Hercules HCB72B-1 Owner's Manual & Safety Instructions

20v brushless 7-1/4″ rear-handle worm drive style circular saw
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual &
Safety Instructions
®
25b
Model
HCB72B-1
20V Brushless 7-1/4" Rear-Handle
Worm Drive Style Circular Saw
WARNING:
To prevent serious injury, User must read and understand
Owner's Manual. SAVE THIS MANUAL.
When unpacking, make sure that the product is intact and undamaged.
If any parts are missing or broken, please call 1‑800‑444‑3353
as soon as possible. Reference 59641.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCB72B-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Hercules HCB72B-1

Summary of Contents for Hercules HCB72B-1

  • Page 1 Owner’s Manual & Safety Instructions ® Model HCB72B-1 20V Brushless 7-1/4″ Rear-Handle Worm Drive Style Circular Saw WARNING: To prevent serious injury, User must read and understand Owner’s Manual. SAVE THIS MANUAL. When unpacking, make sure that the product is intact and undamaged.

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION GENERAL POWER TOOL SAFETY WARNINGS f. Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving parts. Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Loose clothes, jewelry or long hair can be caught in moving parts.
  • Page 3 b. Do not use the power tool if the switch b. Do not reach underneath the workpiece. does not turn it on and off. Any power The guard cannot protect you from tool that cannot be controlled with the switch the blade below the workpiece.
  • Page 4 b. When blade is binding, or when interrupting d. Always observe that the lower guard a cut for any reason, release the trigger is covering the blade before placing and hold the saw motionless in the material the saw down on bench or floor. An until the blade comes to a complete stop.

  • Page 5: Extension Cords

    k. Do not modify or attempt to repair the power 11. Vibration Safety tool or the battery pack except as indicated This tool vibrates during use. in the instructions for use and care. Repeated or long‑term exposure to vibration may cause temporary or permanent physical injury, The battery Charger gets hot during particularly to the hands, arms and shoulders.

  • Page 6: Specifications

    Symbology SPECIFICATIONS Battery Hercules 20V Li‑Ion Volts Charger Hercules 20V Li‑Ion No Load Speed :5800/min Direct Current Maximum Blade Diameter 7‑1/4" (Ø184mm) Amperes Arbor 5/8" Diamond 45°  :   1 -7/8" Maximum Depth of Cut 90°  : 2-1/2" n 0 xxxx/min.

  • Page 7: Functional Description

    Functional Description Auxiliary Handle Trigger Fixed Guard Lock Off Trigger Dust Port Main Handle Depth Lock Lever Lower Guard Lever Lower Guard Blade Spindle Lock Bevel Scale Bevel Lock Lever Blade Fence Wrench Lock Base Plate Knob Item 59641 For technical questions, please call 1-800-444-3353. Page 7...
  • Page 8 4. Install Blade with the directional arrow pointing the OPERATING INSTRUCTIONS same as the directional arrow on Lower Guard. 5. Place Outer Flange on Spindle, recessed side first Read the ENTIRE IMPORTANT SAFETY with wording on Flange facing out. Hold in Spindle INFORMATION section at the beginning of Lock while using the Blade Wrench to replace the this manual including all text under...

  • Page 9: Workpiece And Work Area Set Up

    4. Make sure Trigger is in the off‑position, Attaching Dust Port then attach the Battery Pack. 5. Firmly grip the Main Handle with one hand and Attach Dust Port to Fixed Guard using the Auxiliary Handle with the other hand. Bolt.

  • Page 10: Maintenance And Servicing

    Plunge Cut MAINTENANCE AND SERVICING 1. Disconnect battery pack before Procedures not specifically explained making any adjustments. in this manual must be performed 2. Mark a cutting line on the workpiece. only by a qualified technician. 3. Adjust cut depth so Blade barely clears the workpiece.

  • Page 11: Troubleshooting

    Troubleshooting Problem Possible Causes Likely Solutions Tool will 1. Battery Pack not properly 1. Remove Battery Pack, make sure there are no not start. connected. obstructions, reinsert the Battery Pack according to its shape (it should only fit one way), and press firmly until the Battery Pack locks in place.

  • Page 12: Year Limited Warranty

    5-YEAR LIMITED WARRANTY This Hercules tool is warranted to the original purchaser to be free from defects in materials and workmanship for a period of five (5) years beginning on the date of purchase. This warranty does not cover battery packs and battery chargers, which are covered under separate warranties.
