Ford Expedition 2011 Owner's Manual
  1. Manuals
  2. Brands
  3. Ford Manuals
  4. Automobile
  5. Expedition 2011
  6. Owner's manual
Ford Expedition 2011 Owner's Manual

Ford Expedition 2011 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AM/FM stereo with CD
Windshield wiper/washer control
Steering wheel adjustment
2011 Expedition (exd)
Owners Guide, 1st Printing
USA (fus)

Table of Contents

https://www.MyCarManual.com
4
12
12
18
20
39
39
46
48
49
56
59
59
60
60
64
70
71
71
74
76
82
82
84
89
91
96
100
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Expedition 2011 and is the answer not in the manual?

Questions and answers

Howard L Purdy
July 22, 2025

Where is the fill plug four the rear axcel

0

Related Manuals for Ford Expedition 2011

Summary of Contents for Ford Expedition 2011

  • Page 1: Table Of Contents

    Table of Contents Introduction Instrument Cluster Warning lights and chimes Gauges Message center Entertainment Systems AM/FM stereo with CD Auxiliary input jack (Line in) USB port Rear seat controls Satellite radio information Navigation system SYNC Climate Controls Manual heating and air conditioning Dual automatic temperature control Rear window defroster Lights...
  • Page 2 Table of Contents Locks and Security Keys Locks Anti-theft system Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes AdvanceTrac...
  • Page 3 Ford Motor Company. Ford may change the contents without notice and without incurring obligation. Copyright © 2010 Ford Motor Company https://www.MyCarManual.com...

  • Page 4: Introduction

    Introduction CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.

  • Page 5: Perchlorate Material

    Introduction Warning symbols on your vehicle When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind. Protecting the environment We must all play our part in protecting the environment.

  • Page 6: Special Notices

    Introduction Do not add friction modifier compounds or special break-in oils since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage. SPECIAL NOTICES New Vehicle Limited Warranty For a detailed description of what is covered and what is not covered by your vehicle’s New Vehicle Limited Warranty, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.

  • Page 7: Data Recording

    In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may...
  • Page 8 EDR. Ford Motor Company and Ford of Canada do not access event data recorder...

  • Page 9: Cell Phone Use

    WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that you use extreme caution when using any device or feature that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
  • Page 10 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Child Seat Lower Airbag - Side Anchor Child Seat Tether Brake System Anchor Anti-Lock Brake System Parking Brake System Brake Fluid -...
  • Page 11 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Child Safety Door Interior Luggage Lock/Unlock Compartment Release Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...

  • Page 12: Instrument Cluster

    Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
  • Page 13 Instrument Cluster Solid illumination after the engine is started indicates the on-board diagnostics system (OBD-II) has detected a malfunction. Refer to On-board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter.
  • Page 14 Instrument Cluster WARNING: Driving a vehicle with the brake system warning light on is dangerous. A significant decrease in braking performance may occur. It will take you longer to stop the vehicle. Have the vehicle checked by your authorized dealer. Driving extended distances with the parking brake engaged can cause brake failure and the risk of personal injury.
  • Page 15 Instrument Cluster Engine oil pressure (RTT): Displays when the oil pressure falls below the normal range. Refer to Engine oil in the Maintenance and Specifications chapter. Engine coolant temperature (RTT): Displays when the engine coolant temperature is high. Stop the vehicle as soon as safely possible, switch off the engine and let it cool.
  • Page 16 Instrument Cluster Transmission Tow/Haul Feature (RTT): Displays when the Tow/Haul feature has been activated. Refer to the Driving chapter for transmission function and operation. If the light flashes steadily, have the system serviced immediately, damage to the transmission could occur. AdvanceTrac (if equipped): Displays when the AdvanceTrac with RSC system is active.
  • Page 17 Instrument Cluster Four-wheel drive auto (RTT) (if equipped): Displays when four-wheel drive automatic mode is AUTO engaged. If the light fails to display when the ignition is turned on, or remains on, have the system serviced immediately by your authorized dealer.

  • Page 18: Gauges

    Instrument Cluster GAUGES Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating.
  • Page 19 Instrument Cluster Odometer: Registers the total miles (kilometers) of the vehicle. • With standard message center • With optional message center Refer to Message center in this chapter for information on how to switch the display from Metric to English. Trip odometer: Registers the miles (kilometers) of individual journeys.

  • Page 20: Standard Message Center (If Equipped)

    Instrument Cluster Engine oil pressure gauge: Indicates engine oil pressure. The needle should stay in the normal operating range (between “L” and “H”). If the needle falls below the normal range, stop the vehicle, turn off the engine and check the engine oil level.
  • Page 21 Instrument Cluster MILES (km) TO E This displays an estimate of approximately how far you can drive with the fuel remaining in your tank under normal driving conditions. Remember to turn the ignition off when refueling to allow this feature to correctly detect the added fuel.

  • Page 22: Message Center

    Instrument Cluster COMPASS DISPLAY (if equipped) The compass heading is displayed as one of N, NE, E, SE, S, SW, W and NW in the message center display. The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antenna. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy.

  • Page 23: Setup Menu

    Instrument Cluster Compass calibration adjustment NOTE: For optimum calibration, drive to an open, level location away from large metallic objects or structures. Switch off all non-essential electrical accessories (heated rear window, heater, A/C, map lamps, wiper, etc.) and make sure all the doors are closed. 1.

  • Page 24: Recommended Engine Oils

    Instrument Cluster HOLD RESET FOR SYSTEM CHECK Press and hold the SELECT/RESET stem to start the system check when HOLD RESET FOR SYSTEM CHECK is displayed in the message center. For each of the monitored systems, the message center will indicate either an ok message or a warning message for two seconds.
  • Page 25 Instrument Cluster Press and hold the SELECT/RESET stem to change from English to Metric. Press the SELECT/RESET stem for the next SETUP MENU item or wait for more than four seconds to return to the INFO MENU. AUTOLAMP This feature keeps your headlights on for up to three minutes after the ignition is switched off.
  • Page 26 Instrument Cluster System warnings System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems. In the event of a multiple warning situation, the message center will cycle the display to show all warnings by displaying each one for four seconds.
  • Page 27 Instrument Cluster LOW TIRE PRESSURE — Displayed when one or more tires on your vehicle have low tire pressure. Refer to Inflating your tires in the Tires, Wheels and Loading chapter. TIRE PRESSURE MONITOR FAULT — Displayed when the Tire Pressure Monitoring System is malfunctioning.
  • Page 28 Instrument Cluster BRAKE FLUID LEVEL LOW — Indicates the brake fluid level is low and the brake system should be inspected immediately. Refer to Brake fluid in the Maintenance and Specifications chapter. XXX MILES TO E FUEL LEVEL LOW — Displayed as an early reminder of a low fuel condition.

  • Page 29: Optional Message Center (If Equipped)

    Instrument Cluster BUCKLE UP TO UNMUTE AUDIO — Displayed when a MyKey™ is in use and Belt-Minder is activated. Refer to MyKey™ in the Locks and Security chapter for more information. ADVTRAC ON MYKEY SETTING — Displayed when a MyKey™ is in use when trying to disable the AdvanceTrac system and the optional setting is on.
  • Page 30 Instrument Cluster LOW FUEL LEVEL will display when you have approximately 50 miles (80 km), to empty. Press RESET to clear this warning message. It will return at approximately 25 miles (40 km), 10 miles (16 km) and 0 miles (0 km) miles to empty.

  • Page 31: Reset For System Check

    Instrument Cluster TIMER Timer displays the trip elapsed drive time. To operate, do the following: 1. Press and release RESET in order to start the timer. 2. Press and release RESET to pause the timer. 3. Press and hold RESET until the timer resets. System check and vehicle feature customization Press the SETUP button repeatedly to cycle the message center through...

  • Page 32: Autolamp (Sec)

    Instrument Cluster To reset the oil monitoring system to 100% after each oil change perform the following: 1. Press and release SETUP to display “OIL LIFE XXX% HOLD RESET = NEW”. 2. Press and hold RESET for two seconds and release to reset the oil life to 100%.
  • Page 33 Instrument Cluster POWER LIFTGATE (if equipped) This feature allows users to open/close the rear liftgate at the touch of a button. Press the RESET button to turn the power liftgate on or off. If disabled, the outside release handle and the rear cargo area control button are off. The instrument panel button will continue to function the liftgate in power mode.
  • Page 34 Instrument Cluster Most geographic areas (zones) have a magnetic north compass point that varies slightly from the northerly direction on maps. This variation is four degrees between adjacent zones and will become noticeable as the vehicle crosses multiple zones. A correct zone setting will eliminate this error.
  • Page 35 Instrument Cluster ENGLISH / FRENCH / SPANISH RESET FOR NEW Allows you to choose which language the message center will display in. Selectable languages are English, Spanish, or French. Press RESET to cycle through each of the language choices. Press and hold RESET for two seconds to set the language choice. System warnings System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems.
  • Page 36 Instrument Cluster CHECK CHARGING SYSTEM — Displayed when the electrical system is not maintaining proper voltage when the engine is running. If you are operating electrical accessories when the engine is idling at a low speed, turn off as many of the electrical loads as soon as possible. If the warning stays on or comes on when the engine is operating at normal speeds, contact your authorized dealer as soon as possible.
  • Page 37 Instrument Cluster CHECK AIR SUSPENSION (if equipped) — Displayed when the air suspension system is not operating properly. If this message is displayed while driving, pull off the road as soon as safely possible. For more information, refer to Air suspension system in the Driving chapter. CHECK PARK AID (if equipped) —...
  • Page 38 Instrument Cluster SHIFT DELAYED PULL FORWARD (if equipped) — May display when shifting to or from 4X4 LOW. For more information, refer to Control Trac four-wheel drive (4X4) operation in the Driving chapter. MYKEY ACTIVE DRIVE SAFELY — Displayed at startup when MyKey™...

  • Page 39: Entertainment Systems

    (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device or feature that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
  • Page 40 Entertainment Systems In satellite radio mode (if equipped), press to scroll through the SIRIUS channels. Satellite radio is available only with a valid SIRIUS radio subscription. Check with your authorized dealer for availability. (Phone): Press to access SYNC phone features if your vehicle is equipped with SYNC .
  • Page 41 Entertainment Systems • DELETE SONG: Press OK to delete a song from the system’s memory. Press to cycle through the saved songs. When the song appears in the display that you would like to delete, press OK. The song will appear in the display for confirmation. Press OK again and the display will read SONG DELETED.
  • Page 42 Entertainment Systems To activate, press MENU repeatedly until RBDS (ON/OFF) appears in the display. Use SEEK to toggle RBDS ON/OFF. (When RBDS is OFF, you will not be able to search for RBDS equipped stations or view the station name or type.) To search for specific RBDS music categories: When the desired category appears in the display, press to find the desired type,...
  • Page 43 Entertainment Systems Track/Folder mode: Available only on MP3 discs in CD mode. In Track mode, pressing SEEK, SEEK will scroll through all tracks on the disc In Folder mode, pressing SEEK, SEEK will scroll only through tracks within the selected folder. Press FOLDER, FOLDER to access the previous/next folder (if...
  • Page 44 Entertainment Systems In CATEGORY MODE, press SEEK, SEEK to select a category (Jazz, Rock, News, etc.). Once the desired category is in the display, press SEEK, SEEK to seek to the previous/next channel in the selected category. Press and hold SEEK, SEEK to fast seek through the previous /next channels.
  • Page 45 Entertainment Systems 10. FF (Fast forward): In CD mode, press FF to manually advance in a track. In DVD mode (if equipped), press and hold to advance through the current chapter. 11. REW (Rewind): In CD mode, press REW to manually reverse in a track.

  • Page 46: Auxiliary Input Jack (Line In)

    Auxiliary input jack (Line in) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device or feature that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
  • Page 47 Entertainment Systems Your vehicle is equipped with an Auxiliary Input Jack (AIJ) located inside the center console. The Auxiliary Input Jack provides a way to connect your portable music player to the in-vehicle audio system. This allows the audio from a portable music player to be played through the vehicle speakers with high fidelity.

  • Page 48: Usb Port

    USB port (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device or feature that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.

