- Page 1 F107d INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call. 1-888-333-9952. We’re ready to help! Scan for easy install video san.us/793...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE Before getting started, let’s make sure this mount is perfect for you! Does your TV weigh more than 35 lb (15.9 kg) including accessories? No — Perfect! 35 lb (15.9 kg) Yes —...
- Page 3 Dimensions NOTE: TV shifts 4.3 in. (10.8 cm) [cm] to the right or left when in the home position. Consider this when selecting the location of your wall mount. [20.0] [10.0] 16º 16º [10.8] [7.5] [6.5] [7.5] [10.0] [20.0] [18.3] [7.5] [20.0] [19.3]...
-
Page 4: Step 1 Parts And Hardware
Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used. - Page 5 STEP 2 Parts and Hardware STEP 3 Parts and Hardware Washer Locking Screw Wall Plate Template Wall Plate Assembly 8-32 x 3/8 in. 8-32 Cable Ties Concrete Installation Kit CMK1 (not included) Contact Customer Service at 1-888-333-9952 to have these additional pieces shipped directly to you. Lag Bolts 5/16 x 2¾...
- Page 6 STEP 1 Attach TV Bracket to TV 1-1 Measure Your TV Hole Pattern 1-2 Assemble Your TV Bracket Measure the width and height of your TV hole pattern in cm. Determine which TV bracket configuration to use, A, B, or C based on your TV hole pattern measurements.
- Page 7 20.0 x 20.0 20.0 x 10.0 20.0 20.0 10.0 20.0 Assemble TV bracket extenders onto TV bracket Assemble TV bracket extenders onto TV bracket illustrated. illustrated. Secure using eight screws in the corner holes shown. Secure using eight screws in the corner holes shown.
- Page 8 1-3 Select TV Screw 1-4 Select TV Screw Length Standard configurations Diameter are shown. For special If your TV has a flat back AND you want your TV closer to applications, or if you Hand thread screws into the the wall, use the shorter screws. are uncertain about your threaded inserts on the back hardware selection,...
- Page 9 1-5 Attach TV Bracket Position your TV bracket configuration (A or B) over your TV hole pattern - making sure the bracket is centered over the TV hole pattern and level. Secure bracket using your screw/washer (Flat Back) or spacer/screw/washer (Round Back / Extra Space) selection.
- Page 10 STEP 2A Attach Wall Plate - Wood Stud CAUTION: Avoid potential personal injuries and property damage! ● Drywall covering the wall must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm) Locate your stud.
- Page 11 Install wall plate assembly using two lag bolts . Tighten the lag bolts only until they are pulled firmly against the wall plate. CAUTION: Improper use could reduce the holding power of the lag bolt. DO NOT over-tighten the lag bolts. NOTE: If needed, you can make small level adjustments to the wall plate by loosening the bottom lag bolt and shifting the wall plate until level.
- Page 12 STEP 2B Attach Wall Plate - Solid Concrete / Concrete Block CAUTION: Avoid potential personal injuries and property damage! Concrete Installation Kit CMK1 is not included ● Mount the wall plate assembly directly onto the concrete surface (see page 5) Contact Customer Service ●...
- Page 13 Remove the wall plate template and insert two anchors (Fischer UX 10 x 60 - included in the Concrete Installation Kit CMK1*). CAUTION: Be sure the anchors are seated flush with the concrete surface. using two lag bolts and two washers (use only the lag bolts and washers from the Concrete Install wall plate assembly Installation Kit CMK1*).
- Page 14 STEP 3 Hang TV onto Wall Plate HEAVY! You may need assistance with this step. Hang the TV onto the arm of wall plate assembly by first hooking the top support, then resting the TV into place. Lock the TV to the wall plate assembly with locking screw and washer IMPORTANT: This locking screw...
