• Never rub the enclosure surface of OKO x4A5 using VIBRATION - product is not designed to work in a dry cloth because of the danger of electrostatic heavy vibration discharge.
BACK FRONT *for activating BLE communication in seal-run mode. See Operation of the Device OVERPRINT Order number OKO X4A5 - 1001 DSN: 01234567 Serial number Barcode, code 128 ORDER NUMBER & OKO VERSIONS Generic information Hardware/firmware version x - interface for local communication X - version with connector (Fig.2)
Maximum input voltage U Maximum internal capacitance C 40uF Maximum output voltage U Maximum internal inductance L 5,88V Negligible Maximum input power P 1,1W Maximum external inductance L Maximum output power P * In development aiut OKOx4A5. Operation Manual. 20240115 e-mail: service@aiut.com www.aiut.com...
OKO operation in regular (run) mode • OKO x4A5 can enter Regular (run) mode with SITA application. In this mode the device operates regularly - it Pulse counting active takes pulses from the meter and transfers the data over mobile network to acquisition server periodically •...
6. MECHANICAL ASSEMBLY OKO X4A5 Meter type: HONEYWELL, ELSTER, INTERGAZ BK (Z4 and Z6 index type), Landis+Gyr Model 750, Model 1010 Insert the IC E015/IC L015 adapter on the gas meter. Secure the adapter with Fix OKO to the adapter.
Page 7
Firmly hold plastic body in one hand and apply lateral force to break off the plastic wing. OKO X4A5 Meter type: ELEKTROMETAL EM Fix and screw the IC K015 adapter to the gas meter. Seal the adapter with Fix OKO to the adapter.
Page 8
OKO X4A5 Meter type: GL i UG by APATOR METRIX Fix the IC M015 adapter on the gas meter. Secure the adapter with Fix OKO to the adapter. a blue seal. Screw and seal OKO with two grey IMR seals on both sides of Secure the whole set with the cover.
Page 9
Firmly hold plastic body in one hand and apply lateral force to break off the plastic wing. OKO X4A5 Gas meters embedded with pulse output Connect the wires to the IC U015 adapter as Fix OKO to the adapter and screw on both sides of the cover.
7. DEVICE COMMISSIONING WITH SITA Together with the mechanical installation of OKO x4A5, an action activating the device from seal-run mode and registering it in particular location must be performed*. The operation can be performed with SITA - an application dedicated for mobile devices (smartphone, tablet) with android OS that supports the operational procedures such as installation/uninstallation and configuration of IoT devices, as well as diagnostics, operations and services.
8. REPLICATED PULSE MEASUREMENT Thanks to the replicated pulse output, OKO x4A5 can be connected to 3rd party data acquisition system. The output is located in a dedicated IMR adapter and can provide meter pulse output connections to other meter pulse utilization devices, without interfering or disrupting the collection of data and having minimal effect on any power source within the AMR device.
9. SCOPE OF DATA The content of data packet sent by OKO x4A5 depends on configuration, while the frequency of data transfer is set in schedules. The exemplary information contained in the data packet sent by OKO is listed below.