  • Page 49: Rear Seat Controls

    Entertainment Systems Your vehicle may be equipped with a USB port inside your center console. This feature allows you to plug in media playing devices, memory sticks, and also to charge devices if they support this feature. For further information on this feature, refer to Accessing and using your USB port in the SYNC supplement or Navigation System supplement.
  • Page 50 Entertainment Systems 2. VOLUME: Press to increase or to decrease the volume level in the headphones. From the rear seat controls, volume control can be set no higher than the current radio setting unless the speakers are turned off. : In radio mode, press and release to scroll through memory presets.
  • Page 51 Entertainment Systems Simultaneously press 3 and 5 to restrict the rear passengers control to LOCAL media. While in dual play mode, this means that only media which is played through the auxiliary input jacks, or media which has been selected at the radio by the driver can be accessed by the rear passengers.
  • Page 52 Entertainment Systems • Dual Play mode may also be activated by simultaneously pressing memory presets 2 and 4 located on the radio. The rear speakers are muted and rear seat passengers can listen to the selected media through their headphones. To deactivate dual play mode: •...

  • Page 53: General Audio Information

    Entertainment Systems GENERAL AUDIO INFORMATION Radio frequencies: AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are: AM: 530, 540–1700, 1710 kHz FM: 87.7, 87.9–107.7, 107.9 MHz Radio reception factors: There are three factors that can affect radio reception: •...
  • Page 54 CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Do not use any irregular shaped CDs or discs with a scratch protection film attached.
  • Page 55 Entertainment Systems • MP3 track mode ignores any folder structure on the MP3 disc. The player numbers each MP3 track on the disc (noted by the .mp3 file extension) from T001 to a maximum of T255. Note: The maximum number of playable MP3 files may be less depending on the structure of the CD and exact model of radio present.

  • Page 56: Satellite Radio Information

    Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
  • Page 57 Entertainment Systems Satellite radio electronic serial number (ESN): This 12–digit Satellite Serial Number is needed to activate, modify or track your satellite radio account. You will need this number when communicating with SIRIUS . While in satellite radio mode, you can view this number on the radio display by pressing the AUX and preset 1 controls simultaneously.
  • Page 58 Entertainment Systems Radio Display Condition Action Required NO TEXT Artist information not Artist information not available. available at this time on this channel. The system is working properly. NO TEXT Song title information Song title information not available. not available at this time on this channel.

  • Page 59: Navigation System

    Entertainment Systems NAVIGATION SYSTEM (IF EQUIPPED) Your vehicle may be equipped with a navigation system. Refer to the Navigation System supplement for further information. SYNC (IF EQUIPPED) Your vehicle may be equipped with SYNC , a hands-free communications and entertainment system with special phone and media features. For more information, please refer to the SYNC supplement or to the SYNC section in the Navigation System supplement (if equipped).

  • Page 60: Climate Controls

    Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) 1. Temperature selection: Controls the temperature of the airflow in the vehicle. 2. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control.
  • Page 61 Climate Controls 5. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in MAX A/C, (defrost) and (floor/defrost). 6. Fan speed adjustment: Controls the volume of air circulated in the vehicle. Manual heating and air conditioning system with rear passenger compartment climate control (if equipped) 1.
  • Page 62 Climate Controls 3. REAR: Press to enable the control located in the rear of the floor console (if equipped), or to activate the auxiliary A/C system per the settings on the front control. Press again to turn the auxiliary system off. REAR Rear temperature control: Press to enable the auxiliary system and to set the desired rear cabin airflow temperature...
  • Page 63 Climate Controls Operating tips • To reduce fog build-up on the windshield during humid weather, place the air flow selector in the position. • To reduce humidity build-up inside the vehicle: do not drive with the air flow selector in the O (off) or (in cold weather) MAX A/C position. •...

  • Page 64: Dual Zone Automatic Temperature Control With Rear Passenger Compartment Climate Control (If Equipped)

    Climate Controls DUAL ZONE AUTOMATIC TEMPERATURE CONTROL WITH REAR PASSENGER COMPARTMENT CLIMATE CONTROL (IF EQUIPPED) Defrost: Distributes outside air through the windshield defroster vents and demister vents. Can be used to clear thin ice or fog from the windshield. 2. Rear temperature control: Press to enable the auxiliary system and set the desired rear cabin airflow temperature with the front control.
  • Page 65 Climate Controls 5. R Rear fan speed control: Press to enable the auxiliary system or to adjust the rear fan speed from the front control. Press to manually increase or decrease the fan speed. When the rear fan button is pressed, the display will show only the rear cabin settings.

  • Page 66: Dual Automatic Temperature Control

    Climate Controls 17. EXT: Press to display the outside temperature. Press again to display the cabin temperature settings. Note: Exterior readings are more accurate when the vehicle is moving. 18. REAR: Press to enable the control located in the rear of the floor console.
  • Page 67 Climate Controls Rear defroster: Press to activate/deactivate the rear window defroster. Refer to Rear window defroster later in this chapter for more information. 5. R Rear fan speed control: Press to enable the auxiliary system or to adjust the rear fan speed from the front control. Press to manually increase or decrease the fan speed.
  • Page 68 Climate Controls 13. OFF: Outside air is shut out and the climate system is turned off. 14. Driver temperature control: Press to increase or decrease the temperature on the driver side of the cabin. Sets the passenger side temperature also when DUAL is disengaged. Note: The recommended vehicle cabin setting is between 72°F (22°C) and 75°F (24°C).

  • Page 69: Auxiliary Climate Control

    Climate Controls • A small amount of air may be felt from the floor vent regardless of the air distribution setting that is selected. During extreme high ambient temperatures when idling stationary for extended periods of time in gear, it is recommended to run the A/C with recirculation mode.

  • Page 70: Rear Window Defroster

    Climate Controls REAR WINDOW DEFROSTER The rear defroster control is located on the climate control panel and works to clear the rear window of fog and thin ice. The engine must be running to operate the rear window defroster. Press the control to turn the rear window defroster on. An indicator light on the button will illuminate when active.

  • Page 71: Lights

    Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position turn on the headlamps. Rotate back to to turn the headlamps off. Autolamp control The autolamp system provides light sensitive automatic on/off control of the exterior lights normally controlled by the headlamp control.
  • Page 72 Lights High beams Push the lever toward the instrument panel to activate. Pull the lever toward you to deactivate. Flash-to-pass Pull toward you slightly to activate and release to deactivate. Daytime running lamps (DRL) (if equipped) Turns the headlamps on at reduced intensity output. To activate: •...

  • Page 73: Panel Dimmer Control

    Lights PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel and all applicable switches in the vehicle during headlamp and parking lamp operation. Move the control to the full upright position, past detent, to turn on the interior lamps.

  • Page 74: Headlamps

    Lights 3. Turn on the low beam headlamps to illuminate the wall or screen and open the hood. Cover one of the headlamps so no light from that lamp hits the wall. 4. On the wall or screen you will observe a light pattern with a distinct horizontal edge towards the right.

  • Page 75: Interior Lamps

    Lights INTERIOR LAMPS Front row map lamps (if equipped) To turn on the map lamps, press the outer edge of the clear lens. The front row map lamp lights when: • any door is opened. • the instrument panel dimmer switch is rotated until the courtesy lamps come on.

  • Page 76: Bulb Replacement

    Lights Rear cargo lamp The dome lamp lights when: • any door is opened, and the switch is in the middle position. • the instrument panel dimmer switch is rotated until the courtesy lamps come on. • any of the remote entry controls are pressed and ignition is off (and switch is in the middle position).
  • Page 77 To replace all instrument panel lights - see your authorized dealer * To obtain replacement approach lamp assembly bulbs, see your authorized dealer and reference Ford part no. 2L1Z–13B374–BB for the passenger side mirror and 2L1Z–13B375–BB for the driver side mirror.
  • Page 78 Lights Replacing interior bulbs Check the operation of all bulbs frequently. Replacing exterior bulbs Check the operation of all the bulbs frequently. Replacing headlamp bulbs 1. Make sure that the headlamp control is in the off position. 2. Open the hood. 3.
  • Page 79 Lights 7. Insert the glass end of the new bulb into the headlamp assembly. When the grooves in the plastic base are aligned, turn the new bulb clockwise to install. 8. Connect the electrical connector. 9. Install the headlamp assembly and secure with two retainer bolts. Replacing front parking lamp/turn/sidemarker signal bulbs 1.
  • Page 80 Lights Replacing tail/stop/turn/sidemarker/backup lamp bulbs The tail/stop/turn/sidemarker/backup lamp bulbs are located in the same portion of the tail lamp assembly, one just below the other. Follow the same steps to replace either bulb: 1. Make sure the headlamp switch is in the off position and then open the liftgate to expose the lamp assembly screws.
  • Page 81 Lights 4. Press the four tabs that hold the light assembly on, one at a time, and pull the black bulb carrier away from the lamp. 5. Pull the old bulb out and replace with the new bulb. 6. Snap the black bulb carrier into the lamp assembly.

  • Page 82: Driver Controls

    Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Speed dependent wipers: When the wiper control is on, the speed of the wipers will automatically adjust with the vehicle speed.
  • Page 83 Driver Controls Courtesy wipe feature: One extra wipe will occur a few seconds after washing the front window to clear any excess washer fluid remaining on the windshield. Note: Do not operate the washer when the washer reservoir is empty. This may cause the washer pump to overheat.

  • Page 84: Tilt Steering Wheel

    Driver Controls TILT STEERING WHEEL 1. Pull and hold the steering wheel release control toward you. 2. Move the steering up or down until you find the desired location. 3. Release the steering wheel release control. This will lock the steering wheel in position.

  • Page 85: Overhead Console

    Driver Controls OVERHEAD CONSOLE The appearance of your vehicle’s overhead console will vary according to your option package. Forward storage bin (if equipped) The storage compartment may be used to store a pair of sunglasses. Press the release area on the rear edge of the bin door to open the storage compartment.

  • Page 86: Center Console (If Equipped)

    Driver Controls Power quarter rear windows (if equipped) Press and hold the VENT portion of the control to open the power rear quarter windows. Pull and hold the VENT control to close the power rear quarter windows. Note: Vehicles without a moon roof, will only have the VENT button.

  • Page 87: Auxiliary Power Point (12V Dc)

    Driver Controls AUXILIARY POWER POINT (12V DC) Power outlets are designed for accessory plugs only. Do not insert any other object in the power outlet as this will damage the outlet and blow the fuse. Do not hang any type of accessory or accessory bracket from the plug.
  • Page 88 Driver Controls Power point (110V AC) (if equipped) The 110V AC power point outlet is used for powering electrical devices that require up to 150W. Exceeding the 150W limit will cause the power point to cut off the power temporarily to provide overload protection. Note: The 110V AC power point is equipped with a safety cap and a safety twist tab.

  • Page 89: Power Windows

    Driver Controls The 110V AC power point can provide power whenever the vehicle ignition is in the on position and the power point green indicator light located in the top left corner is turned on. Refer to the indicator light code below for the power point status.
  • Page 90 Driver Controls Rear window buffeting: When one or both of the rear windows are open, the vehicle may demonstrate a wind throb or buffeting noise; this noise can be alleviated by: • lowering a front window approximately two to three inches or •...

  • Page 91: Interior Mirror

    Driver Controls Window lock The window lock feature allows only the driver and front passenger to operate the power windows. To lock out all the window controls (except for the driver and front passenger) press the right side of the control. Press the left side to restore the window controls.

  • Page 92: Mirrors

    Driver Controls Do not clean the housing or glass of any mirror with harsh abrasives, fuel or other petroleum-based cleaning products. Note: If equipped with a rearview camera system, a video image will display in the mirror or the navigation system display (if equipped) when the vehicle is put in R (Reverse).
  • Page 93 Driver Controls Fold-away mirrors Fold the side mirrors in carefully before driving through a narrow POWER FOLD space, like an automatic car wash. Powerfold mirrors (if equipped) Rotate the 4–way adjustment switch to the center position. Press the switch down to auto fold in and down again to auto fold back to design position.

  • Page 94: Power Adjustable Foot Pedals (If Equipped)

    Driver Controls Signal indicator mirrors (if equipped) When the turn signal is activated, the lower portion of the mirror housing will blink. POWER ADJUSTABLE FOOT PEDALS (IF EQUIPPED) The accelerator and brake pedal should only be adjusted when the vehicle is stopped and the gearshift lever is in the P (Park) position.

