- Page 1 PRODUCT USE INSTRUCTIONS Ordering code：00BG01 Part number：FNI IOL-309-S01-M12 [ Technical support ] 1 / 12...
- Page 2 IO-Link Hub Module User Manual 16xDI/DO PNP 2 / 12...
-
Page 3: Table Of Contents
Contents Security ............................... 4 ■ Expected use ..........................4 ■ Installation and start-up .........................4 ■ Corrosion resistance ........................4 ■ Dangerous voltage ......................... 4 ■ General security ..........................4 1.Component function description ....................6 1.1Module overview ........................6 2.. Interface definition ........................7 2.1 IO-Link interface ........................7 2.2 Digital input/output port connection diagram ..............7 2.3 Status LED meter ........................8... -
Page 4: Security
Security ■ Expected use This manual describes as decentralized input and output modules for connecting to an industrial network. --------------------------------------------------------------------------------------------------------------------------------- ■ Installation and start-up Precautions! Installation and start-up may only be performed by trained personnel. A qualified individual is one who is familiar with the installation and operation of the product and has the necessary qualifications to perform such operations. -
Page 5: General Security
General security ■ Debugging Trouble Owner/operator Expected use obligations inspection If the defect or equipment failure cannot be corrected, the operation This equipment Before of the is an EMC Class debugging, equipment A compliant read the user must be product. This manual stopped to device produces... -
Page 6: Component Function Description
1.Component function description Module overview Status LED: Status LED: Status LED: Digital I/O Digital I/O Digital I/O Power actuator IO-Link port 0 port 2 port 4 StatusLED: Status LED: Digital I/O Digital I/O Digital I/O Digital I/O Fixing hole Digital I/O port 6 port 7 port 5... -
Page 7: Interface Definition
2.Interface definition 2.1 IO-Link interface M12, A type, Male Description Us power supply, +24V Ua actuator power supply, +24V C/Q, I0-Link data transmission channel 2.2 Digital input/output port connection diagram M12, A type, Female Ordinary I/O PNP Input PNP output 7 / 12... -
Page 8: Status Led Meter
2.3 Status LED meter Status LED Status Description Steady green Module power supply is normal Destroy Module is not powered Steady green Auxiliary power supply is normal Destroy No auxiliary power supply Steady green Communication abnormality Flashing green Communication is normal 2.4 Mechanical dimensions Project Specification... -
Page 9: Io-Link Data
3.IO-Link data 3.1 Communication parameters Data transmission baud rate COM2 (38.4kbit/s) Minimum cycle time Process data cycle time 3ms, consistent with the minimum cycle time Process data length 2 bytes input, 2 bytes output 3.2 Process data 3.2.1 Process data/input data Byte Bits 3.2.2 Process data/output data... -
Page 10: Parameter Specifications
3.3 Parameter specifications Rated working voltage 18...30V DC Maximum current of each port (Pin1) Maximum current of each signal (Pin2, Pin4) 500mA Total current Us ＜1.4A Total current Ua ＜2A Ambient temperature -5~55℃ Relative humidity: 10%RH ～ 90%RH, no condensation Storage temperature -5~70℃... -
Page 11: Error Code
3.5 Error code 3.6 Event 11 / 12... - Page 12 12 / 12...
