SANUS VuePoint FPA405 Instruction Manual

Hide thumbs Also See for FPA405:
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Download this manual
FPA405
INSTRUCTION MANUAL
We'll Make It Stress-Free
If you have any questions along the way, just give us a call:
1-888-333-9952 We're ready to help!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FPA405 and is the answer not in the manual?

Questions and answers

Related Manuals for SANUS VuePoint FPA405

Summary of Contents for SANUS VuePoint FPA405

  • Page 1 FPA405 INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call: 1-888-333-9952 We’re ready to help!

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS PLEASE READ ENTIRE MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS Before You Begin Please verify the following items:  Your TV, soundbar, soundbar mount, and any accessories you plan to install DO NOT EXCEED the specifi ed weight limit of your TV wall mount.
  • Page 3 WARNING: • This soundbar mount is only designed for use with TV wall mounts that meet third party safety certifi cations. • This soundbar mount is ONLY designed to mount BELOW the television (see Figure 3). • This soundbar mount is designed to be installed and utilized only as specifi ed in this manual. The manufacturer is not responsible for improper assembly, use, or handling of this product.

  • Page 4: Weight Restrictions

    Weight Restrictions Weight Limit for SOA-SBM1 DO NOT EXCEED 15 lbs. (6.8 kg) 15 lb for this Soundbar Mount (6.8 kg) Weight Limit for Your TV Mount CAUTION: Avoid potential personal injuries and property damage! The weight of your TV, PLUS this soundbar mount, your soundbar, and any accessories, MUST BE LOWER than the maximum weight rating of your TV mount.

  • Page 5: Items Needed

    Items Needed Phillips Screwdriver Level Party Certifi ed TV Wall Mount * Included in this Kit *Your TV wall mount may vary from the 3/16 in. Hex Key illustrations throughout this manual — note that the procedure to install the soundbar is the same.
  • Page 6 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
  • Page 7 Parts and Hardware for STEP 3 Mount Spacer NEW Washers for your TV Mount Interface Bracket Washer Washer M4/M5 M6/M8 Washer Washer LARGE LARGE M4/M5 M6/M8...
  • Page 8 Parts and Hardware for STEP 3 (continued) NEW TV Screws for TVs that DO NOT use spacers M4 x 16mm M5 x 16mm M6 x 16mm M6 x 25mm M8 x 20mm...
  • Page 9 NEW TV Screws and Spacers for TVs that REQUIRE spacers M4 x 40mm M5 x 40mm M6 x 40mm M6 x 50mm TV Spacers 22mm M8 x 40mm...
  • Page 10 Install Soundbar Bracket * STEP 1 Using a Soundbar Manufacturer’s Supplied Hanger OPTION If your Soundbar did NOT include a supplied hanger, see OPTION 2 on PAGE 12 Attach the soundbar brackets to your soundbar’s hanger with knobs keyhole screws NOTE: Do not fully tighten the knobs until STEP 5.
  • Page 11 Bottom of Soundbar Hanger SOUNDBAR MANUFACTURER SUPPLIED HANGER...
  • Page 12 Install Soundbar Bracket STEP 1 Directly to the Soundbar OPTION Assemble knobs and keyhole screws Attach the soundbar brackets your soundbar using the knob assemblies. NOTE: Do not fully tighten the knobs until STEP 5. IMPORTANT: If needed, use fender washers under soundbar bracket to rest fl...
  • Page 13 Bottom of Soundbar...
  • Page 14 Prepare Your TV (if mounted) STEP 2 If your TV is already mounted: CAUTION: Follow your TV mount’s manual for instructions on how to safely remove your TV and TV bracket. Remove any cables attached to your TV. Remove your TV/bracket assembly from your wall plate, arm assembly, or pillar.
  • Page 16 Install Soundbar Bracket with Your TV Mount STEP 3 Determine which screw diameter Step 3-1 Step 3-2 fits your monitor or TV — M4, M5, M6, or M8. • For TVs with a fl at/ unobstructed back, follow Step 3-1. •...
  • Page 17 IMPORTANT: To offset the shift in Standard confi gurations shown. height of your TV bracket, due to the For special applications, contact soundbar brackets , you MUST use Customer Service. washers , in the top hole locations. Step 3-1 Step 3-2 CAUTION: Verify adequate thread engagement with...
  • Page 18 M4/M5 M6/M8 STEP 3-1 10 11 12 13 14 screws 06 08 07 09 washers Assemble your TV mount’s interface bracket with soundbar brackets washers and the four TV screws and washers from the table above. WARNING: You must use the larger washers (unless they do not fi...
  • Page 19 M4/M5 M6/M8 STEP 3-2 15 16 17 18 19 screws 06 08 07 09 washers Assemble your TV mount’s interface bracket with soundbar brackets , washers , spacers and the four TV screws and washers from the table above. WARNING: You must use the larger washers (unless they do not fi...
  • Page 20 Adjust Soundbar Bracket STEP 4 Adjust both arms of soundbar brackets until your soundbar or soundbar hanger is in your desired position. NOTE: You may need to reposition the hole locations in soundbar brackets to adjust your soundbar to the desired position. IMPORTANT: The fi...
  • Page 21 Option 1 Option 2 ≤ 51 mm (2 in.) ≤ 51 mm (2 in.)
  • Page 22 (continued) STEP 4 CAUTION: The MIDDLE connection of soundbar brackets must not extend beyond the edge of the TV. 01 01...
  • Page 23 soundbar brackets NOTE: The should be positioned as vertically as possible.
  • Page 24 Tighten Connections STEP 5 Once your soundbar or soundbar hanger is in the desired position, tighten ALL screw and knob connections. IMPORTANT! Do not over-tighten the screws — this will deform the washers.
  • Page 25 Hang Your TV/Soundbar Assembly STEP 6 Follow your TV wall mount installation manual to hang your TV assembly. Option 1 Option 2...

