- Page 1 Make life full of hope USER GUIDE LiFePO4 Battery System for Households LiFePO4 Battery System for Households 358-010291-07...
- Page 2 Contents...
-
Page 3: About This Manual
LiFePO4 Battery System for Households LiFePO4 Battery System for Households 1 ABOUT THIS MANUAL 2. INTRODUCTION The battery system main using Solar power system for Family house. It also have a with to controller the 1.1 Purpose battery easily and protect our Household application timely. This manual describes the introduction, installation, operation and emergency situations of the battery bank. -
Page 4: Specifications
LiFePO4 Battery System for Households LiFePO4 Battery System for Households 2.3 Specifications Model LPBF48100-M Capacity 5kWh Battery Type LiFePO4 Nominal Voltage 51.2V Operating Voltage 48-57.6V Recommend Charge/Discharge Current[1] ≤50A Recommend Charge/Discharge Power[1] ≤2,500W Maximum Charge/Discharge Current(15s) 100A Battery terminal: 5B6A RS485 cable Maximum Charge/Discharge Power(15s) 5,000W... -
Page 5: Switch On/Off
LiFePO4 Battery System for Households LiFePO4 Battery System for Households Please follow below steps to implement battery connection: Assemble battery ring terminal based on recommended battery cable and terminal size. Note: if you need the battery wake-up when the grid back, connect the battery with grid use power adapter and communication line 1 shown in the package list. - Page 6 Eg: Rated voltage is "51.2V"; model is "5KWH", Eg: "52.0V" / "3.90KW" / "70%" refers to battery voltage. "01"is the countdown. power and SOC. Eg:"52.0V" / "C09"/"70%"arebatteryvoltage,fault Eg: "52.0V" / "50A" / "70%" refers to battery voltage. codeandSOCrespectively,andFaulticonconstant. current and SOC. current or watt Short press the switch button to switch watt and current...
-
Page 7: Emergency Situations
5. EMERGENCY SITUATIONS overtemperature Felicity cannot guarantee battery absolute safety. 5.1 Fire In case of fires, make sure that the following equipment is available near the system. • SCBA (self-contained breathing apparatus) and protective gear in compliance with the Directive on Personal Protective Equipment 89/686/EEC.
