38" Corner Desk Riser
Instruction Manual
SKU: DESK-V000KL/LA/LN/LW
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-v000kl
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo DESK-V000KL
Summary of Contents for Vivo DESK-V000KL
- Page 1 38” Corner Desk Riser Instruction Manual SKU: DESK-V000KL/LA/LN/LW Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-v000kl GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. - Page 3 STEP 2 Install Stopper (F) to underside of Keyboard Tray (B) using ST4.2x12mm Screws (S-B) and a Phillips screwdriver. STEP 3 Press Foot Pads (E) into holes in base of Desk (A).
- Page 4 STEP 4 Cut the large plastic ties on bottom of Desk (A). CAUTION: Do not squeeze the release handle with the desk in a sideways or upside-down position. STEP 5 Place Desk (A) right-side up on a table. Raise the desk by squeezing the handle underneath the desktop.
- Page 5 STEP 6 Place Keyboard Tray (B) on metal brackets on Desk (A). Secure keyboard tray to brackets using M5x10mm Screws (S-A) and a Phillips screwdriver. STEP 7 Apply Cable Clips (C) to underside of desk assembly.
- Page 6 Assembly Complete Desk riser is now ready for use Press the side levers to raise or lower your desk riser. When lowering without any weight on the desktop, lightly press down on riser as you lower it to allow for a smoother lowering process. If it feels difficult to lower after placing laptop and other intended setup items, apply light pressure to lower smoothly or add additional weight.
- Page 7 Tension Adjustment If your desk riser lifts up or down too easily, or is too difficult, the gas spring cable can be adjusted to your desired tension. The adjustment is located at the base of your riser. Start by loosening the Upper (1) and Lower (2) Nuts using an adjustable wrench. Loosen Nuts until they are both on the opposite ends of the Gas Spring Cable.
- Page 8 Tension Adjustment - cont’d Option A: Desk Is Difficult to Raise/Lower | Increase Tension If the desk feels difficult to raise and lower, you will need to increase the Gas Spring Cable tension. Gently pull the cable away from the Lever until the Inner Nut (2) is firmly pressed against the middle divider.
- Page 9 Tension Adjustment - cont’d Option B: Desk Raises/Lowers Too Easily | Decrease Tension If the desk is raising or lowering without the handle being pressed, the tension will need loosened. Gently push the cable down towards the base of the riser until the Upper Nut (1) is firmly pressed against the middle divider.
- Page 10 CAUTION! Leave enough slack Raise desktop slowly Keep monitor and Follow the cable to keep items stable. routing instructions to laptop base fully on in cable to allow for the desktop. full range of vertical avoid the potential to pinch cables. motion (15”...
- Page 11 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
- Page 12 : 1HR 8M help@vivo-us.com (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