-
Page 15: Manage Cables
Manage Cables Cables can be routed through the cable channel on the top of the arm of the wall plate assembly for a cleaner look. - Page 16 TV Adjustments TILT ADJUSTMENT LEVEL ADJUSTMENT Your TV should adjust easily when moved, then stay in place. To adjust the leveling of your TV, loosen the locking screw , level your TV, then tighten locking screw If your TV is too loose or too tight, adjust the tilt tension IMPORTANT: This locking screw knob by hand.
- Page 17 REMOVING THE TV HEAVY! You may need assistance with this step. , disconnect all cables and then reverse the procedures in STEP 3. To remove your TV from the wall plate assembly...
- Page 18 Features 20.0 10.0 20.0 10.0 TV bracket can be confi gured to fi t TV hole patterns from 7.5 x 7.5 cm up to 20.0 x 20.0 cm...
- Page 19 Adjustments allow fi ngertip control Fully articulating arm of TV or restriction of TV movement creates 2-point movement for optimal viewing position TV tilts up or down for the perfect viewing angle Cable channel holds cables along mount arm for a clean look Level adjustments create a...
- Page 20 ESPAÑOL INSTRUCCIONES DE SEGURIDAD IMPORTANTES. CONSÉRVELAS. LEA TODO EL MANUAL ANTES DE UTILIZAR ESTE PRODUCTO. Antes de comenzar, verifiquemos que este soporte sea perfecto para usted. ¿Su televisor pesa más de 15.9 kg (35 libras), incluidos los accesorios? (15.9 kg) No —...
- Page 21 ESPAÑOL Piezas y accesorios suministrados ADVERTENCIA: Este producto contiene piezas pequeñas que, si fuesen tragadas, podrían producir asfixia. Antes de iniciar el ensamblaje, compruebe que todas las piezas estén incluidas y en buenas condiciones. Si faltan piezas o alguna está dañada, no devuelva el artículo al distribuidor; póngase en contacto con el servicio de atención al cliente. Nunca utilice piezas deterioradas.
- Page 22 ESPAÑOL 1-3 Seleccione el diámetro 1-4 Seleccione el largo de los tornillos para el de los tornillos para el televisor televisor PRECAUCIÓN: Enrosque manualmente los Si el dorso del televisor es plano, utilice los tornillos cortos. tornillos en los encastres Verifique que el tornillo o la combinación roscados del dorso del televisor de tornillo y espaciador enrosquen...
- Page 23 ESPAÑOL Instale el módulo de la placa mural usando dos tornillos tirafondo . Ajuste los tornillos tirafondo solamente hasta que queden firmes contra la placa mural. PRECAUCIÓN: El uso indebido podría reducir la capacidad de retención de los tornillos tirafondo. NO ajuste en exceso los tornillos tirafondo.
- Page 24 ESPAÑOL PASO 3 Colgar el televisor en la placa mural ¡ELEMENTO PESADO! Es posible que necesite ayuda en este paso. Para colgar el televisor en el brazo del módulo de la placa mural , primero enganche el soporte superior y luego apoye el televisor en su lugar.
-
Page 25: Ajustes Del Televisor
ESPAÑOL Ajustes del televisor AJUSTE DE LA INCLINACIÓN AJUSTE DEL NIVEL El televisor debe acomodarse fácilmente al moverlo, y luego Para ajustar la nivelación de su televisor, afloje el tornillo de quedar en su lugar. seguridad , nivele el televisor, y luego ajuste el tornillo de Si el televisor está... - Page 26 ESPAÑOL Descripción Los ajustes permiten el control El brazo completamente manual o la restricción del articulado crea un movimiento movimiento del televisor. de 2 puntos para alcanzar una posición de visualización óptima. El televisor se inclina hacia arriba / abajo para obtener el ángulo de Los canales para visualización perfecto.
- Page 28 Thank you for choosing Sanus Vuepoint! Please take a moment to let us know how we did: Call us: 1-888-333-9952 Email us: info@sanus.com Leave a review: vuepoint.sanus.com Milestone AV Technologies and its a liated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete.