  • Page 95: Power Deployable Running Boards (If Equipped)

    Driver Controls POWER DEPLOYABLE RUNNING BOARDS (IF EQUIPPED) Deployable running boards (DRB) automatically move when the doors are opened to assist entering and exiting the vehicle. Automatic power deploy: • The running boards will extend down and out when the doors are opened.

  • Page 96: Speed Control

    Driver Controls position and flush the system (in particular the front and rear hinge arms) with a high-pressure car wash wand. Note: Do not use the running boards, front and rear hinge assemblies, running board motors, or the running board under body mounts to lift the vehicle when jacking.
  • Page 97 Driver Controls Setting speed control 1. Press and release ON. 2. Accelerate to the desired speed. 3. Press and release SET +. 4. Take your foot off the accelerator pedal. 5. The indicator light on the instrument cluster will turn on. Note: •...

  • Page 98: Steering Wheel Controls (If Equipped)

    Driver Controls Turning off speed control To turn off the speed control, press OFF or turn off the ignition. Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased. STEERING WHEEL CONTROLS (IF EQUIPPED) Audio control features MEDIA: Press repeatedly to scroll through available audio modes.
  • Page 99 Driver Controls SYNC system hands free control feature (if equipped) Press VOICE briefly until the voice icon appears on the display to use the voice command feature. You will hear a tone and LISTENING will appear in the radio display. Press and hold VOICE to exit voice command.

  • Page 100: Moon Roof

    Driver Controls MOON ROOF (IF EQUIPPED) The moon roof control is located on the overhead console. WARNING: Do not let children play with the moon roof or leave children unattended in the vehicle. They may seriously hurt themselves. The moon roof is equipped with an automatic, one-touch, express opening and closing feature.

  • Page 101: Universal Garage Door Opener (If Equipped)

    Driver Controls UNIVERSAL GARAGE DOOR OPENER (IF EQUIPPED) Your vehicle may be equipped with a universal garage door opener which can be used to replace the common hand-held transmitter. Car2U Home Automation System (if equipped) The Car2U Home Automation System is a universal transmitter located in the driver’s visor that includes two primary features –...
  • Page 102 Driver Controls Types of garage door openers (rolling code and fixed code) The Car2U Home Automation System may be programmed to operate rolling code and fixed code garage door openers. • Rolling code garage door openers were produced after 1996 and are code protected.
  • Page 103 Driver Controls 1. Firmly press the two outer Car2U system buttons for 1–2 seconds, then release. 2. Go to the garage to locate the garage door opener motor and its “learn” button. You may need a ladder to reach the unit and you may need to remove the unit’s cover or light lens to locate the “learn”...
  • Page 104 Driver Controls To program another rolling code device such as an additional garage door opener, a security device or home lighting, repeat Steps 1 through 4 substituting a different function button in Step 3 than what you used for the garage door opener. For example, you could assign the left-most button to the garage door, the center button to a security device, and the right-most button to another garage door opener.
  • Page 105 Driver Controls 3. To input these positions into the Car2U system, simultaneously press all three Car2U system buttons for a few seconds and then release to put the device into programming mode. The indicator lights will blink slowly. Within 2.5 minutes enter your corresponding DIP switch settings from left to right into your Car2U system by pressing and releasing the buttons corresponding to the settings you circled.

  • Page 106: Positive Retention Floor Mat

    Driver Controls To erase programming on the Car2U system (individual buttons cannot be erased), use the following procedure: 1. Firmly press the two outside Car2U system buttons simultaneously for approximately 20 seconds until the indicator lights begin to blink rapidly. The indicator lights are located directly above the buttons.

  • Page 107: Power Liftgate - If Equipped

    Driver Controls POWER LIFTGATE (IF EQUIPPED) The liftgate can be operated by the following: • Instrument panel control button • Transmitter button • Outside control button • Control button in the rear cargo area Note: The liftgate can be reversed with a second press on a control button or transmitter and can be manually closed at any time.
  • Page 108 Driver Controls closed before operating or moving the vehicle, especially in an enclosure, like a garage or a parking structure. The liftgate or it components could be damaged in an enclosure, if the liftgate is open. When power operating the liftgate at temperatures below 32° F (0° C), the liftgate may stop about 5 in.
  • Page 109 Driver Controls To close the liftgate with the rear cargo area control button: Press and release the control on the left rear quarter panel to close the liftgate. The chime will beep once if conditions are not correct to start an operation (i.e., the vehicle is out of park).
  • Page 110 Driver Controls Resetting the power liftgate: If any of these conditions occur, the power liftgate may not operate and must be reset: • A low voltage or dead battery • Disconnected battery • The liftgate is manually closed and left ajar (unlatched) To reset the power liftgate: 1.

  • Page 111: Manual Liftgate (If Equipped)

    Driver Controls MANUAL LIFTGATE (IF EQUIPPED) The liftgate area is only intended for cargo, not passengers. You can open and close the liftgate from outside the vehicle. The liftgate cannot be opened from the cargo area control button, only closed. Note: In the event of a power failure, the latch can be accessed and released from the inside using the access panel on the liftgate trim.
  • Page 112 Driver Controls Cargo shelf/divider (if equipped) The cargo shelf/divider is located behind the rear seat of your vehicle. The shelf has two positions: Flat shelf which pivots up and snaps into place or a divider which pivots up and snaps vertically into place. Do not put more than 30 lb (14 kg) on the shelf.

  • Page 113: Luggage Rack

    Always ensure that the load is secure before traveling. Ford Motor Company recommends loading the roof rack only when equipped with (optional) crossbars, to avoid unintended damage to the roof panel.

  • Page 114: Locks And Security

    Locks and Security KEYS Your vehicle may be equipped with two integrated keyhead transmitters (IKTs). The key blade functions as a programmed key which starts the vehicle and unlocks/locks all the doors. The transmitter portion functions as the remote entry transmitter.
  • Page 115 Locks and Security MYKEY™ The MyKey™ feature allows you to program a restricted driving mode to promote good driving habits. All but one of the keys programmed to the vehicle can be activated as a MyKey™. The key will remain restricted until MyKey™...
  • Page 116 Locks and Security 2. Press and release the RESET button. HOLD RESET TO CONFIRM MYKEY will be displayed. 3. Press and hold the RESET button for two seconds until MARK THIS AS RESTRICTED is displayed. 4. Wait until KEY RESTRICTED AT NEXT START is displayed. MyKey™...
  • Page 117 MyKey™ is not compatible with non-Ford approved aftermarket remote start systems. If you choose to install a remote start system please see your authorized dealer for a Ford approved remote start system. When using a Ford-approved remote start system, the default settings will recognize the remote start system as an additional admin key with its associated privileges.
  • Page 118 Locks and Security Note: For all vehicles with remote start installed, it is possible to program all original vehicle keys as MyKeys™, in which case, you will need to use your remote start system to reset all MyKeys™ as admin keys by doing the following: 1.
  • Page 119 Locks and Security Condition Potential Causes • Key in the ignition is a MyKey™ Cannot clear MyKey™ • No MyKeys™ are programmed to the vehicle. Refer to Create a MyKey™ section • Vehicle has been started using a remote start system that is programmed as MyKey™.

  • Page 120: Power Door Locks

    Locks and Security POWER DOOR LOCKS Press control to unlock all doors. Press control to lock all doors. Smart locks This feature helps to prevent you from locking yourself out of the vehicle if your key is still in the ignition. When you open one of the front doors or the liftgate and you lock the vehicle with the power door lock control (on the driver or passenger door trim panel), all the doors will lock, then all doors will automatically...
  • Page 121 Locks and Security The autolock feature repeats when: • any door is opened then closed while the ignition is in the on position and the vehicle speed is 9 mph (15 km/h) or lower, and • the vehicle attains a speed greater than 12 mph (20 km/h). Deactivating/activating autolock Your vehicle comes with the autolock feature enabled.
  • Page 122 Locks and Security Keyless entry keypad procedure 1. Turn the ignition to the off position. 2. Close all doors, the liftgate and liftgate window. 3. Enter 5–digit entry code 4. Press and hold the 3 • 4. While holding the 3 • 4 press the 7 • 8. 5.
  • Page 123 Locks and Security Power door lock switch autounlock enable/disable procedure Before starting, ensure the ignition is in the off position and all vehicle doors are closed. You must complete Steps 1–5 within 30 seconds or the procedure will have to be repeated. If the procedure needs to be repeated, wait a minimum of 30 seconds before beginning again.

  • Page 124: Childproof Door Locks

    Locks and Security CHILDPROOF DOOR LOCKS Childproof door locks prevent opening of the rear doors from inside the vehicle regardless of the state of the main locks (locked or unlocked). The childproof locks are located on the rear edge of each rear door and must be set separately for each door.
  • Page 125 Locks and Security The typical operating range for your IKT is approximately 33 feet (10 meters). A decrease in operating range could be caused by: • weather conditions, • nearby radio towers, • structures around the vehicle, or • other vehicles parked next to your vehicle. The IKT allows you to: •...
  • Page 126 Locks and Security Two stage unlocking may be disabled or re-enabled by simultaneously pressing the controls on the IKT for four seconds (disabling two stage unlock allows all vehicle doors to unlock simultaneously). The parking lamps will flash twice to indicate that two-stage unlock was enabled or disabled.
  • Page 127 Locks and Security Car finder Press twice within three seconds. The horn will chirp and the turn lamps will flash. It is recommended that this method be used to locate your vehicle, rather than using the panic alarm. Sounding a panic alarm Press to activate the alarm.
  • Page 128 Locks and Security Deprogramming memory feature from the transmitter To deactivate this feature: 1. Press and hold either the 1 or 2 button on the driver’s door for five seconds. A tone will be heard after 1 ⁄ seconds when the memory store is done, continue to hold until a second tone is heard after five seconds.
  • Page 129 Locks and Security Replacing lost integrated keyhead transmitters (IKTs) If you would like to have your integrated keyhead transmitters reprogrammed because you lost one, or would like to buy additional IKTs, you can either reprogram them yourself, or take all IKTs to your authorized dealer for reprogramming.

  • Page 130: Securicode™ Keyless Entry System

    Locks and Security • If the courtesy lamps were turned on because one of the vehicle doors or the liftgate was opened, the battery saver will shut them off 10 minutes after the ignition has been turned to the off position. •...
  • Page 131 Locks and Security Tips • Do not use five numbers in sequential order. • The factory set code will work even if you have set your own personal code. Erasing personal code 1. Enter the factory set 5–digit code. 2. Within five seconds, press the 1 • 2 on the keypad and release. 3.

  • Page 132: Anti-Theft System

    Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection.
  • Page 133 Locks and Security Anti-theft indicator The anti-theft indicator is located in the instrument panel cluster. • When the ignition is in the off position, the indicator will flash once every two seconds to indicate the SecuriLock system is functioning as a theft deterrent.
  • Page 134 Check to make sure the coded key is an approved Ford coded key. If your keys are lost or stolen you will need to do the following: •...
  • Page 135 Locks and Security • If two previously programmed coded keys are not available, you must take your vehicle to your authorized dealer to have the spare key(s) programmed. Please read and understand the entire procedure before you begin. 1. Insert the first previously programmed coded key into the ignition.

  • Page 136: Perimeter Alarm System (If Equipped)

    Locks and Security To program additional new unprogrammed key(s), wait 20 seconds and then repeat this procedure from Step 1. Note: To program MyKey™ features, refer to MyKey™ in this chapter. PERIMETER ALARM SYSTEM (IF EQUIPPED) The perimeter anti-theft system will help protect your vehicle from unauthorized entry.
  • Page 137 Locks and Security Each door, the hood, and the liftgate is armed individually, and if any are open, they must be closed before the open entry point (door, hood, or liftgate) can enter the 20 second countdown. The turn signal lamps will flash once when all doors, the hood and the liftgate are closed indicating the vehicle is locked and entering the 20 second countdown.

