TV-S2011
U
SERVICE MANUAL
COLOR TELEVISION
• This Service Manual contains information about the difference between
TV-S2011 (U5AL) and TV-S2011 (U). If requiring other information, see
Service Manual of TV-S2011 (U), (S/M Code No. 09-99C-416-8R2).
S/M Code No. 09-011-416-8S3

Advertisement

   Also See for Aiwa TV-S2011

Aiwa TV-S2011 Operating Instructions Manual
Aiwa TV-S2011 Operating Instructions Manual 24 pages
aiwa TV-S2011 Service Manual
aiwa TV-S2011 Service Manual 7 pages

   Related Manuals for Aiwa TV-S2011

   Summary of Contents for Aiwa TV-S2011

  • Page 1: Service Manual

    TV-S2011 SERVICE MANUAL COLOR TELEVISION • This Service Manual contains information about the difference between TV-S2011 (U5AL) and TV-S2011 (U). If requiring other information, see Service Manual of TV-S2011 (U), (S/M Code No. 09-99C-416-8R2). S/M Code No. 09-011-416-8S3...

  • Page 2: Specifications

    SPECIFICATIONS Tuner System Frequency synthesized tuner TV System NTSC-M Channel Coverage VHF: 2 to 13 UHF: 14 to 69 CATV: 5A, A-1 to A-5, A to W, W+1 to W+84 Program Memory Antenna Input 75 ohms, unbalanced Picture Tube 20" Screen Size 406 (W) X 305 (H) mm (16 x 12...

  • Page 3: Notices Before Repairing

    NOTICES BEFORE REPAIRING To make the best use of this equipment, make sure to obey the following items when repairing (or mending). 1. Do not damage or melt the tunicate of the leading Insulation resistance: 1.5 to 3.0 MΩ (500 V/s) wire on the AC1 side, including the power supply Voltage-withstand: 1 KV for 1 minute cord.

  • Page 4

    ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C211 87-018-115-080 CAP, CER 47P-50V C214 87-A12-086-080 CAP,E 0.47-50 SMG 8Z-JBH-622-010 IC,M37272M8-183SP C215 87-A12-086-080 CAP,E 0.47-50 SMG 87-A91-538-010 RCR UNIT,SBX1981-72P C301 87-A12-091-080 CAP,E 10-50 SMG 87-A21-133-080 IC,BMR-0101D C302...

  • Page 5

    REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C620 88-130-102-080 RES,1K-1/4W J L604 8Z-JBE-608-010 COIL,CHOKEELC08D560E C703 87-015-464-080 CAP,E 4.7-16 BP L701 87-005-614-080 COIL 100UH LAV35 J C704 87-A10-292-080 CAP,M 5600P-50 J L801 8Z-JBH-613-010 FLTR,LINE ELF18N016A C705 87-A10-296-080 CAP,M 0.012-50 J R107...

  • Page 6

    WIRING – 1 (MAIN) – 6 –...

  • Page 7

    SCHEMATIC DIAGRAM – 1 (MAIN / NK) – 7 –...

  • Page 8

    WIRING – 2 (NK) – 8 –...

  • Page 9

    MECHANICAL EXPLODED VIEW 1 / 1 HT-SINK LENS – 9 –...

  • Page 10: Color Name Table

    MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 87-054-086-010 BADGE,AIWA 52.5 16 8Z-JBE-010-010 PANEL,REAR U MPI 2 8Z-JBE-003-010 PANEL,FR S2011 UL 17 8Z-JBW-602-110 CONN ASSY,4P V WHT SP20 3 86-LBB-007-010 LENS,LED 18 84-LB3-216-010...

  • Page 11

    2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9820543 0251431 Printed in Singapore...
