INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS
FIGURE 600 / 601
BALL VALVES
FLANGED TWO-PIECE BALL VALVES
This instruction manual includes installation, operation
and maintenance information for FNW flanged
split-body ball valves. This manual addresses lever
operated ball valves only. Please refer to other
FNW manuals for other ball valves, actuated valves,
modifications or accessories.
TABLE OF CONTENTS
Storage ........................................................................ 2
Installation .................................................................. 2
Operation ................................................................... 3
Maintenance .............................................................. 3
Charts/Diagrams ....................................................... 4
Toubleshooting ......................................................... 6
Warranty ......................................................................7
FNW.COM
CAUTION:
• Valve pressure ratings are based on many variables,
including valve series and size, as well as body, seat and
bolt material. Verify that the application does not exceed
the pressure or temperature rating of the valves.
• Always depressurize the line with the valve in the open
position before disassembly.
• Wear protective equipment and take appropriate
precautions to safeguard against injury caused by the
discharge of trapped fluids.
• Use only FNW recommended spare parts for maintenance.
• To ensure safety and to maintain warranty, never modify
the valve in any way without prior approval from FNW.
We reserve the right to modify or improve the designs or
1
specifications of our products at any time without notice.
Advertisement
Table of Contents
Related Manuals for FNW FIGURE 601
Summary of Contents for FNW FIGURE 601
-
Page 1: Table Of Contents
• Use only FNW recommended spare parts for maintenance. • To ensure safety and to maintain warranty, never modify Toubleshooting ............6 the valve in any way without prior approval from FNW. Warranty ..............7 FNW.COM We reserve the right to modify or improve the designs or... -
Page 2: Storage
• If the valve was supplied with an actuator, secondary support may be necessary. Contact FNW for recommendations. • FNW flanged ball valves are designed for mounting between ANSI flanges. It should be taken into account that a valve which is designed for a particular flange standard cannot, under normal situations, be used with flanges from another standard. -
Page 3: Before Installation
- Remove handle nut (15), handle (16) or actuator set, stop-lock-cap (14), stem nut (13), Belleville washer (12), gland (11), bush (10). - Remove body bolt (5) or stud nut to allow end cap (2), separate from body (1), remove body gasket (19). FNW.COM We reserve the right to modify or improve the designs or... -
Page 4: Charts/Diagrams
575 ~ 664 1/2-13 UNC 61.67 708 ~ 814 1/2-13 UNC 1024 85.33 5/8-11 UNC 1847 153.92 3/4-10 UNC 3000 FNW.COM We reserve the right to modify or improve the designs or specifications of our products at any time without notice. -
Page 5: Parts Diagram
6 Studs 8 Studs 10 Studs 12 Studs PARTS DIAGRAM 1 SIZE: 1/2" ~ 2-1/2" (3"-4") FNW.COM We reserve the right to modify or improve the designs or specifications of our products at any time without notice. SIZE: 1/2" ~ 2-1/2"... -
Page 6: Troubleshooting
• Verify that the valve is in the fully closed position. If leakage persists, the valve should be disassembled and damaged parts replaced. • Please see spec sheet for soft good repair kits. FNW.COM We reserve the right to modify or improve the designs or... -
Page 7: Warranty
(whether or not based on negligence) arising directly or indirectly from delays or failure to give notice of delay. FNW.COM We reserve the right to modify or improve the designs or specifications of our products at any time without notice.