  • Page 138: Seating And Safety Restraints

    Seating and Safety Restraints SEATING Adjustable head restraints Your vehicle is equipped with front row outboard head restraints that are vertically adjustable. WARNING: To minimize the risk of neck injury in the event of a crash, the driver and passenger occupants should not sit in and/or operate the vehicle, until the head restraint is placed in its proper position.
  • Page 139 Seating and Safety Restraints 3. Lower the head restraint by pressing and holding the guide sleeve adjust/release button and pushing down on the head restraint. Properly adjust the head restraint so that the top of the head restraint is even with the top of your head and positioned as close as possible to the back of your head.
  • Page 140 Seating and Safety Restraints 2. Simultaneously press and hold both the adjust/release button and the unlock/remove button, then pull up on the head restraint. To reinstall the adjustable head restraint, do the following: 1. Insert the two stems into the guide sleeve collars.
  • Page 141 Seating and Safety Restraints Lift handle to move seat forward or backward. Manual seat recliner (if equipped) WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips. WARNING: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision.
  • Page 142 Seating and Safety Restraints Using the armrest (if equipped) Push the release control to move the armrest up or down. Using the manual lumbar support (if equipped) The lumbar support control is located on the outboard side of the seat. Turn the lumbar support control clockwise for more support.
  • Page 143 Seating and Safety Restraints Using the power lumbar support (if equipped) The power lumbar control is located on the outboard side of the seat. Press the forward side of the control for additional support. Press the rear side of the control to reduce support.
  • Page 144 Seating and Safety Restraints Move the switch in the direction of the arrows to raise or lower the rear portion of the seat cushion. Press the switch in the direction of the arrows to move the seat forward, backward, up or down. Press the control to recline the seatback forward or rearward.
  • Page 145 Seating and Safety Restraints Memory seat/power mirrors/adjustable pedals (if equipped) This system allows automatic positioning of the driver seat, power mirrors and adjustable pedals to two programmable positions. The memory seat control is located on the driver’s seat. • To program position 1, move the driver seat and mirrors to the desired position using the associated controls.
  • Page 146 Seating and Safety Restraints Heated seats WARNING: Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions, must exercise care when using the seat heater. The seat heater may cause burns even at low temperatures, especially if used for long periods of time.
  • Page 147 Seating and Safety Restraints Climate controlled seats air filter replacement (if equipped) The climate controlled seat system includes air filters that must be replaced periodically. Refer to the scheduled maintenance information for more information. • There is a filter located under each front seat.

  • Page 148: Rear Seats

    Seating and Safety Restraints To install a filter: • First, position the filter in its housing making sure that the far forward end is all the way up in the housing. Then push in on the center of the outside edge of the filter and rotate up into the housing until it clips into position.
  • Page 149 Seating and Safety Restraints 2. Locate handle on the side of the seat cushion by the door. 3. Pull up on the handle and push the seatback forward toward the front of the vehicle. To return the seat to the upright position: 1.
  • Page 150 Seating and Safety Restraints Placing the 2nd row outboard 40% seats in cargo mode WARNING: Use caution when folding the seatback to the flat back position as the system will move forward when you lift the release handle. The 2nd row seats can be placed in a kneel down load floor position to allow more cargo space.
  • Page 151 Seating and Safety Restraints Returning to the upright position from full lowered load floor position The seatback cannot be returned to the upright position until the seat is returned from the kneel down position. To return the seat to the upright position: 1.
  • Page 152 Seating and Safety Restraints To return the seat to a seating position: 1. Push the seat down and latch to the floor with a moderate amount of effort and speed. 2. Make sure the seat is latched to the floor. 3.
  • Page 153 Seating and Safety Restraints Exiting the 3rd row 1. Pull the strap located at the bottom outboard of the seat back to release the seat from the floor, and rotate the seat up towards the front seat. 2. Follow the directions above to return the seat from the E-Z entry and to the upright position.
  • Page 154 Seating and Safety Restraints WARNING: To prevent possible damage to the seat or safety belts, ensure that the safety belts are not buckled when moving the seat to the load floor position. 2. With the latch released the seatback can be lowered into the load floor position.
  • Page 155 Seating and Safety Restraints Adjusting the 2nd row center 20% seat (if equipped) Lift the handle to move the seat forward or backward. Note: This seat can be moved forward to keep a child in a child restraint close to the front seat occupants. The seat should be moved to the full rearward position when it is occupied by older children or adults, including children in booster seats.
  • Page 156 Seating and Safety Restraints The heated seats only operate when the ignition is on. To operate the heated seats: • Press the indicated side of the control for maximum heat. • Press again to deactivate. • Press the indicated side of the control for minimum heat.
  • Page 157 Seating and Safety Restraints Folding down the 3rd row seats to the load floor WARNING: To prevent possible damage to the seat or safety belts, ensure that the safety belts are not buckled when moving the seat to the load floor position. Before folding the third row seats, fold the head restraints down by pulling on the strap located at the...
  • Page 158 Seating and Safety Restraints Third row power folding seat (if equipped) Note: Be sure that the head restraints are folded down before powering the 3rd row seat down. The control buttons are located on the right-hand rear quarter trim panel (accessible from the liftgate area).

  • Page 159: Safety Restraints

    Seating and Safety Restraints SAFETY RESTRAINTS The restraint system provides an improved overall level of frontal crash protection to front seat occupants and is designed to help further reduce the risk of airbag-related injuries. The system is able to analyze different occupant conditions and crash severity before activating the appropriate safety devices to help better protect a range of occupants in a variety of frontal crash situations.
  • Page 160 Seating and Safety Restraints Driver and passenger dual-stage airbag supplemental restraints The dual-stage airbags offer the capability to tailor the level of airbag inflation energy. A lower, less forceful energy level is provided for more common, moderate-severity impacts. A higher energy level is used for the most severe impacts.
  • Page 161 Seating and Safety Restraints Determining if the restraint system is operational The restraint system uses a warning light in the instrument cluster or a back-up tone to indicate the condition of the system. Refer to the Warning lights and chimes section in the Instrument Cluster chapter. Routine maintenance of the restraint system is not required.
  • Page 162 Seating and Safety Restraints WARNING: It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
  • Page 163 Seating and Safety Restraints Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle. •...
  • Page 164 Seating and Safety Restraints Pregnant women should always wear their safety belt. The lap belt portion of a combination lap and shoulder belt should be positioned low across the hips below the belly and worn as tight as comfort will allow.
  • Page 165 Seating and Safety Restraints How to use the automatic locking mode • Buckle the combination lap and shoulder belt. • Grasp the shoulder portion and pull downward until the entire belt is pulled out. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound.
  • Page 166 Seating and Safety Restraints WARNING: BELT AND RETRACTOR ASSEMBLY MUST BE REPLACED if the safety belt assembly “automatic locking retractor” feature or any other safety belt function is not operating properly when checked by an authorized dealer. Failure to replace the belt and retractor assembly could increase the risk of injury in collisions.
  • Page 167 Seating and Safety Restraints Safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and right front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, squeeze the side release buttons with your thumb and finger and slide the height adjuster down.
  • Page 168 Seating and Safety Restraints To adjust the comfort guide: 1. Slip the shoulder belt into the belt guide. (The portion of the belt between the latch tongue and the D-ring, not the portion where the belt exits from the quarter trim panel.) 2.
  • Page 169 Seating and Safety Restraints Safety belt warning light and indicator chime The safety belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If... Then... The driver safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the...
  • Page 170 Seating and Safety Restraints If... Then... The driver’s safety belt is not The Belt-Minder feature is activated buckled approximately five - the safety belt warning light seconds after the safety belt illuminates and the warning chime warning light has turned off... sounds for six seconds every 30 seconds, repeating for approximately five minutes or until...
  • Page 171 Seating and Safety Restraints Reasons given... Consider... Prime time for an accident. “I was in a hurry” Belt-Minder reminds us to take a few seconds to buckle up. “Safety belts don’t work” Safety belts, when used properly, reduce risk of death to front seat occupants by 45% in cars, and by 60% in light trucks.
  • Page 172 Seating and Safety Restraints Deactivating/activating the Belt-Minder feature (if equipped) Read Steps 1 - 4 thoroughly before proceeding with the deactivation/activation programming procedure. Note: If you are using MyKey™, the Belt-Minder cannot be disabled. Also, if the Belt-Minder has been previously disabled, it will be re-enabled after the use of MyKey™.

  • Page 173: Airbags

    Seating and Safety Restraints • This will enable the Belt-Minder feature for that seating position if it is currently disabled. As confirmation, the safety belt warning light will flash four times per second for three seconds, followed by three seconds with the light off, then followed by the safety belt warning light flashing four times per second for three seconds again.
  • Page 174 Seating and Safety Restraints WARNING: When possible, all children 12 years old and under should be properly restrained in a rear seating position. WARNING: The National Highway Traffic Safety Administration (NHTSA) recommends a minimum distance of at least 10 inches (25 cm) between an occupant’s chest and the driver airbag module.
  • Page 175 Seating and Safety Restraints Children and airbags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
  • Page 176 Seating and Safety Restraints The airbags inflate and deflate rapidly upon activation. After airbag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
  • Page 177 Seating and Safety Restraints • one or more impact and safing sensors and diagnostic monitor (RCM), • a readiness light and tone • the electrical wiring which connects the components. The RCM (restraints control module) monitors its own internal circuits and the supplemental airbag electrical system wiring (including the impact sensors, the system wiring, the airbag system readiness light, the airbag backup power and the airbag ignitors).
  • Page 178 Seating and Safety Restraints WARNING: Do not attempt to service, repair, or modify the airbag SRS, its fuses or the seat cover on a seat containing an airbag. Contact your authorized dealer as soon as possible. WARNING: All occupants of the vehicle should always wear their safety belts even when an airbag SRS is provided.
  • Page 179 Seating and Safety Restraints The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system. Rather, it means the forces were not of the type sufficient to cause activation. Side airbags are designed to inflate in side-impact collisions, not roll-over, rear-impact, frontal or near-frontal collisions, unless the collision causes sufficient lateral deceleration.
  • Page 180 Seating and Safety Restraints WARNING: All occupants of the vehicle including the driver should always wear their safety belts even when an airbag SRS and Safety Canopy System is provided. WARNING: To reduce risk of injury, do not obstruct or place objects in the deployment path of the inflatable Safety Canopy .
  • Page 181 Seating and Safety Restraints Children 12 years old and under should always be properly restrained in the second or third row seats. The safety canopy will not interfere with children restrained using a properly installed child or booster seat because it is designed to inflate downward from the headliner above the doors along the side window opening.
  • Page 182 Seating and Safety Restraints Determining if the system is operational The SRS uses a readiness light in the instrument cluster or a tone to indicate the condition of the system. Refer to the Airbag readiness section in the Instrument Cluster chapter. Routine maintenance of the airbag is not required.

  • Page 183: Safety Restraints For Children

    Recommendations for Safety Restraints are based on probable child height, age and weight thresholds from NHTSA and other safety organizations or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consult your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in the vehicle.
  • Page 184 Seating and Safety Restraints Recommendations for Safety Restraints for Children Child size, height, weight, or Recommended restraint type Infants or Children weighing 40 lb (18 kg) Use a child safety seat toddlers or less (generally age four or (sometimes called an younger) infant carrier, convertible seat, or...
  • Page 185 Seating and Safety Restraints Recommendations for attaching child safety restraints for children Use any attachment method as indicated below by “X” LATCH LATCH Safety Safety Safety (lower (lower belt belt and belt Restraint Child anchors anchors LATCH only Type Weight only) (lower tether...
  • Page 186 Seating and Safety Restraints WARNING: Always carefully follow the instructions and warnings provided by the manufacturer of any child restraint to determine if the restraint device is appropriate for your child’s size, height, weight, or age. Follow the child restraint manufacturer’s instructions and warnings provided for installation and use in conjunction with the instructions and warnings provided by the vehicle manufacturer.

