Air Conditioning Control System
BM ADAPTER
MODEL
BACS-AP50
Instruction Book
The serial number and DP of the product can be found on the back cover of this manual. They are required to use
the product, so please keep this manual safe.
Proper installation is important for your safety and proper functioning of the units. Thoroughly read the following safety
precautions prior to installation.
Safety notes are marked with
may result when the instructions are not followed exactly as stated.
Before installing the controller, please read this Instruction Book carefully to ensure proper operation.
Retain this manual for future reference.
BACS-AP50
WARNING or
CAUTION, depending on the severity of possible consequences that
<ORIGINAL>
WT10951X01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BACS-AP50 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mitsubishi Electric BACS-AP50

Summary of Contents for Mitsubishi Electric BACS-AP50

  • Page 1 <ORIGINAL> Air Conditioning Control System BM ADAPTER MODEL BACS-AP50 Instruction Book BACS-AP50 The serial number and DP of the product can be found on the back cover of this manual. They are required to use the product, so please keep this manual safe.

  • Page 2: Manual Download

    Manual Download Manual Download Manual Download http://www.mitsubishielectric.com/ldg/ibim/ en Go to the above website to download manuals, select model name, then choose language. de Besuchen Sie die oben stehende Website, um Anleitungen herunterzuladen, wählen Sie den Modellnamen und dann die Sprache aus. Rendez-vous sur le site Web ci-dessus pour télécharger les manuels, sélectionnez le nom de modèle puis choisissez la langue.

  • Page 3: Table Of Contents

    1-3. Trademarks and registered trademarks..................... 6 1-4. Compliance with applicable laws and regulations..................6 1-5. Software details ............................7 2. Parts names ........................8 2-1. BACS-AP50 ............................... 8 3. Before using the controller....................12 4. Regular inspection ......................13 5. Initial settings........................14 5-1.

  • Page 4: Safety Precautions

    Safety precautions Safety precautions  Thoroughly read the following safety precautions prior to installation.  Observe these precautions carefully to ensure safety. indicates a hazardous situation which, if not avoided, could result WARNING in death or serious injury. indicates a hazardous situation which, if not avoided, could result CAUTION in minor or moderate injury.
  • Page 5 Safety precautions CAUTION To reduce the risk of injury from broken glass, do not apply excessive force to the glass parts. To reduce the risk of electric shock or malfunction, do not touch the touch panel, switches, or buttons with a pointed object. To reduce the risk of injury, electric shock, or malfunction, do not touch sharp edges of parts.

  • Page 6: Introduction

    When DP is 123456, the password will be Init123456.  In this manual, unless otherwise specified, "unit" means general air-conditioning equipment.  For matters not explained in this manual, refer to the Instruction Book (Detailed Operation) for BACS-AP50. 1-2. Related manuals ...

  • Page 7: Software Details

    1. Introduction 1-5. Software details Details of the open source integrated in the controller are available at the following URL: https://(IP address of the controller)/license/ WT10951X01...

  • Page 8: Parts Names

    2. Parts names 2. Parts names 2-1. BACS-AP50  BACS-AP50 (with the service cover) Item Function and description POWER Lit in green: The controller is receiving power. Unlit: The controller is not receiving power. ON/OFF Lit in green: On Blinking in green: Error...
  • Page 9 USB port (Type-C) (USB 3.1 Gen1) For updating the software Service cover To be removed when the AC power cable or M-NET transmission cable is connected to the controller. *2 For details, refer to the Instruction Book (Detailed Operation) for BACS-AP50. WT10951X01...
  • Page 10 2. Parts names  BACS-AP50 (without the service cover) Item Function and description (A) LAN1 LAN port for initial setting and updating the software. (B) LAN2 LAN port for BACnet connection. Connects to a building management system with a LAN cable via a switching HUB.
  • Page 11 2. Parts names Item Function and description (F) TB3 (M3.5) Terminal block for connecting the M-NET transmission cable. (G) TB1 (M3.5) Terminal block for connecting the AC power wires (L/L1, N/L2). (H) Ground (M4) Terminal for connecting the protective ground wire. CN10 Not available Serial number label...

  • Page 12: Before Using The Controller

    3. Before using the controller 3. Before using the controller  The controller must not be installed by the user. (Proper safety level and functionality may not be ensured.)  The installation of the controller must be performed by the dealer (or the contractor) in accordance with the applicable laws, regulations, and certifications.

  • Page 13: Regular Inspection

    4. Regular inspection 4. Regular inspection Product components deteriorate over time and can pose safety hazards. Regularly conduct safety inspections to use the product safely and in good condition. WT10951X01...

