SERVICE MANUAL
COLOR TELEVISION
• This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
of TV-SE211<EH>, (S/M Code No. 09-997-417-7T1).
• This Service Manual does not include "NOTICES BEFORE REPAIRING",
"DISASSEMBLY INSTRUCTIONS" and "ADJUSTMENT".
These items will be issued in the next supplement.
TV-SE211
S/M Code No. 09-004-417-7R2
EH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TV-SE211 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa TV-SE211

Summary of Contents for Aiwa TV-SE211

  • Page 1 SERVICE MANUAL COLOR TELEVISION • This Service Manual is the “Revision Publishing” and replaces “Simple Manual” of TV-SE211<EH>, (S/M Code No. 09-997-417-7T1). • This Service Manual does not include “NOTICES BEFORE REPAIRING”, “DISASSEMBLY INSTRUCTIONS” and “ADJUSTMENT”. These items will be issued in the next supplement.

  • Page 2: Specifications

    SPECIFICATIONS Tuner System Frequency synthesized tuner TV System PAL-BG/H Channel Coverage VHF: E2 to E12 ch UHF: E21 to E69 ch CABLES: S1 to S41 ch Program Memory Antenna Input 75 ohms, unbalanced Picture Tube 21" Screen Size 406 (W) X 305 (H) mm (16 X 12 in.) 508 mm (diagonal) (20 in.) Video Input...
  • Page 3 ELETRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION MAIN C.B BT301 8Z-JB4-669-010 CONN ASSY,5P MAIN-NK 8Z-JB4-612-010 IC,TMP87CP38N-LA71 BT401 8Z-JB4-660-010 CONN ASSY,5P 401-481 AUDIO 87-A21-133-080 IC,BMR-0101D BT402 8Z-JB4-661-010 CONN ASSY,6P 402-482 AUDIO 87-A21-106-010 IC,SLA24C04-D BT403 8Z-JB4-662-010...
  • Page 4 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C317 87-A12-001-080 CAP,E 2200-10 M SMG C809 87-016-584-080 CAP,E 220-25 M SSL C318 87-018-134-080 CAPACITOR,TC-U 0.01-16 C810 87-A10-728-080 CAP,E 680-10 M LXV C319 87-016-632-080 CAP,E 0.47-50 M SSL C811 87-018-198-080 CAP,TC-U 2700P-16 X...
  • Page 5 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION L108 87-003-149-080 COIL,47UH J LAL02 C416 87-016-587-080 CAP,E 1000-25 M SSL L109 87-003-134-080 COIL,1.5UH K LAL02 C418 87-010-196-080 CHIP CAPACITOR,0.1-25 L110 8Z-JB4-634-010 COIL,VCO 38.9MHZ C419 87-016-625-080 CAP,E 22-16 M SSL L111 87-003-149-080 COIL,47UH J LAL02...
  • Page 6 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C215 87-010-560-080 CAP,E 10-50 GAS C299 87-A10-189-080 CAP,E 220-10 M C217 87-010-560-080 CAP,E 10-50 GAS J201 87-JB1-615-010 CONN,21P V SCART C218 87-A10-189-080 CAP,E 220-10 M J202 87-JB1-615-010 CONN,21P V SCART C219 87-010-560-080 CAP,E 10-50 GAS...

  • Page 7: Chip Resistor Part Code

    REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION L703 87-005-473-080 COIL,10UH J FLR50 L705 87-005-473-080 COIL,10UH J FLR50 L551 87-005-444-080 COIL 100UH,K L707 87-005-473-080 COIL,10UH J FLR50 PN551 87-009-195-010 CONN,5P B5BEH L708 87-005-485-080 COIL,100UH J FLR50 PN552 87-A60-622-010 CONN,5P 8283 V WHT...

  • Page 8: Transistor Illustration

    TRANSISTOR ILLUSTRATION E C B B E C E C B S D G 2SC3467 2SC4002 2SA1175 2SJ460 2SA1015 2SC3779 2SA950 2SK2541 2SC2785 E C B B C E E C B B C E 2SD2395 SE115 2SC2688 2SC1740 2SD2333 2SC2412K 2SK2158 2SA1307...

  • Page 9: Wiring - 1 (Main)

    WIRING - 1 (MAIN) - 9 -...