  • Page 187: Safety Seats For Children

    Seating and Safety Restraints training to ensure that all children ages 0 to 16 are properly restrained in the correct restraint system. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and your pediatrician to make sure your seat is appropriate for your child and properly installed in the vehicle.
  • Page 188 Seating and Safety Restraints Airbags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the vehicle seat all the way back.
  • Page 189 Seating and Safety Restraints Perform the following steps when installing the child seat with combination lap/shoulder belts: Note: Although the child seat illustrated is a forward facing child seat, the steps are the same for installing a rear facing child seat. 1.
  • Page 190 Seating and Safety Restraints 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
  • Page 191 Ford Motor Company recommends the use of a child safety seat having a top tether strap. See Attaching child safety seats with tether straps and Recommendations for attaching child safety restraints for children in this chapter for more information.
  • Page 192 Seating and Safety Restraints Your vehicle has LATCH lower anchors for child seat installation at the seating positions marked with the child seat symbol. The LATCH anchors are located at the rear section of the rear seat between the cushion and seatback, below the locator symbols on the seat back.
  • Page 193 Seating and Safety Restraints WARNING: Never attach two child safety seats to the same anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death. Each time you use the safety seat, check that the seat is properly attached to the lower anchors and tether anchor, if applicable.
  • Page 194 Seating and Safety Restraints The tether strap anchors in your vehicle are in the following positions (shown from top view): • Second row bench seat • Second row bucket seats Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor.
  • Page 195 Seating and Safety Restraints 2. Locate the correct anchor for the selected seating position. • Second row outboard seating positions • Second row center seating position (if equipped) 3. Grasp the tether strap and position it to the seat frame. 4.
  • Page 196 Seating and Safety Restraints 5. Rotate the tether strap clip. 6. Tighten the child safety seat tether strap according to the manufacturer’s instructions. Third row center seating position 1. Route the child safety seat tether strap over the back of the seat. 2.
  • Page 197 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. https://www.MyCarManual.com...
  • Page 198 Seating and Safety Restraints Booster seats position a child so that vehicle lap/shoulder safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably at the edge of the cushion, while minimizing slouching.
  • Page 199 Seating and Safety Restraints Types of booster seats There are generally two types of belt-positioning booster seats: backless and high back. Always use booster seats in conjunction with the vehicle lap/shoulder belt. • Backless booster seats If your backless booster seat has a removable shield, remove the shield.
  • Page 200 Seating and Safety Restraints Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
  • Page 201 Refer to the child restraint manufacturer’s instructions for additional inspection and maintenance information specific to the child restraint. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.

  • Page 202: Tires, Wheels And Loading

    Tires, Wheels and Loading NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed...
  • Page 203 Tires, Wheels and Loading Power is supplied to all four wheels through a transfer case or power transfer unit. 4WD vehicles allow you to select different drive modes as necessary. Information on transfer case operation and shifting procedures can be found in the Driving chapter. Information on transfer case maintenance can be found in the Maintenance and Specifications chapter.

  • Page 204: Information About Uniform Tire Quality Grading

    Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
  • Page 205 Tires, Wheels and Loading Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 ⁄...
  • Page 206 Tires, Wheels and Loading TIRES Tires are designed to give many thousands of miles of service, but they must be maintained in order to get the maximum benefit from them. Glossary of tire terminology • Tire label: A label showing the OE (Original Equipment) tire sizes, recommended inflation pressure and the maximum weight the vehicle can carry.

  • Page 207: Inflating Your Tires

    Ford Motor Company. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
  • Page 208 Tires, Wheels and Loading The cold inflation pressure should never be set lower than the recommended pressure on the Safety Compliance Certification Label or Tire Label. When weather temperature changes occur, tire inflation pressures also change. A 10°F (6°C) temperature drop can cause a corresponding drop of 1 psi (7 kPa) in inflation pressure.

  • Page 209: Tire Care

    Tires, Wheels and Loading TIRE CARE Inspecting your tires and wheel valve stems Periodically inspect the tire treads for uneven or excessive wear and remove objects such as stones, nails or glass that may be wedged in the tread grooves. Check the tire and valve stems for holes, cracks, or cuts that may permit air leakage and repair or replace the tire and replace the valve stem.
  • Page 210 Tires, Wheels and Loading Damage Periodically inspect the tire treads and sidewalls for damage (such as bulges in the tread or sidewalls, cracks in the tread groove and separation in the tread or sidewall). If damage is observed or suspected have the tire inspected by a tire professional.
  • Page 211 (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door.
  • Page 212 The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your tire pressure monitoring system.
  • Page 213 Tires, Wheels and Loading Tire and wheel alignment A bad jolt from hitting a curb or pothole can cause the front end of your vehicle to become misaligned or cause damage to your tires. If your vehicle seems to pull to one side when you’re driving, the wheels may be out of alignment.

  • Page 214: Information Contained On The Tire Sidewall

    Tires, Wheels and Loading INFORMATION CONTAINED ON THE TIRE SIDEWALL Both U.S. and Canada Federal regulations require tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a U.S. DOT Tire Identification Number for safety standard certification and in case of a recall.
  • Page 215 Tires, Wheels and Loading 7. H: Indicates the tire’s speed rating. The speed rating denotes the speed at which a tire is designed to be driven for extended periods of time under a standard condition of load and inflation pressure. The tires on your vehicle may operate at different conditions for load and inflation pressure.
  • Page 216 Tires, Wheels and Loading 10. Tire Ply Composition and Material Used: Indicates the number of plies or the number of layers of rubber-coated fabric in the tire tread and sidewall. Tire manufacturers also must indicate the ply materials in the tire and the sidewall, which include steel, nylon, polyester, and others.
  • Page 217 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below. Note: Tire Quality Grades do not apply to this type of tire. 1.
  • Page 218 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.

  • Page 219: Tire Pressure Monitoring System (Tpms)

    Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
  • Page 220 Tires, Wheels and Loading following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: The tire pressure monitoring system is NOT a substitute for manually checking tire pressure.
  • Page 221 Tires, Wheels and Loading To restore the full functionality of the tire pressure monitoring system, have the damaged road wheel/tire repaired and remounted on your vehicle. For additional information, refer to Changing tires with TPMS in this section. When you believe your system is not operating properly The main function of the tire pressure monitoring system is to warn you when your tires need air.
  • Page 222 Tires, Wheels and Loading Low tire pressure Possible cause Customer action required warning light Flashing warning Spare tire in use Your temporary spare tire is in light use. Repair the damaged road wheel and re-mount it on the vehicle to restore system functionality.

  • Page 223: Snow Tires And Chains

    Follow these guidelines when using snow tires and chains: • If possible, avoid fully loading your vehicle. • Use only cable type chains or chains offered by Ford as an accessory or equivalent. Other conventional link type chains may contact and cause damage to the vehicle’s wheel house and/or body.
  • Page 224 Tires, Wheels and Loading provide maximum return of vehicle design performance. Before loading your vehicle, familiarize yourself with the following terms for determining your vehicle’s weight ratings, with or without a trailer, from the vehicle’s Tire Label or Safety Compliance Certification Label: Base Curb Weight –...
  • Page 225 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
  • Page 226 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
  • Page 227 Tires, Wheels and Loading • Example only: WARNING: Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury.
  • Page 228 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
  • Page 229 Tires, Wheels and Loading WARNING: Do not use replacement tires with lower load carrying capacities than the original tires because they may lower the vehicle’s GVWR and GAWR limitations. Replacement tires with a higher limit than the original tires do not increase the GVWR and GAWR limitations.
  • Page 230 Tires, Wheels and Loading • A final example for your vehicle with 1,400 lb. (635 kg) of cargo and luggage capacity. You and one of your friends decide to pick up cement from the local home improvement store to finish that patio you have been planning for the past 2 years.

  • Page 231: Trailer Towing

    Tires, Wheels and Loading TRAILER TOWING Trailer towing puts additional loads on your vehicle’s engine, transmission, axle, brakes, tires and suspension. For your safety and to maximize vehicle performance, be sure to use the proper equipment while towing. Follow these guidelines to ensure safe towing: •...
  • Page 232 Tires, Wheels and Loading Note: Before towing a trailer, make sure the trailer brakes (if equipped) and lamps are properly connected and functional. If equipped with electronic trailer brakes, refer to the instructions provided by the aftermarket electronic brake controller manufacturer for determining trailer brake functionality.
  • Page 233 Tires, Wheels and Loading Hitches Do not use hitches that clamp onto the vehicle bumper; use a load-carrying hitch. You must distribute the load in your trailer so that 10–15% of the total weight of the trailer is on the tongue. WARNING: The trailer hitch on this vehicle is part of the vehicle rear crash safety structure.
  • Page 234 Tires, Wheels and Loading 4. Attach the trailer to the vehicle and adjust the hitch equalizers so that the front bumper height is within a ⁄ in. (13 mm) of the reference point. After proper adjustment, the rear bumper should be no higher than in Step 3. 5.
  • Page 235 Tires, Wheels and Loading • Turn off the speed control. The speed control may shut off automatically when you are towing on long, steep grades. • Activate the tow/haul feature to eliminate excessive transmission shifting and assist in transmission cooling. For additional information, refer to Automatic transmission operation in the Driving chapter.

  • Page 236: Recreational Towing

    Tires, Wheels and Loading Launching or retrieving a boat Disconnect the wiring to the trailer before backing the trailer into the water. Reconnect the wiring to the trailer after the trailer is removed from the water. When backing down a ramp during boat launching or retrieval: •...

  • Page 237: Driving

    Driving STARTING Positions of the ignition 1. Off— locks the steering wheel, automatic transmission gearshift lever and allows key removal. 2. Accessory— allows the electrical accessories such as the radio to operate while the engine is not running. 3. On— all electrical circuits operational.
  • Page 238 Driving WARNING: If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important safety precautions A computer system controls the engine’s idle revolutions per minute (RPM). When the engine starts, the idle RPM runs higher than normal in order to warm the engine.
  • Page 239 Driving 4. Make sure the parking brake is set. 5. Turn the key to 3 (on) without turning the key to 4 (start). Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights.
  • Page 240 Driving 3. After idling for a few seconds, release the parking brake, apply the brake, shift into gear and drive. Note: If the engine does not start on the first try, turn the key to the off position, wait 10 seconds and try Step 2 again. If the engine still fails to start, press the accelerator to the floor and try Step 2 again, keeping the accelerator on the floor until the engine begins to accelerate above cranking speeds;...

  • Page 241: Engine Block Heater - If Equipped

    Driving Guarding against exhaust fumes Carbon monoxide is present in exhaust fumes. Take precautions to avoid its dangerous effects. WARNING: If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes.
  • Page 242 Driving WARNING: To reduce the risk of electrical shock, do not use your heater with ungrounded electrical systems or two-pronged (cheater) adapters. Prior to using the engine block heater, follow these recommendations for proper and safe operation: • For your safety, use an outdoor extension cord that is product certified by Underwriter’s Laboratory (UL) or Canadian Standards Association (CSA).

  • Page 243: Brakes

    Driving How to use the engine block heater Ensure the receptacle terminals are clean and dry prior to use. To clean them, use a dry cloth. Depending on the type of factory installed equipment, your engine block heater system may consume anywhere between 400 watts or 1000 watts of power per hour.
  • Page 244 Driving Anti-lock brake system (ABS) On ABS-equipped vehicles, a noise from the hydraulic pump motor and pulsation in the pedal may be observed during ABS braking events. Pedal pulsation coupled with noise while braking under panic conditions or on loose gravel, bumps, wet or snowy roads is normal and indicates proper functioning of the vehicle’s anti-lock brake system.
  • Page 245 Driving Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops. The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the BRAKE ignition is turned on) until the parking brake is released.

