Page 1 of 10
Air Technologies Inc.
CSA600 iSeries
Premium Turbine Dust Collectors & Odor
Control Systems
Instruction & Maintenance Manual
READ AND UNDERSTAND THIS MANUAL BEFORE OPERATING THE SYSTEM
STORE THE MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE
THIS MANUAL CONTAINS CRITICAL OPERATING INFORMATION
WHICH IF NOT FOLLOWED
COULD CAUSE DAMAGE TO THE SYSTYEM NOT COVERED BY WARRANTY.
These instructions apply specifically to the systems that are
included in the AX267 & AX284 packages for LPKF systems.
We Make Clean Air
------------------------------------------------------------
----------------------------------------------------------
30 Hymus Boulevard, Montreal, Quebec, H9R 1C9
Tel.: (514) 630-4444 Fax: (514) 630-4454 website:
www.QUATRO-air.com
info@QUATRO-air.com
Advertisement
Table of Contents
Related Manuals for Quatro CSA600 i Series
Summary of Contents for Quatro CSA600 i Series
- Page 1 QUATRO Page 1 of 10 Air Technologies Inc. CSA600 iSeries Premium Turbine Dust Collectors & Odor Control Systems Instruction & Maintenance Manual READ AND UNDERSTAND THIS MANUAL BEFORE OPERATING THE SYSTEM STORE THE MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE...
-
Page 2: What's In The Box
1- INTRODUCTION You are now the owner of a QUATRO CSA System, an advanced effective indoor dust and fume collection system designed specifically to remove particulate matter and odor causing gas phase contaminants at the source. You can expect a noticeable improvement in air quality as the CSA System begins the process of reducing microscopic airborne particulate. - Page 3 Never use any form of remote control that switches the power source on and off. In doing so, serious damage to the controls and motors may occur. Contact QUATRO if power switching is the only way you have to remotely control the unit.
- Page 4 Receiving Remote Signal Remote Switch Closed (On) OR Receiving Remote Signal From Another Piece Of Equipment Standby Fading Shutdown Delay Quatro System Continues To Run For 30-45 Seconds To Remove All Debris From LED 5 IN-OUT Work Area (L5) Flashing...
- Page 5 Remote (Automatic) Operation & Remote Status The Quatro System is designed to be used with other pieces of equipment that can support remote operation and/or remote status monitoring. The connection is made using the AE468 LPKF Remote Cable. The Quatro System supports “Closed Contact”...
- Page 6 To enable the remote system startup for either remote option, first plug the system into power and then connect remote cable. Then simply have the other piece of equipment supply a remote control voltage. When the unit is stopped the Quatro System will shut down after a short delay.
- Page 7 QUATRO Page 7 of 10 Air Technologies Inc. 6- FILTER SERVICE & REPLACEMENT Important Notes: NONE of the filters in the system are cleanable. They will all need to be removed and disposed of periodically. LED Diagnostic Table - “Service Filter(s)” Alerts (iSeries Controls) If “Service Filter(s)”...
- Page 8 QUATRO Page 8 of 10 Air Technologies Inc. Replacement Filter Part Numbers Description Part No. Filter Stage Anti Microbial Bag Filter (5 Pack) AG128 Stage 1 Hi Cap Filter (2 Pack) F073-BX Stage 2 HEPA Filter F074 Stage 3 Odor Filter (Most Applications)
-
Page 9: Troubleshooting Guide
QUATRO Page 9 of 10 Air Technologies Inc. Replacement Instructions ALLOW MOTOR(S) TO COOL FOR 45 MINS BEFORE SERVICING 1- Unplug power cord and open motor access panel. 2- Disconnect wires, cut zip ties. 3- Remove the retaining nuts & lock washer holding the motor assemblies. -
Page 10: Specifications
QUATRO claims no warranty as to merchantability or as to the fitness of the merchandise for any particular use and shall not be liable for any loss or damage. No person, firm or corporation is authorised to assume for QUATRO any other liability in connection with the sale of these goods.