  • Page 26: Antes De Comenzar

    ESPAÑOL INSTRUCCIONES DE SEGURIDAD IMPORTANTES LEA EL MANUAL COMPLETO ANTES DE UTILIZAR ESTE PRODUCTO – CONSERVE ESTAS INSTRUCCIONES Antes de comenzar Verifi que los siguientes puntos:  Que su televisor, la barra de sonido, la montura de barra de sonido y cualquier accesorio que vaya a instalar NO EXCEDAN el límite de peso especifi...
  • Page 27 ESPAÑOL ADVERTENCIA: • Esta montura de barra de sonido ha sido diseñada exclusivamente para su uso con soportes de pared para televisores que cumplan las certifi caciones externas de seguridad. • Esta montura de barra de sonido ha sido diseñada EXCLUSIVAMENTE para colocarse DEBAJO del televisor (consulte la Figura 3).
  • Page 28 ESPAÑOL Restricciones de peso PÁGINA 4 NO EXCEDA los 6,8 kg (15 lb) en la 6,8 kg Límite de peso de SOA-SBM1 montura de barra de sonido (15 lb) Límite de peso de su soporte para televisor PRECAUCIÓN: Evite posibles lesiones personales y daños materiales. El peso del televisor, MÁS la montura de la barra de sonido, la barra de sonido y los accesorios DEBE SER MENOR que el peso máximo permitido para el soporte del televisor.

  • Page 29: Piezas Necesarias

    Piezas necesarias ESPAÑOL PÁGINA 5 *El soporte de pared para su televisor puede variar de las Este kit incluye ilustraciones que aparecen en este manual. Tenga en cuenta que el procedimiento de instalación de la barra de sonido no varía. Piezas y elementos de sujeción suministrados PÁGINA 6 ADVERTENCIA:...
  • Page 30 ESPAÑOL Instale el soporte de la barra de sonido * PASO 1 Utilizar el soporte de la barra de PÁGINA 10 OPCIÓN sonidoproporcionado por el fabricante Si su barra de sonido NO incluye soporte, consulte la OPCIÓN 2 en la PÁGINA 12 Acople los soportes de la barra de sonido al soporte de la misma con las perillas los tornillos de las ranuras...
  • Page 31 ESPAÑOL IMPORTANTE: Si lo necesita, use arandelas de protección bajo el soporte de la barra de sonido para mantener plana la superfi cie. Prepare su televisor (si está instalado) PASO 2 PÁGINA 14 Si su televisor ya está instalado en un soporte: PRECAUCIÓN: Siga las instrucciones del manual de instalación para retirar de forma segura su televisor y el soporte del mismo.
  • Page 32 ESPAÑOL PÁGINA 16 PASO 3 Instale el soporte de la barra de sonido con el de su televisor Determine el diámetro de los tornillos para su monitor y su tipo de televisor: M4, M5, M6, o M8. • Para televisores con dorso plano/libre de obstrucciones, siga el Paso 3-1. * •...
  • Page 33 PASO 3-1 PÁGINA 18 ESPAÑOL Monte el soporte de acoplamiento de su montura para televisor con los soportes de la barra de sonido , arandelas y los cuatro tornillos y arandelas para el televisor de la tabla anterior. ADVERTENCIA: Debe usar las arandelas más grandes , a menos que no sean adecuadas para el soporte del televisor.
  • Page 34 ESPAÑOL PASO 4 Ajuste el soporte de la barra de sonido PÁGINA 20 Ajuste los dos brazos de los soportes de la barra de sonido hasta que esta o su soporte se encuentren en la posición deseada. NOTA: Posiblemente necesite reubicar los orifi cios de los soportes de la barra de sonido para ajustarla a la posición deseada.
  • Page 35 ESPAÑOL PASO 5 PÁGINA 24 Cuando la barra de sonido o su soporte se encuentre en la posición deseada, ajuste TODAS las conexiones de tornillos y perillas. ¡IMPORTANTE! No ajuste en exceso los tornillos ya que podría deformar las arandelas. PASO 6 PÁGINA 25 Siga las instrucciones del manual de instalación del soporte de pared para televisor para...

  • Page 36: Customer Service

    Customer Service 888-333-9952 info@sanus.com Leave a review: vuepoint sanus.com 0800-056-2853 Milestone AV Technologies and its affi liated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions, or variations.
