Sharp MX-3501N Service Manual

Sharp MX-3501N Service Manual

Digital full color multifunctional system duplex single pass feeder
Hide thumbs Also See for MX-3501N:
Table of Contents

Advertisement

Quick Links

Download this manual
More Service Manuals at www.service-manual.net
[1]
PRODUCT OUTLINE . . . . . . . . . . . . . . . . .1-1
[2]
SPECIFICATIONS . . . . . . . . . . . . . . . . . . .2-1
[3]
functions . . . . . . . . . . . . . . . . . . . . . . . .3-1
[4]
1. Document size detection . . . . . . . . . . .4-1
2. Timing chart . . . . . . . . . . . . . . . . . . . . .4-1
[5]
1. Exterior section . . . . . . . . . . . . . . . . . . .5-1
2. Paper feed section . . . . . . . . . . . . . . . .5-2
3. Upper transport section . . . . . . . . . . . .5-6
4. Lower transport section . . . . . . . . . . . .5-8
5. Optical section . . . . . . . . . . . . . . . . . .5-12
6. Paper exit section . . . . . . . . . . . . . . . .5-16
7. Drive section . . . . . . . . . . . . . . . . . . . .5-17
8. Others . . . . . . . . . . . . . . . . . . . . . . . . .5-19
[6]
1. Maintenance system table . . . . . . . . . .6-1
[7]
1. Levelness adjustment . . . . . . . . . . . . . .7-1
(front surface mode) . . . . . . . . . . . . . . .7-1
(back surface mode) . . . . . . . . . . . . . . .7-2
(front surface mode) . . . . . . . . . . . . . . .7-3
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with
specified ones for maintaining the safety and performance of the set.
SERVICE MANUAL
DIGITAL FULL COLOR
MULTIFUNCTIONAL SYSTEM
DUPLEX SINGLE PASS FEEDER
(DSPF)
MODEL
CONTENTS
[8]
[9]
WWW.SERVICE-MANUAL.NET
SHARP CORPORATION
CODE: 00ZMX3501/S1E
MX-3501N
MX-4501N
(back surface mode) . . . . . . . . . . . . . . 7-3
(front surface mode) . . . . . . . . . . . . . . 7-4
(back surface mode) . . . . . . . . . . . . . . 7-4
adjustment . . . . . . . . . . . . . . . . . . . . . . 7-6
feed tray adjustment . . . . . . . . . . . . . . 7-7
15. Shading adjustment . . . . . . . . . . . . . . . 7-9
(CCD calibration) . . . . . . . . . . . . . . . . 7-10
SELF DIAG AND TROUBLE CODE
diagram . . . . . . . . . . . . . . . . . . . . . . . . 9-1
2. Block diagram . . . . . . . . . . . . . . . . . . . 9-4
3. Actual wiring chart . . . . . . . . . . . . . . . . 9-5
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX-3501N and is the answer not in the manual?

Questions and answers

Related Manuals for Sharp MX-3501N

Summary of Contents for Sharp MX-3501N

  • Page 1: Table Of Contents

    SERVICE MANUAL CODE: 00ZMX3501/S1E DIGITAL FULL COLOR MULTIFUNCTIONAL SYSTEM DUPLEX SINGLE PASS FEEDER (DSPF) MX-3501N MX-4501N MODEL CONTENTS PRODUCT OUTLINE ....1-1 5. Image focus adjustment (back surface mode) .
