U-Line H-3699 Manual

π
H-3699
PRODUCE BAG STAND
NARROW PROFILE
TOOL NEEDED
Wrench (included)
1. Attach bottom pole to base by inserting it through
the hole in the base from the bottom (side with feet).
(See Figure 1)
Figure 1
2. Insert black carriage bolt from top to bottom.
(See Figure 2)
3. Put the nut on the bottom side. Put all 4 bolts and
nuts on loosely. (See Figure 3)
Figure 3
PAGE 1 OF 2
1-800-295-5510
uline.com
ASSEMBLY
Figure 2
4. Tighten nuts with wrench provided. (See Figure 4)
Figure 4
5. Slide top pole over bottom pole. Line up one hole
with snap button. Push snap button and slide pole
over it until button pops through pole. (See Figure 5)
Figure 5
0415 IH-3699
