H-9608
MANUAL PAPER
TOWEL DISPENSER
TOOLS NEEDED
Electric Drill
1/4" Drill Bit
Dispenser x 1
NOTE: Snap-in key sold separately. Contact
Uline Customer Service at 1-800-295-5510 to
purchase.
1. Align snap-in key with lock on top of dispenser
and push in until it snaps into place.
(See Figure 1).
Figure 1
PAGE 1 OF 3
1-800-295-5510
uline.com
Phillips Screwdriver
Tape Measure
Metal Key x 1
Plastic Snap-In Key x 1
(Not Included)
OPTIONAL SNAP-IN KEY
Level
PARTS
2. Rotate snap-in key clockwise to open dispenser.
(See Figure 2)
Figure 2
NOTE: Snap-in key cannot be removed once
inserted.
Wall Anchor x 5
Screw x 5
1021 IH-9608
