PHYWE 07029-12 Instruction Manual

PHYWE Systeme GmbH & Co. KG
Robert-Bosch-Breite 10
37079 Göttingen
Germany
Tel. +49 (0) 551 604-0
Fax +49 (0) 551 604-107
E-mail info@phywe.de
Operating Instructions
The unit complies
with the applicable
EC regulations

TABLE OF CONTENTS

1 SAFETY INSTRUCTIONS
2 PURPOSE AND CHARACTERISTICS
3 GENERAL CHARACTERISTICS
4 TECHNICAL DESCRIPTION
5 OPERATING INSTRUCTIONS
6 TROUBLESHOOTING
7 SCOPE OF DELIVERY
8 WARRANTY
9 PRODUCER
10 WASTE DISPOSAL
www.phywe.com, © All rights reserved
Digitalmultimeter, 750V AC/DC, 20A AC/DC, 2000MΩ,
200µF, 10MHz, 20H, -20...1000°C
Fig. 1: Digitalmultimeter, 750V AC/DC, 20A AC/DC, 2000MΩ, 200µF, 10MHz, 20H, -20...1000°C, 07029-12
1 SAFETY INSTRUCTIONS

Do not store or use it in environments of high temperature,
high humidity, high flammability or strong magnetic fields.

Use only safety connecting cords.

Wipe the meter with a damp cloth and soft detergent, and
avoid abrasive and drastic cleaning agents such as alco-
hol.

Take out the battery to prevent the meter from being cor-
roded by a leaking battery if the meter is not going to be
used for a long time.

Be careful of the status of batteries. When "
played on LCD, replace batteries.

This series of device is designed according to the
EN61010-1 standard (safety standard issued by Interna-
tional Electro technical Committee). Read these safety no-
tices before using it.

Do not input current higher than 20A when measuring cur-
rent.

Never input DC higher than 1000V or AC higher than
750V virtual voltage as measuring voltage.

Verify the correct earthing, connection and insulation of
test leads to avoid electric shock when measuring the
voltage of DC higher than 36V or AC higher than 25V.

Test leads should be away from test points when switch-
ing the functions or measurement ranges.

Select the correct functions and measurement ranges and
beware of improper operation. You may still be careful to
ensure safety even even though the device has range pro-
tection functions.
07029-12
" is dis-
1
