guides you through the installation step by step and registers the APULSE device at the selected location. - Page 10 APULSE x1F6 OPERATION MANUAL v. 20250327 MECHANICAL ASSEMBLY OF APULSE B1F6 Necessary equipment Supported BAYLAN water meters • Baylan KK-1* • Baylan KK-17 • APULSE B1F6 • Baylan KK-12* • Baylan TK-2* • 2 x IMR seal • BaylanKK-12s • Baylan VK-6 •...
- Page 11 APULSE x1F6 OPERATION MANUAL v. 20250327 MECHANICAL ASSEMBLY OF APULSE I1F6 Supported ITRON water meters Necessary equipment • APULSE I1F6 • Flodis • Woltex M • 1 x IMR seal • Aquadis+ • Unimag Cyble • 1 x cheese head nylon screw •...
- Page 12 APULSE x1F6 OPERATION MANUAL v. 20250327 MECHANICAL ASSEMBLY OF APULSE S1F6 Supported SENSUS water meters Necessary equipment • APULSE S1F6 • Sensus: 120, 120C, 405S, 420, 420PC, 620, 820 • 2 x IMR seal • 2 x Philips head screw •...
- Page 13 APULSE x1F6 OPERATION MANUAL v. 20250327 DEVICE OPERATION IN THE SITA APPLICATION DEVICE REGISTERING IN THE SYSTEM WITH SITA APPLICATION After the mechanical assembly of the APULSE device, an action must be performed to register the device in the selected location. The operation is performed using the SITA application.
-
Page 14: Archive Data
APULSE x1F6 OPERATION MANUAL v. 20250327 ARCHIVE DATA The APULSE x1F6 is equipped with a large archive (up to 10 years, depending on the configuration). The device offers two main types of archives: daily and monthly. The archives can be accessed remotely or locally using the SITA mobile application. - Page 15 APULSE x1F6 OPERATION MANUAL v. 20250327 ACCESSORIES ABAT APULSE-W I1XX-2XXX Rated capacity : 2600 mAh Rated voltage: 3,6 V Type of connection: Scotchlock connector (SL-UY-2) Dimensions [mm]: 53x57 ABAT APULSE-W D1XX-2XXX Rated capacity : 2600 mAh Rated voltage: 3,6V Type of connection: Scotchlock connector (SL-UY-2) Dimensions [mm]: 51x60 ANT 868MHZ MAGNETIC 3M...
