Delta Electronics DPS-350TB series Specifications

DPS-350TB
FEATURES
• Application: Desktop PC
• 80mm fan
• Comply with Intel ATX12V 2.0
• Remote On/Off
• Low acoustics noise
• High reliability
• Fan speed control
• Short circuit protection
• Over voltage protection
• Over current protection
• Active PFC
Output Voltage Regulation
V1 +3.3V
±5%
V2 +5V ±5%
V3 +12V ±5%
V4 +12V ±5%
CPU
V5 -12V ±10%
V6 +5Vsb ±5%
1. Total continue power output: 350W
2. The combined power on +3.3V & +5V: 130W max
All specifications are subject to change without prior notice.
DELTA ELECTRONICS, INC.
3, TUNG YUAN ROAD, CHUNGLI
INDUSTRIAL ZONE
TAOYUAN SHIEH, TAIWAN, R.O.C.
TEL: 886-3-4526107
FAX: 886-3-4527314
mail: powersales@delta.com.tw
Series
150 (W) x 86 (H) x 140 (L) mm
ENVIRONMENTAL
• Operating ambient temperature: 10~50 ºC
• Operating relative humidity: 5~95%
• Storage ambient temperature: -40~70ºC
• Storage relative humidity: 5~95%
• Altitude: 10,000~50,000 feet
• MTBF: > 100K hours @ max. load & 25ºC
ambient conditions.
Minimum Maximum
Peak Load
Load Load
0.5A 22.0A -
1.0A 21.0A -
1.0A 11.0A -
1.0A 14.0A -
0.0A 0.5A -
0.0A 2.0A 2.5A
DELTA PRODUCTS CORPORATION
4405 CUSHING PARKWAY
FREMONT, CA 94538, U.S.A.
TEL: 1-510-668-5100
FAX: 1-510-668-0680
ELECTRICAL SPECIFICATIONS
INPUT
• Input Range
• Frequency
• Input Current
• Efficiency
• EMI/RFI
OUTPUT
• Maximum Power
• Holdup Time
• Rise Time
• Leakage Current
• Overvoltage Protection: +3.3V, +5V, +12V, +12V
12V
• Overcurrent Protection: < 240VA
• Short-Circuit Protection: Latch off
Ripple & Noise
• Power Good Signal: TTL compatible on delay 100mS
Vp-p
to 500mS, off delay 1mS.
80mV
100mV
200mV
200mV
200mV
150mV
DELTA ELECTRONICS(JAPAN) INC.
DELTA SHIBADAIMON BLDG.
2-1-14 SHIBADAIMON, MINATO-KU,
TOKYO, 105-0012, JAPAN
TEL: 81-3-5733-1111
FAX: 81-3-5733-1211
90~135Vac/ 180~265Vac
47~63Hz
<8A @ 115Vac, <4A @ 230Vac
>65% @ 115/230Vac
CISPR 22 Class B
350 Watts
>10mS @ 115/230Vac
1~25mS
<0.25mA @ 100Vac
, -
CPU
