Montageanleitung | Mounting instructions
DisplayLift
Wandmontage | Wall installation
Art.-Nr. | Ref.No. 4013000 300
Montage auf Ständer | Mounting on stand
Art.-Nr. | Ref.No. 4013000 301 + 4013 000 303
4013000301
4013 000301
mit Stellfüßen /
with levelling feet
4013 000303
www.kindermann.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kindermann DisplayLift
Summary of Contents for Kindermann DisplayLift
- Page 1 4013 000301 mit Stellfüßen / with levelling feet 4013 000303 Montageanleitung | Mounting instructions DisplayLift Wandmontage | Wall installation Art.-Nr. | Ref.No. 4013000 300 Montage auf Ständer | Mounting on stand www.kindermann.com Art.-Nr. | Ref.No. 4013000 301 + 4013 000 303...
- Page 2 1. Basic safety instructions ........................................3 2. Mounting instructions wall installation (4013 000 300) ............................4 2.1 Scope of delivery ........................................5 2.2 Required tools ...........................................5 2.3 Assembling ......................................... 6 - 9 3. Mounting instructions mounting on stand (4013 000301 + 4013000303) ...................... 10 3.1 Scope of delivery ........................................11 3.2 Required tools ........................................11 3.3 Assembling ........................................12 - 16 4. Dimensions ..........................................17 - 19 5. Specifications ............................................. 20 DisplayLift / DisplayLift...
-
Page 3: Safety Instructions
• Due to the shape of the base plate or the roller stand, there is a risk of tripping during operation or installation. • Guide the cables to the DisplayLift in a way that they do not pose a risk of tripping and cannot be damaged. -
Page 4: Mounting Instructions
2. Montageanleitung – Mounting instructions Wandmontage / Wall installation Art.-Nr. / Ref.No. 4013000300 DisplayLift / DisplayLift... -
Page 5: Scope Of Delivery
2 x M4x8 8 x M8x35- gewindeformend 2 x M4x8mm 2 x M4x10mm 4 x M6x16mm rmontiert 4 x M8x16 ndeformend 8 x M8x35- thread-forming ssembled ad-forming 2.2 Benötigtes Werkzeug – Required tools 3, 5, 6 TX 20 DisplayLift / DisplayLift... -
Page 6: Montage
4 x 8,4mm 4 x M8x16 8 x M8x25- gewindeformend 2 x M10x20 12 x 12 x 2 x M4x8 2 x M4x10 4 x M8x16 8 x M8x25- gewindeformend 8 x M8x25- thread-forming M10x20 8 x M8x25- thread-forming DisplayLift / DisplayLift... - Page 7 2 x M4x8 4 x M8x16 8 x M8x25- gewindeformend 12 x 12 x 2 x M10x20 4 x M8x35mm 8 x M8x25- thread-forming (gewindeformend/ thread-forming) 2 x M4x10mm TX 20 2 x M4x10 2 x M4x8 8x16 DisplayLift / DisplayLift...
- Page 8 8 x M8x25- thread-forming 2 x M4x8mm 2 x M4x8 x M4x10 2 x M4x10 2 x M4x8 2 x 4,3mm 4 x M8x16 8 x M8x25- gewindeformend 2 x M10x20 12 x 12 x 8 x M8x25- thread-forming DisplayLift / DisplayLift...
- Page 9 DisplayLift / DisplayLift...
- Page 10 3. Montageanleitung – Mounting instructions Montage auf Ständer / Mounting on stand Art.-Nr. / Ref.No. 4013000301 + 4013000303 DisplayLift / DisplayLift...
- Page 11 2 x M10x20 8 x M8x35- thread-forming (gewindeformend/ 8 x M8x25- thread-forming montiert M8x25- thread-forming 8 x M8x25- thread-forming 8 x M8x25- thread-forming thread-forming) ssembled 3.2 Benötigtes Werkzeug – Required tools 3, 5, 6 TX 20 13, 17 DisplayLift / DisplayLift...
- Page 12 3.3 Montage – Assembling x M4x8 8 x M6x14 8 x M6x16mm 8 x 8,4mm 8 x M8x25- gewindef 2 x M10x20 12 x 8 x M8x25- thread-f 4 x M8 12 x DisplayLift / DisplayLift...
- Page 13 Optional: Montage der Stellfüße (4013000303) – Optional: Mounting of the levelling feet (4013000303) 16 x M4x6mm 4 x Fuß - Foot TX 20 4 x Fuß - Foot 2 x M4x8 2 x M4x10 8x16 DisplayLift / DisplayLift...
- Page 14 12 x 12 x 8 x M8x25- thread-forming 2 x M4x8 2 x M4x10 4 x M8x16 8 x M8x25- gewindeformend 2 x M10x20 12 x 12 x 4 x M8x35mm 8 x M8x25- thread-forming (gewindeformend/ thread-forming) DisplayLift / DisplayLift...
- Page 15 12 x 12 x 2 x M10x20 2 x M10x20 2 x M4x10 2 x M4x8 4 x M8x16 8 x M8x25- gewindeformend 2 x M10x20 8 x M8x25- thread-forming 8 x M8x25- thread-forming 8 x M8x25- thread-forming DisplayLift / DisplayLift...
- Page 16 M4x10 2 x M4x8 2 x M4x8mm 2 x M4x8 2 x M4x10 4 x M8x16 8 x M8x25- gewindeformend 2 x M10x20 2 x 4,3mm 12 x 12 x 8 x M8x25- thread-forming DisplayLift / DisplayLift...
- Page 17 5. Abmessungen – Dimensions Art.-Nr. / Ref.No. 4013000300 226 mm 870 mm 300 mm DisplayLift / DisplayLift...
- Page 18 Art.-Nr. / Ref.No. 4013000301 870 mm 236 mm 797 mm 1123 mm DisplayLift / DisplayLift...
- Page 19 Art.-Nr. / Ref.No. 4013000301 + 4013000303 870 mm 236 mm 797 mm Höhenverstellbar Height adjustable 23-31 mm 1123 mm DisplayLift / DisplayLift...
-
Page 20: Spezifikationen
Transport case Hubsäule in Karton 2: 90 x 25 x 19 cm: ca. 14 kg Lifting pillar in Box 2: 90 x 25 x 19 cm: approx. 14 kg Kindermann GmbH Mainparkring 3 | 97246 Eibelstadt | Germany E-Mail: info@kindermann.de Subject to alterations | 4013000300 / 4013000301 / 4013000303 | 842 245 | DE/EN | 05.2025...