  • Page 246: Advancetrac With Roll Stability Control™ (Rsc ) Stability Enhancement System (If Equipped)

    Driving Pull the release lever to release the brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. ADVANCETRAC WITH ROLL STABILITY CONTROL™ (RSC ) STABILITY ENHANCEMENT SYSTEM (IF EQUIPPED) The AdvanceTrac with RSC system provides the following stability enhancement features for certain driving situations: •...
  • Page 247 Driving WARNING: Remember that even advanced technology cannot defy the laws of physics. It’s always possible to lose control of a vehicle due to inappropriate driver input for the conditions. Aggressive driving on any road condition can cause you to lose control of your vehicle increasing the risk of personal injury or property damage.
  • Page 248 Driving Note: If the system cannot be turned off, refer to MyKey™ in the Locks and Security chapter for more information. When AdvanceTrac with RSC performs a normal system self-check, some drivers may notice a slight movement of the brake, and/or a rumble, grunting, or grinding noise after startup and when driving off.
  • Page 249 Driving Electronic stability control (ESC) Electronic stability control (ESC) may enhance your vehicle’s directional stability during adverse maneuvers, for example when cornering severely or avoiding objects in the roadway. ESC operates by applying brakes to one or more of the wheels individually and, if necessary, reducing engine power if the system detects that the vehicle is about to skid or slide laterally.
  • Page 250 Driving spin. This will restore full engine power and will enhance momentum through the obstacle. To switch off the traction control, press the stability control button. Full features of the AdvanceTrac with RSC system can be restored by pressing the stability control button again or by turning off and restarting the engine.
  • Page 251 WARNING: Turning off trailer sway control increases the risk of loss of vehicle control, serious injury, or death. Ford does not recommend disabling this feature except in situations where speed reduction may be detrimental (e.g., hill climbing), the driver has significant trailer towing experience, and can control trailer sway and maintain safe operation.

  • Page 252: Air Suspension

    Driving If the power steering system breaks down (or if the engine is turned off), you can steer the vehicle manually, but it takes more effort. If the steering wanders or pulls, check for: • Underinflated tire(s) on any wheel(s) •...

  • Page 253: Limited-Slip Axle (If Equipped)

    Driving LIMITED-SLIP AXLE (IF EQUIPPED) This axle provides added traction on slippery surfaces, particularly when one wheel is on a poor traction surface. Under normal conditions, the limited slip axle functions like a standard rear axle. Extended use of other than the manufacturer’s specified size tires on a limited slip rear axle could result in a permanent reduction in effectiveness.

  • Page 254: Brake-Shift Interlock - Column-Shift Transmission

    Driving BRAKE-SHIFT INTERLOCK – COLUMN-SHIFT TRANSMISSION This vehicle is equipped with a park/brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the on position unless brake pedal is pressed. If you cannot move the gearshift lever out of P (Park) with ignition in the on position and the brake pedal pressed, or when the ignition is in the off position, it is possible that a fuse has blown or the vehicle’s brake lamps are not operating properly.
  • Page 255 Driving WARNING: If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your authorized dealer. Brake-shift interlock – floor-shift transmission This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the on position unless the brake pedal is pressed.

  • Page 256: Transmission Operation

    Driving 7. Install the trim panel (3), screw (2) and chrome trim ring (1) in reverse order. 8. Apply brake pedal, start the vehicle, and release the parking brake. See your authorized dealer as soon as possible if this procedure is used.
  • Page 257 Driving P (Park) This position locks the transmission and prevents the rear wheels from turning. To put your vehicle in gear: • Press the brake pedal • Start the engine • Move the gearshift lever into the desired gear. If your vehicle is equipped with a floor-shift transmission, press the gearshift lever release button (on the front...
  • Page 258 Driving Tow/Haul can be activated by pressing the transmission control switch on the end of the gearshift lever (column-shift transmission) or on the side of the gearshift lever (floor-shift transmission). • Column-shift transmission • Floor-shift transmission The TOW HAUL indicator light will illuminate in the instrument cluster.
  • Page 259 Driving When you shut-off and restart the engine, the transmission will automatically return to normal D (Overdrive) mode (Tow/Haul OFF). WARNING: Do not use the Tow/Haul feature when driving in icy or slippery conditions as the increased engine braking can cause the rear wheels to slide and the vehicle to swing around with the possible loss of vehicle control.

  • Page 260: Reverse Sensing System

    Driving REVERSE SENSING SYSTEM (IF EQUIPPED) The reverse sensing system (RSS) sounds a tone to warn the driver of obstacles near the rear bumper when R (Reverse) is selected and the vehicle is moving at speeds less than 3 mph (5 km/h). The system is not effective at speeds above 3 mph (5 km/h) and may not detect certain angular or moving objects.
  • Page 261 Driving The RSS detects obstacles up to six feet (two meters) from the rear bumper with a decreased coverage area at the outer corners of the bumper, (refer to the figures for approximate zone coverage areas). As you move closer to the obstacle, the rate of the tone increases.

  • Page 262: Rear-View Camera System

    Driving REARVIEW CAMERA SYSTEM (IF EQUIPPED) The camera system located on the liftgate provides a video image, which appears in the rearview mirror or on the navigation screen (if equipped), of the area behind the vehicle. It adds assistance to the driver while reversing or reverse parking the vehicle.
  • Page 263 Driving Note: The default setting for the camera delay is off. Press the “Settings” button found on the navigation screen (if equipped) to set the camera delay feature to on or off. When towing, the camera system will only see what is being towed behind the vehicle;...
  • Page 264 Driving Servicing • If the image comes on while the vehicle is not in R (Reverse), have the system inspected by your authorized dealer. • If the image is not clear, then check if there is anything covering the lens such as dirt, mud, ice, snow, etc. If the image is still not clear after cleaning, have your system inspected by your authorized dealer.
  • Page 265 Driving 4WD indicator lights The indicator lights illuminate in the message center in the reconfigurable telltale (RTT) location under the following conditions. Refer to Warning lights and chimes in the Instrument Cluster chapter. • 4X2 - Momentarily illuminates when 2H is selected. •...
  • Page 266 Driving • 4L (4X4 LOW) provides electronically locked four-wheel drive when extra power at reduced speeds is required. The message center will display “4X4 LOW” when this position is selected. This position is not recommended for use on dry pavement. Use this position for off-road low-speed operation or when extra power is required, such as climbing steep grades, going through deep sand or pulling a boat out of the water.
  • Page 267 Driving Shifting to/from 4L 1. Bring the vehicle to a speed of 3 mph (5 km/h) or less. 2. Place the gearshift in N (Neutral). 3. Move the control to the desired position. The message center will display 4X4 SHIFT IN PROGRESS during the shift.
  • Page 268 Driving Drive cautiously to avoid vehicle damage from concealed objects such as rocks and stumps. You should either know the terrain or examine maps of the area before driving. Map out your route before driving in the area. To maintain steering and braking control of your vehicle, you must have all four wheels on the ground and they must be rolling, not sliding or spinning.
  • Page 269 Driving If your vehicle gets stuck If your vehicle gets stuck in mud or snow it may be rocked out by shifting between forward and reverse gears, stopping between shifts, in a steady pattern. Press lightly on the accelerator in each gear. Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur.
  • Page 270 Driving WARNING: Vehicles with a higher center of gravity such as utility and four-wheel drive vehicles handle differently than vehicles with a lower center of gravity. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
  • Page 271 Driving Avoid excessive speed because vehicle momentum can work against you and cause the vehicle to become stuck to the point that assistance may be required from another vehicle. Remember, you may be able to back out the way you came if you proceed with caution. If your vehicle is equipped with AdvanceTrac with RSC, press the AdvanceTrac with RSC button (refer to AdvanceTrac with Roll Stability Control (RSC) Stability Enhancement System in this...
  • Page 272 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
  • Page 273 Driving Descend a hill in the same gear you would use to climb up the hill to avoid excessive brake application and brake overheating. Do not descend in neutral; instead, disengage overdrive or manually shift to a lower gear. When descending a steep hill, avoid sudden hard braking as you could lose control.

  • Page 274: Driving Through Water

    Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).

  • Page 275: Roadside Emergencies

    Roadside Emergencies ROADSIDE ASSISTANCE Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...

  • Page 276: Hazard Flasher Control

    Assistance, call 1-800-241-3673. Canadian customers who require roadside assistance, call 1-800-665-2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles (56 km). To obtain reimbursement information, U.S.

  • Page 277: Fuel Pump Shut-Off Switch

    Roadside Emergencies FUEL FUEL PUMP SHUT-OFF SWITCH RESET The fuel pump shut-off switch is a device intended to stop the electric fuel pump when your vehicle has been involved in a substantial jolt. After a collision, if the engine cranks but does not start, the fuel pump shut-off switch may have been activated.

  • Page 278: Fuses And Relays

    Roadside Emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Note: Always replace a fuse with one that has the specified amperage rating.
  • Page 279 Roadside Emergencies Passenger compartment fuse panel The fuse panel is located under the right-hand side of the instrument panel. To remove the trim panel for access to the fuse box, pull the panel toward you and swing it out away from the side and remove it.
  • Page 280 Roadside Emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Protected Circuits Location Rating Driver window Driver side memory module Audio rear seat controls, Satellite radio, SYNC Not used (spare) Keypad illumination, 3rd row seat enable, Brake shift interlock (BSI), Smart fuse panel logic power Turn signals...
  • Page 281 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating Horn Demand lamps, Glovebox, Visor Instrument panel cluster Ignition switch Radio Instrument panel cluster Not used (spare) Not used (spare) Airbag module Not used (spare) Not used (spare) Rear park assist, 4x4, rear video camera, 2nd row heated seats Passive anti-theft system Climate control...
  • Page 282 Roadside Emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. WARNING: Always disconnect the battery before servicing high current fuses. WARNING: To reduce risk of electrical shock, always replace the cover to the power distribution box before reconnecting the battery or refilling fluid reservoirs.
  • Page 283 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating — Trailer tow (TT) battery charge relay — Fuel pump relay — Electronic fan 1 relay — Rear window defroster/heated mirror relay — Electronic fan 3 relay — Run/Start (R/S) relay —...
  • Page 284 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating 40A** Blower motor relay 40A** 110V AC power point 30A** Auxiliary blower motor 30A** PCM relay 30A** Power liftgate — TT left hand stop/turn relay — TT right hand stop/turn relay —...
  • Page 285 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating — One-touch start diode — Fuel pump diode — Not used 25A** Electronic fan 30A** Moon roof 20A** Auxiliary power point (instrument panel) 20A** Auxiliary power point (rear of center console) 40A** Front row climate controlled seats...

  • Page 286: Changing Tires

    Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
  • Page 287 Roadside Emergencies A dissimilar spare tire/wheel is defined as a spare tire and/or wheel that is different in brand, size or appearance from the road tires and wheels and can be one of three types: 1. T-type mini-spare: This spare tire begins with the letter “T” for tire size and may have “Temporary Use Only”...
  • Page 288 Roadside Emergencies The usage of a full-size dissimilar spare tire/wheel can lead to impairment of the following: • Handling, stability and braking performance • Comfort and noise • Ground clearance and parking at curbs • Winter weather driving capability • Wet weather driving capability •...
  • Page 289 Roadside Emergencies Location of the spare tire and tools The spare tire and tools for your vehicle are stowed in the following locations: Item Location Spare tire Under the vehicle, just forward of the rear bumper Jack tools and jacking instructions Under the access panel located in the floor compartment behind the rear seat Removing the jack and tools...
  • Page 290 Roadside Emergencies Removing the spare tire 1. Remove the jack handle and winch extension from the tray and assemble them. 2. Open the spare tire winch access plug in the bottom of the compartment for the jack and tools tray. 3.
  • Page 291 Roadside Emergencies WARNING: Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack and changing the wheel.
  • Page 292 Roadside Emergencies 5. Position the jack according to the jack locator arrows found on the frame and turn the jack handle and extension tool assembly clockwise. Note: Use the frame rail as the jacking location point, NOT the control arm. 6.
  • Page 293 Roadside Emergencies WARNING: Turn off the running boards (if equipped) before jacking or placing any object under the vehicle. Never place your hand between the extended running board and the vehicle. A moving running board may cause injury. • Never use the front or rear differential as a jacking point.
  • Page 294 Roadside Emergencies 13. Turn on the air suspension system (if equipped). Refer to Message center in the Instrument Cluster chapter for instructions on turning the air suspension system on. Stowing the spare tire 1. Lay the tire on the ground, near the rear of the vehicle, with the valve stem side facing up.

  • Page 295: Wheel Lug Nut Torque Specifications

    M14 x 2.0 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. WARNING: When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.

