- Page 1 USE INSTRUCTIONS Ordering code：00B311 Part number：FNI IOL-104-S01-M08 [ Technical support ] 1 / 12...
- Page 2 IOL-104-S01-M08 16 DI PNP IP67 module user manual 2 / 12...
-
Page 3: Table Of Contents
Contents Security ............................4 ■ Expected use ........................4 ■ Installation and start-up ....................4 ■ Corrosion resistance ......................4 ■ Dangerous voltage ......................4 Getting started guide ......................5 1.1 Module overview ......................6 1.2 Mechanical connection ....................7 1.3 Electrical connections .......................7 Technical data ........................8 2.1. -
Page 4: Security
Security ■Expected use This manual describes as decentralized input and output modules for connecting to an industrial network. ----------------------------------------------------------------------------------------------------------------------- ■Installation and start-up Precautions! Installation and start-up may only be performed by trained personnel. A qualified individual is one who is familiar with the installation and operation of the product and has the necessary qualifications to perform such operations. -
Page 5: General Security
General security ■ Debugging Trouble Owner/operator Expected use obligations inspection If the defect or equipment failure cannot be corrected, the operation This equipment Before of the is an EMC Class debugging, equipment A compliant read the user must be product. This manual stopped to device produces... -
Page 6: Module Overview
1.1 Module overview Figure 1 1 IO-Link interface 8 Fixing holes 2 Fixing holes 9 Port LED: Standard input port 7, Pin 4 3 Label 10 Standard Output Port 6 4 Standard output port 1 11 Standard output port 4 5 Standard output port 3 12 Standard output port 2 6 Standard output port 5... -
Page 7: Mechanical Connection
Indicator light Describe State Port LED Yellow LED indicator Input status is normal Green, pulse Communication is normal State LED Communication indicator abnormality 1.2 Mechanical connection The modules are connected using 2 M4 bolts and 2 washers. Isolation pads are available as accessories. 1.3 Electrical connections 1.3. -
Page 8: Technical Data
2.1. Size 2.2 Mechanical data Shell material Plastic Housing rating according to IEC 60529 IP67 (only in plug-in or plug type) IO-Link interface A-Coded Input port M8(8*Female) Size(W*H*D) 30mm*131mm*25.8mm Installation type 2-Through hole mounting Weight About 107 g 8 / 12... -
Page 9: Operating Conditions
2.3 Operating conditions Operating temperature -5°C ~ 70°C Storage temperature -25°C ~ 70°C 2.4 Electrical data Voltage 18~30V DC，conform to EN61131-2 Voltage fluctuation ＜1% Maximum load current, sensor/channel 100mA Total current <800mA 2.5 IO-Link data As shown in Table 1-1. Surface Data transmission baud rate COM2 (38.4kbit/s) -
Page 10: Process Data/Input Data
SPDU Object name length Scope Defaults Index Index Subindex Supplier ID 0x0454 Device ID 0x0994E3 Supplier name 0x10 FAS(Fujian)Co.,LTD Supplier text 0x11 www.fas-elec.com Product name 0x12 IOL-104-000-M08 Product ID 0x13 00B311 Read only Product text 0x14 IO-Link M8 PNP 16DI... -
Page 11: Error
2.9 Error As shown in Figure 6. Figure 2.10 Event As shown in Figure 7. Figure 11 / 12... - Page 12 12 / 12...
