INSTRUCTION MANUAL
TOTALIZED PULSE INPUT MODULE
(Pi 8 points, 32 Bits, tension clamp terminal block)
BEFORE USE ....
Thank you for choosing us. Before use, please check con-
tents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact our sales office or representatives.
■ PACKAGE INCLUDES:
Totalized pulse input module .............................................(1)
■ MODEL NO.
Confirm Model No. marking on the product to be exactly
what you ordered.
■ INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product, including installation, connection and
basic maintenance procedures.
MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
MODEL
POINTS OF CAUTION
■ HOT SWAPPABLE MODULES
• Replacing the module does not affect other modules on
the same base. Thus, the module can be replaced while
the power is ON. However, replacing multiple modules
at once may greatly change live voltage levels. We highly
recommend to replace them one by one.
■ GENERAL PRECAUTIONS
• DO NOT set the switches on the module while the power
is supplied. The switches are used only for maintenance
without the power.
■ ENVIRONMENT
• Indoor use.
• When heavy dust or metal particles are present in the
air, install the unit inside proper housing with sufficient
ventilation.
• Do not install the unit where it is subjected to continuous
vibration. Do not subject the unit to physical impact.
• Environmental temperature must be within -10 to +55°C
(14 to 131°F) with relative humidity within 30 to 90% RH
in order to ensure adequate life span and operation.
■ WIRING
• Do not install cables close to noise sources (relay drive
cable, high frequency line, etc.).
• Do not bind these cables together with those in which
noises are present. Do not install them in the same duct.
■ AND ....
• The unit is designed to function as soon as power is sup-
plied, however, a warm up for 10 minutes is required for
satisfying complete performance described in the data
sheet.
INSTALLATION
Use the Installation Base (model: R3-BSx).
R3S-PA8
EM-8935 Rev.5 P. 1 / 5
Advertisement
Table of Contents
Related Manuals for MG R3S-PA8
Summary of Contents for MG R3S-PA8
- Page 1 10 minutes is required for satisfying complete performance described in the data sheet. INSTALLATION Use the Installation Base (model: R3-BSx). EM-8935 Rev.5 P. 1 / 5 MG CO., LTD. www.mgco.jp 5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN...
-
Page 2: Component Identification
1) Remove Network Module or its cables and interrupt com- ERR indicator: Bi-color (red/green) LED; munication with other devices. Red with excitation abnormality; 2) Turn ON the Count Reset SW (DIP SW3-1) on R3S-PA8 Green in normal operating conditions. module. Input status indicator: Red LED;... - Page 3 ■ COUNTER PRESET (Available in combination with R3-NE1, R3-NMx (Firmware version 2.00 or later, R3-NM3: Firmware version V1.00 or later), and R3S-PA8 displayed ‘SW3-4 RESET/PRESET’ on the right side) Setting SW3-4 ON and turning power on enable the function. Write the preset value to the Holding Resisters, which has same address as the Input Resisters.
-
Page 4: Terminal Connections
Pi 2 INTERNAL BUS B* Pi 3 Pi 4 INTERNAL POWER Pi 5 Pi 6 Pi 7 Pi 8 Count Reset *For dual redundant communication. EM-8935 Rev.5 P. 4 / 5 MG CO., LTD. www.mgco.jp 5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN... -
Page 5: Wiring Instructions
Be sure wire insulation is not inside the terminal. RESET Screw Driver Power wire EM-8935 Rev.5 P. 5 / 5 MG CO., LTD. www.mgco.jp 5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN...
