THERMAL CURVES

Figure 32: Temperature measurement location
* The allowed maximum hot spot temperature is defined at 125
IPM24S (Standard) Output Current vs. Ambient Temperature and Air Velocity
@ Vin=24V, Vout = 6.5V (Either Orientation)
Output Current(A)
3
Natural
Convection
2
100LFM
200LFM
1
0
60 65 70
Figure 33: Output current vs. ambient temperature and air velocity
@Vin=24V, Vout=6.5V(Either Orientation)
IPM24S (Standard) Output Current vs. Ambient Temperature and Air Velocity
@ Vin=24V, Vout =5V (Either Orientation)
Output Current(A)
3
Natural
Convection
2
100LFM
1
0
60 65 70
Figure 34: Output current vs. ambient temperature and air velocity
@Vin=24V, Vout=5V(Either Orientation)
DS_IPM24S0B0_03202007
℃
.
75 80 85
Ambient Temperature (℃)
75 80 85
Ambient Temperature (℃)
IPM24S (Standard) Output Current vs. Ambient Temperature and Air Velocity
@ Vin=24V, Vout =4V (Either Orientation)
Output Current(A)
3
Natural
Convection
2
1
0
60 65 70
Figure 35: Output current vs. ambient temperature and air velocity
Vin=24V, Vout=4V(Either Orientation)
IPM24S (Standard) Output Current vs. Ambient Temperature and Air Velocity
@ Vin=24V, Vout =3.3V (Either Orientation)
Output Current(A)
3
Natural
Convection
2
1
0
60 65 70
Figure 36: Output current vs. ambient temperature and air velocity
@Vin=24V, Vout=3.3V(Either Orientation)
75 80 85
Ambient Temperature (℃)
75 80 85
Ambient Temperature (℃)
