  • Page 1 Installation Guide Size 8 and 9 Incomer Free Standing factory engineered incomer with switch disconnect Part Number: 0471-0141-01 Issue: 1 www.controltechniques.com...
  • Page 2: General Information

    This manual contains specific safety warnings. It is essential that the warnings are observed and the information considered when working with or designing a system using the Unidrive SP Size 8 and 9 Incomer. This manual should be read in conjunction with the Unidrive SP User Guide.
  • Page 3: Table Of Contents

    Incomer input busbar kit 9500-0096 .......13 AC power supply cable connections - bottom entry ............13 3.4.1 Incomer input busbar kits connections 9500-0094 and 9500-0095 ........14 Cable sizes ............15 Unidrive SP Size 8 and 9 Incomer Installation Guide Issue Number: 1 www.controltechniques.com...
  • Page 4: Introduction

    Introduction The factory engineered incomer is intended to complement Unidrive SP size 8 and 9 Free Standing drives. Factory engineered incomers are supplied with a disconnect switch with input power cable entry possible from the top (all factory engineered incomers) or bottom (excluding incomers IN86X1, IN86X2, IN86X3, IN86X4 and IN96X1).
  • Page 5: Mechanical Installation

    Figure 2-2 Removing the size 8 and 9 Free Standing factory dimensions engineered incomer terminal covers 400mm 630mm (15.75in) (24.80in) ∅ 20mm (0.79in) 315mm (12.40in) 404.6mm (15.93in) Unidrive SP Size 8 and 9 Incomer Installation Guide Issue Number: 1 www.controltechniques.com...
  • Page 6 Figure 2-3 Features of the size 8 and 9 Free Standing factory engineered incomer Front view Rear view Top entry supply cable option Input power connections Switch disconnect Ground terminals Link busbars Baying busbar terminals Bottom entry supply cable option Unidrive SP Size 8 and 9 Incomer Installation Guide www.controltechniques.com Issue Number: 1...
  • Page 7: Baying Free Standing Drive And Incomer

    Disconnect ground cable connections from the front, rear and side panels by removing the M6 nuts and star washers. Figure 2-4 Preparation for baying size 8 and 9 Free Standing factory engineered incomer to a Free Standing drive - removal of panels Unidrive SP Size 8 and 9 Incomer Installation Guide Issue Number: 1...
  • Page 8: Side Panels

    When busbars are assembled, ensure that a 15mm (0.59 in) gap exists between busbars of opposite polarity. WARNING To prevent fire, electrical connections must be fastened to the torque settings stated in these instructions. WARNING Unidrive SP Size 8 and 9 Incomer Installation Guide www.controltechniques.com Issue Number: 1...
  • Page 9 5. Fit the input parallel busbar with M8 x 20 screws (Torque 17Nm [12.50 Ib ft]) and M6 x 30 insulating spacer M6 x 12 screws (Torque 12Nm [8.85 Ib ft]). 6. Fit the input parallel busbar with M8 x 20 screws (Torque 17Nm [12.50 Ib ft]). Unidrive SP Size 8 and 9 Incomer Installation Guide Issue Number: 1...
  • Page 10: Electrical Installation - Power Connections

    Electrical installation - power connections AC Supply specification The Unidrive SP size 8 and 9 Free Standing factory engineered incomer must not be used in a circuit capable of delivering more than 30kA. Cable entry options Power cable entry is possible from the top (all factory engineered incomers) or the bottom of the incomer (excluding incomers IN86X1, IN86X2, IN86X3, IN86X4 and IN96X1).
  • Page 11: Incomer Input Busbar Kits 9500-0091 And 9500-0093

    To prevent fire, electrical connections must be fastened to the torque settings stated in these instructions. WARNING 1. M6 x 16 screw 2. M6 isolating spacer 3. L2 busbar 4. L1 and L3 busbar Unidrive SP Size 8 and 9 Incomer Installation Guide Issue Number: 1 www.controltechniques.com...
  • Page 12: Incomer Input Busbar Kit 9500-0092

    4. L2 busbar 7. Busbar support bracket (left) 2. M6 isolating spacer 5. L3 busbar 8. Busbar support bracket (right) 3. L1 busbar 6. M8 x 20 TORX screw Unidrive SP Size 8 and 9 Incomer Installation Guide www.controltechniques.com Issue Number: 1...
  • Page 13: Incomer Input Busbar Kit 9500-0096

    1. Fit the L2 busbar over the switch disconnect terminal stud and secure to the isolating spacers using 2 x (M6 x 16) screws (torque 12Nm [8.85 Ib ft]). Unidrive SP Size 8 and 9 Incomer Installation Guide Issue Number: 1 www.controltechniques.com...
  • Page 14: Incomer Input Busbar Kits Connections 9500-0094 And 9500-0095

    4. L1 & L3 busbar screws (torque 12Nm [8.85 lb ft]). 5. Insulation sheet 6. Switch disconnect mounting plate NOTE Insulation sheets are delivered flat. Images show approximate appearance when assembled. Unidrive SP Size 8 and 9 Incomer Installation Guide www.controltechniques.com Issue Number: 1...
  • Page 15: Cable Sizes

    6 x M10 nuts and washers (minimum torque 50Nm [36.87 Ib ft]). 5. Secure supply cables to input busbars using M10 screws and nuts (torque 50Nm [36.87 lb ft]). Unidrive SP Size 8 and 9 Incomer Installation Guide Issue Number: 1 www.controltechniques.com...
  • Page 16 0471-0141-01...
