830-629-2900 / 800-729-3839 / Fax 800-653-3839 / Text photos only: 830-481-6433 / INTERNET: www.detex.com
ELECTRICAL INSTRUCTIONS FOR ADVANTEX EBxW MODELS
Rim, SVR
EBxW - Weatherized
101379
104600
101559
104690
Device parts breakdown view & part numbers...................
Mortise cylinder installation, Switch options.......................
Alarm operations................................................................
Troubleshooting..................................................................
Optional accessories..........................................................
Should you have a Question/Problem with your Detex device please call Detex Technical Support from the job site at
1-800-729-3839 and choose option 2 on our menu. Please do not return the product to the distributor.
For WARRANTY information,
scan code below or
go to www.detex.com/warranty
Detex Corporation, 302 Detex Drive, New Braunfels, Texas 78130-3045
R
Table of Contents
Owner's Copy
104904
104904 May 13, 2025
Page
2
3
4
5
6
For device installation videos,
scan code below or
go to www.detex.com/videos
C
Advertisement
Related Manuals for Detex ADVANTEX EB W Series
Summary of Contents for Detex ADVANTEX EB W Series
- Page 1 Troubleshooting..............Optional accessories............Should you have a Question/Problem with your Detex device please call Detex Technical Support from the job site at 1-800-729-3839 and choose option 2 on our menu. Please do not return the product to the distributor. For device installation videos,...
- Page 2 ITEM PART # DESCRIPTION 105500-204 S&R ADVANTEX CENTERCASE PUSHPAD, 10 x STDI-CD-W 101642-9 ENDCAP, EC1, STAINLESS STEEL 102095-9 ENDCAP, EC1, STAINLESS STEEL for FLEX CONDUIT 104304-9 ENDCAP, EC2, STAINLESS STEEL 104612-1 ENDCAP, EC2, ALUMINUM 104317-9 ENDCAP, EC2, STAINLESS STEEL, for FLEX CONDUIT 104686-1 ENDCAP, EC2, ALUMINUM, for FLEX CONDUIT 101093-1W...
-
Page 3: Switch Options
MORTISE CYLINDER INSTALLATION .313" Cylinder nut socket CD (Cylinder Dogging) Installation p/n 103779 (sold separately) .715" Mortise Cylinder Mortise Cylinder with standard Yale cam required Endcap Dogging Spacers Assembly Fillerplate Endcap Mounting Bracket Installation steps: a. Remove endcap and endcap mounting bracket. b. -
Page 4: Alarm Operations
Protect wires to avoid pinching Battery connector (standard) Table 3 Remote Signal - Output Remote Bypass - Input (dry) Remote signal (optional) Common Violet N.O. contact Brown Remote bypass Normally Open Violet N.O. contact Yellow Normally Closed ---- ---- Gray-Green Contacts rated at 1.0A @ 30VDC or 0.5A @ 125VAC ALARM OPERATIONS Refer to switch options pages... - Page 5 ACTIVATE/DEACTIVATE SILENT ALARM: 1. Remove all power. 2. Turn the device on with the key. 3. Maintain a short between the violet bypass wires. 4. Push and maintain alarm trigger switch and apply power. 5. Unit will chirp twice when silent arming is turned 'ON', and chirps once when silent arming is turned 'OFF'.
- Page 6 Optional Accessories EC1 endcap EC2 endcap Advantex Flex Conduit Kit Catalog No: FCA-[Specify FC3EC1W-630 FC3EC2W-630 Finish] FC10EC1W-630 FC10EC2W-630 FC3W Electrical Wires Not FC10W Supplied Flex Conduit Kit Catalog No: FC3W or FC10W Waterproof Connectors Provided Tamper Kit Security Kit Rim, Catalog No: SSK1 SVR, Catalog No: SSK2 Mortise, Catalog No: SSK3 Security Pin TORX Bits provided...
