  • Page 1 USER MANUAL Facility Status Display Installation and Operation Guide...
  • Page 2 Copeland 1065 Big Shanty Road NW, Suite 100 Kennesaw, GA 30144 USA 770-425-2724 • 1-800-829-2724 www.copeland.com Email: ColdChain.TechnicalServices@copeland.com...

  • Page 3: Table Of Contents

    7.4.2 Open Network Layout ......................................18 7.5 Software Setup....................................19 7.6 Troubleshooting....................................20 8 E2 ALARM ANNUNCIATOR SETUP ......................21 9 SOFTWARE UPDATES............................ 21 10 SPECIFICATIONS ............................22 11 FSD RIBBON CABLE INSTALLATION...................... 22 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 4: Introduction

    E2 via Ethernet connectivity (minimum E2 firmware revision 2.65F01). Figure 1-1 - Facility Status Display (P/N 850-5100) The FSD has a touch screen color display for quick navigation and can be mounted in a separate, remote location from the E2 controller, which enables alarms and other relevant store information to be viewed from where it is most convenient for the user.

  • Page 5: Installation

    (two turns), near the Ethernet port (LAN) on the back of the display, and close the ferrite (Figure 2-2) around the Ethernet cable. Figure 2-2 - Ferrite Installation on Ethernet Cable 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 6: Alarm Relays

    Once this hole is cut, mount the unit as desired (Figure 2-4), and position the enclosure so that the four support tabs are flush against the outside lip of the opening in the wall. 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.
  • Page 7 Figure 2-4 - Mounting The Power Supply Box leave ½” clearance each side for face plate 1/2” Open Side of 8.0” Power Supply Box 1/2” 1/2” 1/2” 9.0” Figure 2-5 - Leave 1/2” For Face Plate Mounting 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 8: Set Up Fsd And E2 Communication

    A loader screen will appear. Touch Exit Loader at the top right of the screen. The desktop screen will appear. Select Start > Settings > Network and Dial-up Connections. Double-click the icon labeled SMSC91181. 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 9: Step 3: Set The E2 Ip Address In Fsd

    IP Address, contact your IT administrator for the Hostname.) Figure 3-4 - Click Figure 3-6 - Second Boot Loader/Startup Screen 3. Touch Apply. 4. Reboot the unit by cycling power. 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 10: Alarm Overview

    If communications are lost between the E2 and the FSD, an alarm will generate. NOTE The delay for the alarm will be consistent with the offline delays used in the E2 for board offline alarming. 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 11: Fsd Screen Navigation

    If alarms have been generated, the UP arrow will scroll up to the previous alarm. Touching the DOWN arrow will scroll down to the next alarm in the list. Figure 5-1 - Home or Main Screen 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 12: Alarm List Screen

    FSD Data Point screen. Figure 5-3 - Advisory Detail Screen • Current alarm number with the total number of alarms in the alarm list • Alarm summary for single alarm 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 13: Data Points Detail Screen

    Figure 5-9 - No Pointer Is Defined Message Figure 5-6 - Detailed Information if the Data Point Failed Figure 5-7 - Detailed Information if Data Point is in Override 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 14: Fsd Configuration Screen

    Show Reset Advisories • Display Asset/Alarm • Show Notices • Filter Advisories • Sort Data Points • Audible Alarm settings • Set snooze delay in minutes • Set minimum alarm priority 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 15: Communications Tab

    FSD. Enable this box to show Notices in the alarm list, uncheck to filter out. Figure 5-14 - Communications Screen - Set E2 Parameters 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 16: General Tab

    2. Select the General tab and touch the Exit Application configuration screen and go to the Boot Loader or Start up button (Figure 5-17). screen. Figure 5-17 - General FSD Information Screen Figure 5-15 - General FSD Information Screen 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.
  • Page 17 6. To save your settings, touch and drag the Display Properties window to the left until you see OK in the upper right corner. Touch OK to save and return to the desktop screen. Figure 5-19 - Desktop Screen 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 18: E2 Data Point Setup For Fsd

    For E2 firmware prior to revision 2.69F01, data points can be selected from a remote E2 by connecting the data points to Global Data. Figure 6-2 - Enter the Title Data Point Pointer and String Values 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.
  • Page 19 After entering the data point, enter a unique name in the Data Name field on this screen. If no name is assigned, the data point will be displayed in the default Controller:Application:Property format. 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 20: E2 Ethernet Peer Communications

    Clamp and rated: 10V and 5V 10-Base-T/100-Base-TX Hub Room Temperature (0 to 50 C) P/N 570-0100 10-Base-T/100-Base-TX Hub Extended Temperature (-40 to 65 C) P/N 570-0200 NOTE An external power supply may be needed. 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 21: Software Specifications

    E2 that UltraSite communicates with the other controllers (defined as the “non-gateway” E2s and external entities such as UltraSite). 7.4.1 Closed Network Layout 7.4.2 Open Network Layout Figure 7-1 - Closed Network Layout Figure 7-2 - Open Network Layout 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 22: Software Setup

    Ethernet Subnet in order to communicate box-to-box. Figure 7-3 - TCPIP Setup Screen Tab over to the Peer Netwrk tab: Figure 7-4 - Peer Network Tab - Set Network Type 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 23: Troubleshooting

    All controllers that you would like to appear in this group must all have the same group name and must be using the same network type. Troubleshooting Network troubleshooting is outside the scope of this section (Section 7, E2 Ethernet Peer Communications). Consult your IT Network Administrator for any additional information needed. 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 24: E2 Alarm Annunciator Setup

    When the E2 is set up as an Alarm Annunciator, the Home screen on the E2 becomes the Alarm Log. Software Updates Updates to FSD application functionality will automatically be synched with the update of E2’s firmware. Any software the device runs will be retrieved from the configured E2. 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.

  • Page 25: Specifications

    Once the top has been separated from the back of the enclosure, check the ribbon cable for proper installation and reposition if necessary. Replace the mounting plate onto the enclosure and reattach using the four screws. Cycle power to the unit. 026-1400 R6 Facility Status Display (FSD) ©2024 Copeland LP.
  • Page 26 The contents of this publication are presented for informational purposes only and they are not to be construed as warranties or guarantees, express or implied, regarding the products or services described herein or their use or applicability. Copeland reserves the right to modify the designs or specifications of such products at any time without notice.
