- Page 1 F180d INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call. 1-888-333-9952. We’re ready to help! Scan for easy install video san.us/964...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE Before getting started, let’s make sure this mount is perfect for you! Does your TV weigh more than 100 lbs. (45.4 kg) including accessories? No — Perfect! 100 lbs.
- Page 3 Dimensions NOTE: TV shifts 3 in. (7.61 cm) to the right or left when in the home [cm] 23.62 position. Consider this when select- 60.00 ing the location of your wall mount. 15.75 3.00 OFFSET 40.00 7.87 7.61 20.00 3.94 10.00 12°...
- Page 4 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer;...
-
Page 5: Step 2 Parts And Hardware
STEP 3 Parts and Hardware STEP 2 Parts and Hardware Wall Plate Template Arm Assembly Wall Plate Wall plate Screw 10-24 x 1 in. Locking Screw Lag Bolt Washers 1/4-20 x 3/4 in. .695 x .350 x.075 in. Lag Bolts 5⁄16 in. -
Page 6: Additional Hardware
Additional Hardware Cable Ties Cable Tunnel Kit 2.5 in. (63.4 mm) 18 in. (457.2 mm) - Page 7 STEP 1 Attach TV Bracket to TV 1-1 Measure Your TV Hole Pattern Measure the width and height of your TV hole pattern in cm. Record your measurements: Width __________cm x Height ________ cm 75 mm = 7.5 cm ≈ 3 in. 100 mm = 10 cm ≈...
- Page 8 1-2 Assemble Your TV Bracket 30.0 x 30.0 40.0 x 40.0 Determine which TV bracket configuration to use, A, B, C, or D 15.75 [cm] based on your TV hole pattern measurements. [40.0] 11.81 [30.0] 7.87 15.75 [20.0] [cm] 3.94 [40.0] 7.5 x 7.5 [10.0]...
- Page 9 60.0 x 40.0 40.0 x 20.0 23.62 15.75 [60.0] [40.0] 7.87 [20.0] 15.75 [40.0] 7.87 [20.0] 15.75 20.0 x 40.0 [40.0] [cm] [cm] Assemble TV bracket extenders onto TV bracket as illustrated. Assemble TV bracket extenders onto TV bracket as illustrated. Secure using eight screws in the corner holes shown.
- Page 10 1-3 Select TV Screw Diameter 1-4 Select TV Screw Length Standard configurations are shown. For special applications, or if you If your TV has a flat back AND you want your TV closer to the Hand thread screws into the threaded inserts are uncertain about your wall, use the shorter screws.
- Page 11 1-5 Attach TV Bracket Position your TV bracket configuration (A, B, C, or D) over your TV hole pattern - making sure the bracket is centered over the TV hole pattern and level. Secure bracket using your screw/washer (Flat Back) or spacer/screw/washer (Round Back / Extra Space) selection. IMPORTANT: Ensure TV bracket is securely fastened before moving on to the next step.
-
Page 12: Step 2 Attach Wall Plate To Wall
STEP 2 Attach Wall Plate to Wall CAUTION: Avoid potential personal injuries and property damage! ● Drywall covering the wall must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm) Locate your stud. - Page 13 Drill pilot holes using a 7/32 in. (5.5 mm) diameter drill bit. Remove wall plate template IMPORTANT: Be sure to drill into the center of the stud. IMPORTANT: Pilot holes must be drilled to a depth of 3 in. (75 mm). Install wall plate using washers and lag bolts...
-
Page 14: Step 3 Attach Tv To Wall Plate
STEP 3 Attach TV to Wall Plate HEAVY! You may need assistance with this step. Hang the arm onto the wall plate by first hooking the top support, then resting the arm into place. Install wall plate screws to secure arm to wall plate NOTE: Arm can slide side-to-side along the wall plate for perfect positioning. - Page 15 HEAVY! You may need assistance with this step. Fold first section of the arm against the wall plate to provide stability. Hang the TV bracket onto the arm by first hooking the top support, then resting the TV into place.
- Page 16 Secure the TV bracket to the arm with locking screw IMPORTANT: This locking screw must be installed to secure the TV bracket onto the arm...
- Page 17 Manage Cables - Cable Ties Cables can be routed through the cable channels on the top and bottom of the arm and secured to the arm with cable ties for a cleaner look.
- Page 18 Manage Cables - Cable Tunnel NOTES: Space clips evenly along the length of the tunnel(s) ● This product is NOT recommended for brick, plaster, or wallpa- with a clip near each end. To combine tunnels, use the long pered walls. clip to connect where they meet.
- Page 19 Carefully lift tunnel assembly and position it at the desired location making sure it is level. Peel the tunnels away from Press firmly for 10 the clips seconds at each clip Arrange your wires on either location along the side of the clips.Reattach length of the assembly the tunnels to the clips...
- Page 20 TV Adjustments TILT ADJUSTMENT LEVEL ADJUSTMENT REMOVING THE TV Your TV should adjust easily when moved, To adjust the leveling of your TV, loosen To remove your TV from the arm assembly then stay in place. , disconnect all cables and then reverse the locking screw , level your TV, then If your TV is too loose or too tight, adjust the...
