LOIRE 800 & LOIRE 1000 INBUILT
ZERO CLEARANCE BOX SUPPLEMENT INSTRUCTIONS
MUST BE IN CONJUNCTION WITH THE INSTALLATION MANUAL FOR THE LOIRE 800 AND LOIRE
1000 MODELS.
TESTED IN ACCORDANCE WITH AS/NZS 4013:2014 and AS/NZS 2918.
Please read through this manual thoroughly before installing and starting your free-standing
appliance.
Keep these instructions for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the LOIRE 800 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lacunza LOIRE 800

  • Page 1 LOIRE 800 & LOIRE 1000 INBUILT ZERO CLEARANCE BOX SUPPLEMENT INSTRUCTIONS MUST BE IN CONJUNCTION WITH THE INSTALLATION MANUAL FOR THE LOIRE 800 AND LOIRE 1000 MODELS. TESTED IN ACCORDANCE WITH AS/NZS 4013:2014 and AS/NZS 2918. Please read through this manual thoroughly before installing and starting your free-standing appliance.
  • Page 2 Lacunza Loire 800/1000 Zero Clearance Box Assembly Instructions March 06, 2025 Zero Clearance Parts List Check all the parts are supplied before beginning the assembly.
  • Page 3 Lacunza Loire 800/1000 Zero Clearance Box Assembly Instructions March 06, 2025...
  • Page 4 Lacunza Loire 800/1000 Zero Clearance Box Assembly Instructions March 06, 2025 Assembly Instructions Step 1: Assemble the Stand 1.1 Start by making the four side frames for the stand first. For each end, you will use 2 x Stand Horizontal Short Brackets and 2 x Stand Vertical Brackets. Lay them out as seen in the image below.
  • Page 5 Lacunza Loire 800/1000 Zero Clearance Box Assembly Instructions March 06, 2025 1.4 Now you can join the two Stand Sides with the Stand Horizontal Long Brackets. You can line them up with the Long Brackets go on the outside of each corner. Start by lining up one side first, then move to the other side.
  • Page 6 Lacunza Loire 800/1000 Zero Clearance Box Assembly Instructions March 06, 2025 Step 2: Attaching the Stand to the Zero Box 2.1 Place the Bottom Panel, on top of the completed Stand. The front of the bottom panel should be flat in line with the front stand face.
  • Page 7 Lacunza Loire 800/1000 Zero Clearance Box Assembly Instructions March 06, 2025 2.4 You can then add the 3 x Bottom Brackets to the fixed Bottom Panel. Line them up with each hole on the Bottom Panel, and then use 4 x Self Tapping Screws on each Bottom Bracket (A total of 12 x Self Tapping Screws).
  • Page 8 Lacunza Loire 800/1000 Zero Clearance Box Assembly Instructions March 06, 2025 2.7 Slide the Back Panel into the inside of the Side Panels and Bottom Panel. 2.8 Line up the holes and use 9 x Self Tapping Screws. Use the circle cut-outs in the Back Panel to pull the sheet towards you, which should help when you are inserting the Self Tapping Screws.
  • Page 9 5 x Self Tapping Screws for the sides (A total of 10 x Self Tapping Screws) and 3 x Self Tapping Screws). If you are installing for the Loire 800, then go to Step 4 before continuing. Once the Top Panel is on, tighten all the screws.
  • Page 10 Lacunza Loire 800/1000 Zero Clearance Box Assembly Instructions March 06, 2025 Step 3: Fitting the Flue 3.1 The flue should be raised off the top of the Zero Clearance Box, using the 2 x Flue Brackets. The Flue Brackets are fixed to the 152mm Flue (Inner Casing), and the upper folded u-shaped hook is fixed to the 203mm Flue (Outer Casing).
  • Page 11 4.1 If you are installing the Loire 1000, then you are completed with assembly. If you are installing for the Loire 800, you will need to assemble the 2 x Side Fill-Ins before tightening the Top and Side Panels. There are four slots for each Side Fill-In, at the top and bottom.
  • Page 12 Lacunza Loire 800/1000 Zero Clearance Box Assembly Instructions March 06, 2025 Completed Zero Clearance Box with Stand for Lacunza Loire 800/1000...
  • Page 13 Lacunza Loire 800/1000 Zero Clearance Box Assembly Instructions March 06, 2025 Import Safety and Clearance Information Loire 1000 1. Venting in the ceiling of the enclosure around the outer triple flue skin must be a minimum of 285,705mm2, evenly spaced around the outer casing.
  • Page 14 Lacunza Loire 800/1000 Zero Clearance Box Assembly Instructions March 06, 2025 Loire 800 1. Venting in the ceiling of the enclosure around the outer triple flue skin must be a minimum of 305,723mm2, evenly spaced around the outer casing. 2. Timber framing in the ceiling cavity must be a minimum of 1220mm above the zero box and must not restrict the 305,723mm2 air flow around the flue casing 3.
  • Page 15: Clearance Diagrams

    Clearance Diagrams Loire 800 The Lacunza Loire 800 inbuilt and Zero Clearance Box installed with a 6” triple skin flue kit was tested in one position in a manner conforming to joint Australian/New Zealand Standard 2918:2018. A minimum 555mm deep x 1260mm wide x 6mm thick floor protector (compressed board) should be used under the appliance base when installing the appliance (see joint AS/NZS 2918:2018 3.3.2).
  • Page 16 March 06, 2025 Loire 1000 The Lacunza Loire 1000 inbuilt and Zero Clearance Box installed with a Flo-met SG-FLKIT 200-FS-B Flue Kit was tested in one position in a manner conforming to joint Australian/New Zealand Standard 2918:2018,. A minimum 555mm deep x 1260mm wide x 6mm thick floor protector (compressed board) should be used under the appliance base when installing the appliance (see joint AS/NZS 2918:2018 3.3.2).