  • Page 296: Running Out Of Fuel

    Roadside Emergencies RUNNING OUT OF FUEL If you have run out of fuel and need to refill the vehicle with a portable fuel container, see Running out of fuel in the Maintenance and Specifications chapter for proper fuel filling method using a portable fuel container and the included fuel filler funnel.
  • Page 297 Roadside Emergencies 3. Park the booster vehicle close to the hood of the disabled vehicle making sure the two vehicles do not touch. Set the parking brake on both vehicles and stay clear of the engine cooling fan and other moving parts.
  • Page 298 Roadside Emergencies 4. Make the final connection of the negative (-) cable to the jump starting stud located in the engine compartment, near the washer fluid bottle. Note: Do not attach the negative (-) cable to fuel lines, engine rocker covers, the intake manifold or electrical components as grounding points.
  • Page 299 Roadside Emergencies 1. Remove the jumper cable from the jump starting stud. 2. Remove the jumper cable on the negative (-) terminal of the booster vehicle’s battery. 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4.

  • Page 300: Wrecker Towing

    It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. Also, wrecker towing the vehicle by the frame-mounted tow hooks is not recommended or advised.
  • Page 301 Roadside Emergencies Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle. Emergency towing In case of a roadside emergency with a disabled vehicle (without access...

  • Page 302: Customer Assistance

    A reasonable time must be allowed to perform a repair after taking your vehicle to the authorized dealer. Repairs will be made using Ford or Motorcraft parts, or remanufactured or other parts that are authorized by Ford.
  • Page 303 • The name of the authorized dealer and city where located • The vehicle’s current odometer reading In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states.

  • Page 304: In California (U.s. Only)

    In the case of 1 or 2 above, the consumer must also notify the manufacturer of the need for the repair of the nonconformity at the following address: Ford Motor Company 16800 Executive Plaza Drive Mail Drop 3NE-B Dearborn, MI 48126 https://www.MyCarManual.com...

  • Page 305: The Better Business Bureau (Bbb) Auto Line Program

    THE BETTER BUSINESS BUREAU (BBB) AUTO LINE PROGRAM (U.S. ONLY) Your satisfaction is important to Ford Motor Company and to your dealer. If a warranty concern has not been resolved using the three-step procedure outlined on the first page of the Customer Assistance section, you may be eligible to participate in the BBB AUTO LINE program.

  • Page 306: Bbb Auto Line

    (CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
  • Page 307 The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company/Ford of Canada is not responsible for any damage caused by use of improper fuel.

  • Page 308: Ordering Additional Owner's Literature

    If you buy your vehicle in North America and then relocate to any of the above locations, register your vehicle identification number (VIN) and new address with Ford Motor Company Export Operations & Global Growth Initiatives by emailing expcac@ford.com. If you are in another foreign country, contact the nearest authorized dealer.

  • Page 309: Reporting Safety Defects (U.s. Only)

    However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...

  • Page 310: Cleaning

    Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3-A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.

  • Page 311: Paint Chips

    Cleaning WAXING • Wash the vehicle first. • Use a quality wax that does not contain abrasives. • Do not allow paint sealant to come in contact with any non-body (low-gloss black) colored trim, such as grained door handles, roof racks, bumpers, side moldings, mirror housings or the windshield cowl area.

  • Page 312: Plastic (Non-Painted) Exterior Parts

    Cleaning ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage.

  • Page 313: Windows And Wiper Blades

    Cleaning WINDOWS AND WIPER BLADES The windshield, rear and side windows and the wiper blades should be cleaned regularly. If the wipers do not wipe properly, substances on the vehicle’s glass or the wiper blades may be the cause. These may include hot wax treatments used by commercial car washes, water repellent coatings, tree sap, or other organic contamination;...
  • Page 314 Cleaning • Be certain to wash or wipe your hands clean if you have been in contact with certain products such as insect repellent and suntan lotion in order to avoid possible damage to the interior painted surfaces. • Do not use household or glass cleaners as these may damage the finish of the instrument panel, interior trim and cluster lens.

  • Page 315: Cleaning The Climate Controlled Seats (If Equipped)

    Cleaning • If a ring forms on the fabric after spot cleaning, clean the entire area immediately (but do not oversaturate) or the ring will set. • Do not use household cleaning products or glass cleaners, which can stain and discolor the fabric and affect the flame retardant abilities of the seat materials.
  • Page 316 Cleaning LEATHER SEATS FOR THE KING RANCH EDITION ONLY (IF EQUIPPED) Your vehicle is equipped with seating covered in premium, top-grain leather which is extremely durable, but still requires special care and maintenance in order to ensure longevity and comfort. Regular cleaning and conditioning will maintain the appearance of the leather.

  • Page 317: Ford And Lincoln Mercury Car Care Products

    FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...

  • Page 318: Maintenance And Specifications

    Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle, we provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service. Check your Warranty Guide to find out which parts and services are covered.

  • Page 319: Opening The Hood

    Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom of the instrument panel. 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood.

  • Page 320: Engine Compartment

    Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 5.4L V8 1. Windshield washer fluid reservoir 2. Engine oil dipstick 3. Brake fluid reservoir 4. Engine coolant reservoir 5. Air filter assembly 6. Power steering fluid reservoir 7. Power distribution box 8.

  • Page 321: Windshield Washer Fluid

    In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specifications. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.

  • Page 322: Changing The Wiper Blades

    Maintenance and Specifications CHANGING THE WIPER BLADES Replace wiper blades at least once per year for optimum performance. To replace the wiper blades: 1. Fold back the wiper arm and position the wiper blade at right angles to the wiper arm. 2.

  • Page 323: Engine Oil

    Maintenance and Specifications 4. To attach the new wiper to the wiper arm, align the cross pin and keyway (denoted with the arrows) and firmly press the wiper blade into the wiper arm until an audible snap is heard. If you find this procedure too difficult, please see your dealer. ENGINE OIL Checking the engine oil Refer to the scheduled maintenance information for the appropriate...
  • Page 324 Maintenance and Specifications • If the oil level is below this mark, engine oil must be added to raise the level within the normal operating range. • If required, add engine oil to the engine. Refer to Adding engine oil in this chapter.
  • Page 325 Approval Committee (ILSAC), comprised of U.S. and Japanese automobile manufacturers. To protect your engine and engine’s warranty, use Motorcraft SAE 5W-20 or an equivalent SAE 5W-20 oil meeting Ford specification WSS-M2C930-A. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.

  • Page 326: Battery

    Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. If your battery has a cover/shield, make sure it is reinstalled after the battery has been cleaned or replaced. For longer, trouble-free operation, keep the top of the battery clean and dry.
  • Page 327 Maintenance and Specifications WARNING: Keep batteries out of reach of children. Batteries contain sulfuric acid. Avoid contact with skin, eyes or clothing. Shield your eyes when working near the battery to protect against possible splashing of acid solution. In case of acid contact with skin or eyes, flush immediately with water for a minimum of 15 minutes and get prompt medical attention.

  • Page 328: Engine Coolant

    Maintenance and Specifications • If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned. If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected.
  • Page 329 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the FULL COLD level, or within the COLD FILL or MIN / MAX range as listed on the engine coolant reservoir (depending upon application).
  • Page 330 Maintenance and Specifications • DO NOT MIX different colors or types of coolant in your vehicle. Make sure the correct coolant is used. DO NOT MIX recycled coolant and new (unused) coolant together in the vehicle. Mixing of engine coolants may harm your engine’s cooling system. The use of an improper coolant may harm engine and cooling system components and may void the warranty.
  • Page 331 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant since a Ford-approved recycling process is not yet available. Used engine coolant should be disposed of in an appropriate manner.
  • Page 332 Maintenance and Specifications • A coolant concentration of 60% will provide freeze point protection down to -62°F [-52°C]. Increased engine coolant concentrations above 60% will decrease the overheat protection characteristics of the engine coolant and may cause engine damage. • If available, refer to the chart on the coolant container to ensure the coolant concentration in your vehicle will provide adequate freeze protection at the temperatures in which you drive in the winter months.
  • Page 333 Maintenance and Specifications When this occurs the vehicle will still operate. However: • The engine power will be limited. • The air conditioning system will be disabled. Continued operation will increase the engine temperature: • The engine will completely shut down. •...

  • Page 334: Fuel Filter

    Maintenance and Specifications FUEL FILTER Your vehicle is equipped with a lifetime fuel filter that is integrated with the fuel tank. Regular maintenance or replacement is not needed. WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions WARNING: Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire.
  • Page 335 Maintenance and Specifications • Avoid getting fuel liquid in your eyes. If fuel is splashed in the eyes, remove contact lenses (if worn), flush with water for 15 minutes and seek medical attention. Failure to seek proper medical attention could lead to permanent injury.
  • Page 336 Maintenance and Specifications WARNING: Flexible fuel components and standard unleaded gasoline fuel components are not interchangeable. If your vehicle is not serviced in accordance with flexible fuel vehicles procedures, damage may occur and your warranty may be invalidated. WARNING: When refueling always shut the engine off and never allow sparks or open flames near the filler neck.
  • Page 337 Maintenance and Specifications Easy Fuel™ “no cap” fuel system Your fuel tank is equipped with an Easy Fuel™ “no cap” fuel filler system. This allows you to simply open the fuel filler door and insert the fuel filler nozzle into the fuel system. The Easy Fuel™ system is self-sealing and protected against dust, dirt, water and snow/ice.
  • Page 338 Maintenance and Specifications Flex fuel vehicle (FFV) fuel fill inlet Flex fuel vehicles have a yellow bezel placed over the fuel fill inlet. Choosing the right fuel Use only UNLEADED FUEL and FUEL ETHANOL (Ed75–Ed85). The use of leaded fuel is prohibited by law and could damage your vehicle. Your vehicle was not designed to use fuel or fuel additives with metallic compounds, including manganese-based additives.
  • Page 339 Maintenance and Specifications It is best not to alternate repeatedly between gasoline and E85. If you do switch fuels, it is recommended that you add as much fuel as possible—at least half a tank. Do not add less than five gallons (18.9L) when refueling.
  • Page 340 Maintenance and Specifications Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the right fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.

  • Page 341: Essentials Of Good Fuel Economy

    Maintenance and Specifications 1. Locate the white plastic funnel. It is attached to the underside of the spare tire cover or is included with the tire changing tools. 2. Slowly insert the funnel into the Easy Fuel™ system. 3. Fill the vehicle with fuel from the portable fuel container.
  • Page 342 Maintenance and Specifications For consistent results when filling the fuel tank: • Turn the engine/ignition switch to the off position prior to refueling, an error in the reading will result if the engine is left running. • Use the same filling rate setting (low — medium — high) each time the tank is filled.
  • Page 343 Maintenance and Specifications Habits • Smooth, moderate operation can yield up to 10% savings in fuel. • Steady speeds without stopping will usually give the best fuel economy. • Idling for long periods of time (greater than one minute) may waste fuel.

  • Page 344: Emission Control System

    If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
  • Page 345 Maintenance and Specifications Illumination of the service engine soon indicator, charging system warning light or the temperature warning light, fluid leaks, strange odors, smoke or loss of engine power could indicate that the emission control system is not working properly. An improperly operating or damaged exhaust system may allow exhaust to enter the vehicle.
  • Page 346 Maintenance and Specifications electrical system dry out. After three driving cycles without these or any other temporary malfunctions present, the service engine soon indicator should stay off the next time the engine is started. A driving cycle consists of a cold engine startup followed by mixed city/highway driving.

  • Page 347: Power Steering Fluid

    Maintenance and Specifications Allow the vehicle to sit for at least eight hours without starting the engine. Then, start the engine and complete the above driving cycle. The engine must warm up to its normal operating temperature. Once started, do not turn off the engine until the above driving cycle is complete. If the vehicle is still not ready for I/M testing, the above driving cycle will have to be repeated.

  • Page 348: Transmission Fluid

    Maintenance and Specifications TRANSMISSION FLUID Checking automatic transmission fluid The automatic transmission does not have a transmission fluid dipstick. Refer to your scheduled maintenance information for scheduled intervals for fluid checks and changes. Your transmission does not consume fluid. However, the fluid level should be checked if the transmission is not working properly, (i.e., if the transmission slips or shifts slowly) or if you notice some sign of fluid leakage.
  • Page 349 Maintenance and Specifications 2. Unlock the locking clip on the connector (connector shown from below for clarity), then squeeze and pull the connector off of the air outlet tube. 3. Clean the area around the air tube to air cover connection to prevent debris from entering the system and then loosen the bolt on the air tube clamp so the clamp is...
  • Page 350 Maintenance and Specifications 6. Remove the air filter element from the air filter housing. 7. Install a new air filter element. 8. Replace the air filter housing cover and secure the clamps. Be careful not to crimp the filter element edges between the air filter housing and cover and ensure that the tabs on the edge are properly aligned into the slots.