  • Page 10: Schematic Diagram - 1 (Main)

    SCHEMATIC DIAGRAM - 1 (MAIN) - 10 -...

  • Page 11: Wiring - 2 (Audio)

    WIRING - 2 (AUDIO) - 11 -...

  • Page 12: Schematic Diagram - 2 (Audio)

    SCHEMATIC DIAGRAM - 2 (AUDIO) - 12 -...
  • Page 13 WIRING - 3 (SCART) - 13 -...
  • Page 14 SCHEMATIC DIAGRAM - 3 (SCART) - 14 -...
  • Page 15 WIRING - 4 (TEXT) - 15 -...
  • Page 16 SCHEMATIC DIAGRAM - 4 (TEXT) - 16 -...
  • Page 17 WIRING - 5 (NICAM) - 17 -...
  • Page 18 SCHEMATIC DIAGRAM - 5 (NICAM) - 18 -...
  • Page 19 WIRING - 6 (NK) - 19 -...
  • Page 20 SCHEMATIC DIAGRAM - 6 (NK) - 20 -...

  • Page 21: Ic Block Diagram

    IC BLOCK DIAGRAM - 21 -...
  • Page 22 - 22 -...
  • Page 23 - 23 -...
  • Page 24 WAVEFORM IC301 PIN2: A-DE-EN IC301 PIN16: B-IN 100 µs/div 20 µs/div 2 V/div 500 mV/div IC301 PIN11: XTAL IC301 PIN18: R-OUT 20 µs/div 200 ns/div 100 mV/div 1 V/div IC301 PIN19: G-OUT IC301 PIN14: R-IN 20 µs/div 20 µs/div 1 V/div 500 mV/div IC301 PIN20: B-OUT IC301 PIN15: G-IN...
  • Page 25 IC301 PIN22: V-RAMP IC301 PIN27: SDA 100 µs/div 40 µs/div 1 V/div 1 V/div IC301 PIN29: S-ID/CW-OUT IC301 PIN23: V-NFB 100 µs/div 200 ns/div 1 V/div 500 mV/div IC301 PIN24: V-OUT IC301 PIN30: FBP-IN 10 µs/div 4.0 ms/div 500 mV/div 2 V/div IC301 PIN26: SCL IC301 PIN31 : SYNC-OUT...
  • Page 26 IC301 PIN32: H-OUT IC301 PIN45: C-IN 10 µs/div 20 µs/div 1 V/div 200 mV/div IC201 PIN30: V-OUT (SCART C.B) IC301 PIN34: SCP-OUT 10 µs/div 20 µs/div 2 V/div 1 V/div IC301 PIN35: E/W-OUT IC201 PIN4: V1 (SCART C.B) 20 µs/div 4 ms/div 1 V/div 200 mV/div...
  • Page 27 IC DESCRIPTION IC, TMP87CP38N-LA71 Pin Name Description Pin No. GND. POWER Power control output (H = ON). Serial latch clock. SCLK Serial clock. Serial data. Q SUR Q Surround switching (H = ON). N RESET NICAM reset (H= ON/L = Reset). Bass boost / s-woofer (L= Boost).
  • Page 28 IC, MSP3417D Pin Name Description Pin No. Test pin. Not connected. D-CRT-Out1 Digital control output 1. D-CRT-Out0 Digital control output 0. ADR-SEL C Bus address select. STANDBY Standby (L = Standby). C-CL C clock. C-DA C data. Test pin. DVSUP Digital power supply 5V.
  • Page 29 IC, TA1275AZ Pin No. Pin Name Description Y OUT The output pin for Y signal. The pin for controlling the Y processing mode: DL-MODE to VCC: 5.5MHz trap ; open: 5.5MHz trap + D.L ; to GND: DL. (Not used) R-Y OUT The output pin for demodulated R-Y signal.

  • Page 30: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW 1 / 1 P.C.B P.C.B P.C.B P.C.B P.C.B - 30 -...

  • Page 31: Mechanical Parts List

    MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 87-054-086-010 BADGE,AIWA 52.5 2 8Z-JB4-003-010 PANEL,MAIN SE211 3 8Z-JBR-006-010 LENS,LED 4 8Z-JBR-005-010 LENS,RC 5 8Z-JB4-004-010 KEY,MAIN K 6 8Z-JB4-013-010 CABI,FR EU...
  • Page 32 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9820572 0251431 Printed in Singapore...