  • Page 14: Initial Settings

    [2] Installing the BACnet Setting Tool [3] Importing the root CA certificate [4] Setting the IP address of the computer [5] Updating the software of the BACS-AP50 [6] Clock setting of the BACS-AP50 Note  This manual explains the following. For details, refer to the Instruction Book (Detailed Operation) for BACS- AP50.

  • Page 15: Setting The Bacnet Setting Tool

     Is the cable between the PC and BACS-AP50 (LAN1) connected correctly?  Is the IP address of the PC set to an IP address of the same network as LAN1 of the BACS-AP50?  Does the destination IP address setting of the BACnet Setting Tool match the IP address of LAN1 of the BACS-...

  • Page 16: Existing The Bacnet Setting Tool

    5. Initial settings 5-2-2. Existing the BACnet Setting Tool To exit the BACnet Setting Tool, click at the top right of the BACnet Setting Tool screen or select [Exit] from [File] in the menu bar. WT10951X01...

  • Page 17: Menus Of The Bacnet Setting Tool

    5. Initial settings 5-3. Menus of the BACnet Setting Tool 5-3-1. Screen configuration The screen configuration of the BACnet Setting Tool is shown below. To switch the settings screens, select menus on the menu bar, main tabs, or sub tabs. Menu bar Main tab Sub tab...

  • Page 18: Menu Bar Configuration

    Saves BACnet Setting Tool settings data to a specific folder Save Settings As... with a specific file name. Exits the BACnet Setting Tool. Exit Sets the LAN1 IP address for the BACS-AP50 to BACS-AP50 Property communicate with. Acquires the settings data from the BACS-AP50.

  • Page 19: Setting Tab Configuration

    Object event notification (Event_Enable, Notify_Type). Set the notification destination at reset. Other Used when using the Settings Tool to cancel a BACS-AP50 ForcedOff Reset emergency stop originating from the central monitoring device (BACnet). Settings not required. WT10951X01...

  • Page 20: Group Settings

    *2 The maximum number of remote controllers and system controllers that can be configured into a group is four, not including the BACS-AP50 unit. No more than two remote controllers can be included in each group. *3 The number of units connected to M-NET (one system) must satisfy the following restrictions.
  • Page 21 5. Initial settings (1) Configuring the group setting for the units Double-click the Unit address field of the group to be set to display the [Select Unit Address] popup window. Select the units to be included in each group on this window. (a) Unit selection Click a unit address to select.

  • Page 22: Oc Settings

    Light gray: System controllers that do not belong to any group Lime green: System controllers that are currently selected Dark gray: BACS-AP50 address 5-4-2. OC settings To use objects related to outdoor units (COP (AI_51zz01), etc.), enter their addresses in the OC settings.

  • Page 23: Lossnay Settings

    5. Initial settings (a) Outdoor unit selection Click an outdoor unit address to select. Click the selected address to deselect. The unit selection status is indicated in different colors. Light gray indicates the units that are available for selection, and lime green indicates the units that are currently selected.
  • Page 24 5. Initial settings (1) Configuring the interlock settings for the LOSSNAY units Double-click the LOSSNAY address field to display the [Select LOSSNAY Address] popup window. (a) Interlocking LOSSNAY address selection Click the address of the LOSSNAY unit to select. Click the selected address to deselect. Light gray indicates the units that are available for selection, and lime green indicates the units that are currently selected.

  • Page 25: Checking For Proper Installation And Conducting Commissioning

    (1) Start and stop the indoor units from the BACS-AP50, and make sure the indoor units operate accordingly. (2) Start and stop the indoor units from the local remote controller, and make sure the correct operation statuses appear on the BACS-AP50.

  • Page 26: Specifications

    7. Specifications 7. Specifications ■ BACS-AP50 Item Specifications Power supply Rating 100-240 VAC ±10%, 50/60 Hz, single phase Power consumption 15 W LAN1, LAN2 100BASE-TX Ambient Operating -10°C to +55°C (+14°F to +131°F) conditions temperature range Storage temperature -20°C to +60°C (-4°F to +140°F)

  • Page 27: Before Requesting Repairs

    8. Before requesting repairs 8. Before requesting repairs If the problem cannot be solved by referring to the "Before requesting repairs" chapter of the Instruction Book (this manual), stop the operation, and turn off the molded-case circuit breaker. Contact the dealer (contractor, service provider) with the information on the nature of the problem.
  • Page 28 Please be sure to put the contact address/telephone number on this manual before handing it to the customer. KF79C984G01 HEAD OFFICE: TOKYO BLDG., 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN MANUFACTURER: MITSUBISHI ELECTRIC CORPORATION Air-conditioning & Refrigeration Systems Works 5-66, Tebira 6 Chome, Wakayama-city, 640-8686, Japan WT10951X01...