  • Page 351: Vehicle Storage

    Maintenance and Specifications Note: Failure to use the correct air filter element may result in severe engine damage. The customer warranty may be void for any damage to the engine if the correct air filter element is not used. VEHICLE STORAGE If you plan on storing your vehicle for an extended period of time (30 days or more), refer to the following maintenance recommendations to ensure your vehicle stays in good operating condition.
  • Page 352 Note: During extended periods of vehicle storage (30 days or more), fuel may deteriorate due to oxidation. Add Motorcraft Gas Stabilizer or equivalent meeting Ford material specification ESE-M99C112-A to the vehicle fuel system whenever actual or expected storage periods exceed 30 days.

  • Page 353: Part Numbers

    Replace the spark plugs with ones that meet Ford material and design specifications for your vehicle, such as Motorcraft or equivalent replacement parts. The customer warranty may be void for any damage to the engine if such spark plugs are not used.

  • Page 354: Maintenance Product Specifications And Capacities

    Maintenance and Specifications https://www.MyCarManual.com 2011 Expedition (exd) Owners Guide, 1st Printing USA (fus)
  • Page 355 Maintenance and Specifications https://www.MyCarManual.com 2011 Expedition (exd) Owners Guide, 1st Printing USA (fus)
  • Page 356 Maintenance and Specifications https://www.MyCarManual.com 2011 Expedition (exd) Owners Guide, 1st Printing USA (fus)
  • Page 357 Maintenance and Specifications https://www.MyCarManual.com 2011 Expedition (exd) Owners Guide, 1st Printing USA (fus)

  • Page 358: Engine Data

    Maintenance and Specifications ENGINE DATA Engine 5.4L V8 Engine Cubic inches Fuel 87 octane or (E-85) Firing order 1-3-7-2-6-5-4-8 Ignition system Coil on plug Spark plug gap 0.039–0.043 inch (1.05 +/– 0.05mm) Compression ratio 9.8:1 https://www.MyCarManual.com 2011 Expedition (exd) Owners Guide, 1st Printing USA (fus)

  • Page 359: Identifying Your Vehicle

    Maintenance and Specifications Engine drivebelt routing IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure (B-Pillar) by the trailing edge of the driver’s...
  • Page 360 Maintenance and Specifications Vehicle identification number (VIN) The vehicle identification number is located on the driver side instrument panel. XXXXXXXXXXXXXXXXX Please note that in the graphic, XXXX is representative of your vehicle identification number. The Vehicle Identification Number (VIN) contains the following information: 1.

  • Page 361: Transmission Code Designations

    Maintenance and Specifications TRANSMISSION CODE DESIGNATIONS You can find a transmission code on the Safety Compliance Certification Label. The following table tells you which transmission each code represents. Description Code Six-speed automatic (6R80 ) https://www.MyCarManual.com 2011 Expedition (exd) Owners Guide, 1st Printing USA (fus)

  • Page 362: Accessories

    FORD CUSTOM ACCESSORIES FOR YOUR VEHICLE A wide selection of Ford Custom Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
  • Page 363 Ford Motor Company engineering requirements. Contact your Ford dealer for details regarding the manufacturer’s limited warranty and/or a copy of the FLA product limited warranty offered by the accessory manufacturer.

  • Page 364: Ford Esp Extended Service Plans (U.s. Only)

    FORD ESP EXTENDED SERVICE PLANS (U.S. ONLY) More than 30 million Ford, Lincoln, and Mercury owners have discovered the powerful protection of Ford ESP. It is the only extended service plan backed by Ford Motor Company, and provides “peace of mind”...
  • Page 365 Ford ESP Can Quickly Pay for Itself One service bill – the cost of parts and labor – can easily exceed the price of your Ford ESP Service Contract. With Ford ESP, you minimize your risk for unexpected repair bills and rising repair costs.
  • Page 366 Ford Extended Service Plan https://www.MyCarManual.com 2011 Expedition (exd) Owners Guide, 1st Printing USA (fus)

  • Page 367: Ford Esp Extended Service Plans (Canada Only)

    Ford Motor Company dealers. For more information, visit your local Ford of Canada dealer or www.ford.ca to find the Ford Extended Service Plan that is right for you. NOTE: Repairs performed outside of Canada and the United States are not eligible for Ford ESP coverage.

  • Page 368: Scheduled Maintenance Guide

    Every manufacturer develops these systems using different specifications and performance features. That’s why it’s important to rely upon your Ford or Lincoln Mercury dealership to properly diagnose and repair your vehicle. Ford Motor Company has recommended maintenance intervals for various parts and component systems based upon engineering testing.
  • Page 369 Lincoln Mercury dealership for all your vehicle’s needs. Get the most from your service and maintenance visits There are a lot of reasons why visiting your Ford or Lincoln Mercury dealership for all your service needs is a great way to help keep your vehicle running great.

  • Page 370: Which Maintenance Schedule Should You Follow

    With factory-trained technicians, and one-stop service from routine maintenance like oil changes and tire rotations to repairs like brake service, check out the value your Ford and Lincoln Mercury dealers can offer. WHICH MAINTENANCE SCHEDULE SHOULD YOU FOLLOW?
  • Page 371 Inspect accessory drive belt(s). ❑ Inspect clutch operation, if equipped. Be sure to ask your Ford or Lincoln Mercury dealership service advisor or technician about the multi-point vehicle inspection. It’s a comprehensive way to perform a thorough inspection of your vehicle. It’s your checklist that gives you immediate feedback on the overall condition of your vehicle.
  • Page 372 Scheduled Maintenance Guide as well as those things that may require future or immediate attention. The multi-point vehicle inspection is one more way to keep your vehicle running great! https://www.MyCarManual.com 2011 Expedition (exd) Owners Guide, 1st Printing USA (fus)

  • Page 373: Normal Scheduled Maintenance And Log

    Scheduled Maintenance Guide NORMAL SCHEDULED MAINTENANCE AND LOG The following section contains the “Normal Schedule”. This schedule is presented at specific mileage (kilometer) intervals with exceptions noted. https://www.MyCarManual.com 2011 Expedition (exd) Owners Guide, 1st Printing USA (fus)
  • Page 374 Scheduled Maintenance Guide https://www.MyCarManual.com 2011 Expedition (exd) Owners Guide, 1st Printing USA (fus)
  • Page 375 Scheduled Maintenance Guide https://www.MyCarManual.com 2011 Expedition (exd) Owners Guide, 1st Printing USA (fus)
  • Page 376 Scheduled Maintenance Guide Every 15,000 miles Replace cabin air filter (if equipped) (24,000 km) Every 30,000 miles Replace climate-controlled seat filter (if equipped) (48,000 km) Replace engine air filter Replace fuel filter (Ranger) Every 37,500 miles Inspect valve clearances; adjust as necessary (60,000 km) (Transit Connect CNG vehicles) Every 60,000 miles...
  • Page 377 Scheduled Maintenance Guide Maintenance schedule log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#:...
  • Page 378 Scheduled Maintenance Guide EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS...
  • Page 379 Scheduled Maintenance Guide EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS...

  • Page 380: Special Operating Conditions

    Scheduled Maintenance Guide SPECIAL OPERATING CONDITIONS If you operate your Ford/Lincoln/Mercury vehicle primarily in one of the more demanding Special Operating Conditions listed below, you will need to have some items maintained more frequently. If you only occasionally operate your vehicle under these conditions, it is not necessary to perform the additional maintenance.
  • Page 381 Scheduled Maintenance Guide Extensive idling and/or low-speed driving for long distances as in heavy commercial use such as delivery, taxi, patrol car or livery Inspect frequently, service as – Replace cabin air filter (if equipped) required – Replace engine air filter Every 5,000 miles (8,000 km) –...
  • Page 382 Scheduled Maintenance Guide Operating in dusty conditions such as unpaved or dusty roads Inspect frequently, service as – Replace cabin air filter (if equipped) required – Replace engine air filter Every 5,000 miles (8,000 km) – Inspect wheels and related components for abnormal noise, wear, looseness or drag –...
  • Page 383 Scheduled Maintenance Guide Off-road operation Inspect frequently, service as – Inspect steering linkage, ball joints and U-joints; required lubricate if equipped with grease fittings – Replace cabin air filter (if equipped) – Replace engine air filter Every 5,000 miles (8,000 km) or –...
  • Page 384 Scheduled Maintenance Guide Special operating condition log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#:...
  • Page 385 Scheduled Maintenance Guide EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS...
  • Page 386 ❑ Rear axles and power take-off (PTO) units containing synthetic lubricant and light duty trucks equipped with Ford-design axles are lubricated for life. These lubricants are not to be checked or changed unless a leak is suspected, service is re- quired or the axle assembly has been submerged in water.

  • Page 387: Coolant Change Record

    ❑ If operating conditions are normal and you drive your Ford, Lincoln or Mercury vehicle under typical, everyday conditions and you are using an API performance category oil of SL or later (for example SM, etc.) then you can follow the 7,500 mile (12,000 km) normal service oil change intervals schedule.
  • Page 388 Scheduled Maintenance Guide Engine coolant change log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#:...

  • Page 389: Index

    Index Axle lubricant specifications ..354 refill capacities ......354 ABS (see Brakes) .....244 Accessory delay ......91 AdvanceTrac ......246 Battery ........326 Air cleaner filter ....348, 353 acid, treating emergencies ..326 Air suspension ......252 jumping a disabled battery ..296 description ......252 maintenance-free ....326 replacement, specifications ...353 Airbag supplemental servicing ........326...
  • Page 390 Cruise control idle speed control ....326 (see Speed control) ....96 lubrication specifications ..354 Customer Assistance ....275 refill capacities ......354 Ford Extended Service service points ......320 Plan ........364, 367 starting after a collision ..277 Getting assistance outside the Engine block heater ....241 U.S.
  • Page 391 Index filter, specifications ..325, 353 safety information relating to recommendations ....325 automotive fuels .....334 refill capacities ......354 Fuel - flex fuel vehicle specifications ......354 (FFV) .........334, 338 Event data recording ....7 Fuses ........278–279 Exhaust fumes ......241 Garage door opener ....101 Fail safe cooling ......332 Gas cap (see Fuel cap) ....337 Fleet MyKey programming ..115...
  • Page 392 Index Inspection/maintenance (I/M) anti-lock brakes (ABS) ..244 testing ........346 Limited-slip axle .......253 Instrument panel Load limits .........223 cleaning ........313 cluster ........12 Loading instructions ....230 lighting up panel and interior ........73 Locks autolock ........120 childproof ........124 doors ........120 Jack ..........286 Lubricant specifications ...354 positioning .......286 storage ........286 Lug nuts ........295...
  • Page 393 Index illuminated entry ....129 locking/unlocking Parental MyKey doors ........125–126 programming ......115 opening the trunk ....126 Parking brake ......245 panic alarm ......127 Parts replacement/additional (see Motorcraft parts) ...353 transmitters ......129 replacing the batteries ...128 Pedals (see Power adjustable foot pedals) .........94 Reverse sensing system ...260 Power adjustable foot pedals ..94 Roadside assistance ....275...
  • Page 394 Index What Maintenance Schedule Tire Pressure Monitoring Should You Follow? ....370 System (TPMS) Driving ........270 Seats ..........138 child safety seats ....187 Tires, Wheels and Loading ..219 cleaning ........316 Warning Displays ..12, 26, 35 climate control ......147 Tires ......204–206, 286 heated ........155 alignment ........213 memory seat ....127, 145 care ..........209...
  • Page 395 Index Water, Driving through .....274 Windows Vehicle Identification Number power .........89 (VIN) ..........360 rear wiper/washer .....84 Vehicle loading ......223 Windshield washer fluid and Ventilating your vehicle ...241 wipers ..........82 checking and adding fluid ..321 liftgate reservoir .....321 replacing wiper blades ...322 Warning lights (see Lights) ..12 Wrecker towing ......300 Washer fluid ......321...

Table of Contents
