Inverter Generator | 2300 Running / Max 2800 Watts | 120V - 20A
BNG2300iSAC INVERTER GENERATOR | SERIAL NUMBER
S/N #
S/N
This manual contains important details regarding safety and operation of this Inverter Generator.
Before using this product, read all warnings, instructions, and labels.
Serious personal injury and/or property damage may occur if cautions and recommendations are not
followed.
BN Products-USA™
3450 N Sabin Brown Road
Wickenburg, AZ 85390
BNG2300iSAC
SAVE THIS MANUAL - KEEP IN A SAFE PLACE
OPERATOR MANUAL
BN Products-USA™ Customer Service
(800) 992-3833 | mail@bnproducts.com
MODEL
BNPRODUCTS.COM
INFO
(800) 992-3833
BNProducts.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BNG2300iSAC and is the answer not in the manual?

Questions and answers

Summary of Contents for BN Products BNG2300iSAC

  • Page 1 OPERATOR MANUAL BN Products-USA™ Customer Service (800) 992-3833 | mail@bnproducts.com Inverter Generator | 2300 Running / Max 2800 Watts | 120V - 20A BNG2300iSAC BNG2300iSAC INVERTER GENERATOR | SERIAL NUMBER MODEL INFO S/N # BNPRODUCTS.COM SAVE THIS MANUAL - KEEP IN A SAFE PLACE This manual contains important details regarding safety and operation of this Inverter Generator.
  • Page 2: Table Of Contents

    Accessory Descriptions Connecting Devices Notices Generator Grounding CARBON MONOXIDE SAFETY Parallel Operation CO Labels on BNG2300iSAC Inverter SERVICE & MAINTENANCE GENERAL SAFETY WARNINGS Spark Plug Inspection & Replacement OPERATOR PARTS & SERIAL NUMBER Air Cleaner Inspection & Replacement CONTROL PANEL FUNCTIONS...
  • Page 3: Generator Package Contents

    SAE 10W-30 motor oil before starting this generator. The engine oil dipstick provides the exact measurement for reference. The actual appearance of tools or accessories may vary from the images displayed. BN Products-USA™ reserves the right to modify included accessories and package contents, with or without prior notification.
  • Page 4: Carbon Monoxide Safety

    Carbon Monoxide Safety This Inverter Generator set is equipped with Carbon Monoxide Shutdown Detect technology that monitors the accumulation of carbon monoxide, a poisonous gas product by engine exhaust. If the on-board CO sensor detects unsafe or elevated CO gas, the inverter generator’s engine will shut down automatically.
  • Page 5 - Temporary Structure or Tent - Porch, Shed, or Crawl Space Carbon Monoxide (CO) Labels on the BNG2300iSAC Inverter Generator It is extremely important to know and understand the procedure to follow should this generator shut down automatically due to detection of unacceptable levels of carbon monoxide.
  • Page 6: General Safety Warnings

    General Safety Warnings • Familiarize yourself with the operation of the various components, and learn how to effectively shut down the generator quickly. • Know the environment where you intend to use the Inverter Generator; • DO NOT USE the generator: - Indoors - In rainy or wet conditions - Near buildings or close to people...
  • Page 7: Operator Parts & Serial Number

    Operator Parts - BNG2300iSAC Inverter Generator 1 - Fuel Tank Cap 2 - Starter Pull Handle 3 - Side Cover Bolt (2) (Left and Right) 4 - Left Side Cover 5 - Control Panel: See Control Panel Function (next page)
  • Page 8: Control Panel Functions

    Control Panel Functions 1 - Low Idle Switch: When ON, engine will run at 7 - Reset: If overload condition exists, engine will fuel-optimized level for load run with no power output. Unplug devices, then select reset breaker. 2 - Low Oil Alarm: Indicates low oil level 8 - USB Duplex: 5V DC 1 A / 2.1 A 3 - Overload Alarm: Indicates overload condition 9 - Ground Terminal: The ground terminal is used...
  • Page 9: Preparing For Use

    Preparing for Use ADD ENGINE OIL BEFORE FIRST USE THIS GENERATOR IS NOT SHIPPED WITH ENGINE OIL. Do NOT attempt to start the generator without adding engine oil to the generator. • Use SAE 10W-30 motor oil for this generator; API standard Type SE or higher. 1.
  • Page 10: Adding Fuel To The Generator

    • While checking the oil level, inspect for any oil leaks in the bottom of the casing or under the generator During Operation • Observe the running condition of the generator; abnormal conditions or running speed may indicate a maintenance issue; contact BN Products-USA™ Customer Service at (800) 992-3833 when you have questions or need assistance.
  • Page 11: Using The Generator

    Using the Inverter Generator STARTING • Remove all devices (load) from outlet plugs • No electrical devices should be connected to the generator • Switch the Low Idle Switch to “OFF” • Turn the Multi-Switch to the “CHOKE” position • Gently pull the starter cord handle until the cord stops without additional effort.
  • Page 12: Operating Environment

    4.5%. Questions? If you have questions or concerns related to the operating environment for your inverter generator, the Customer Service team at BN Products-USA™ may be able to help; contact our representatives at (800) 992-3833. USING EXTENSION CORDS ATTENTION Extension cords are commonly used with portable generators to ensure safe working distances from a running generator.
  • Page 13: Connecting Devices

    CONNECTING DEVICES TO YOUR INVERTER GENERATOR ATTENTION • Make sure that all electrical equipment, including wires and plugs, are in good condition before connecting to the generator • All loads powered by the generator must be within rated load (watts, amperage) range of the generator, and connected electrical equipment START the generator engine following the instructions contained in this Operator Manual Turn the Low-Idle control switch to the “ON”...
  • Page 14: Parallel Operation

    (See illustration in Figure G to indicate parallel kit connections) Th BNG2300ISAC Inverter Generator supports 120V AC parallel output only when a parallel kit is attached to two BNG2300iSAC generators. This generator set does not include a 240V connector.
  • Page 15: Service & Maintenance

    Service and Maintenance Spark Plug Inspection & Replacement The generator’s spark plug should be inspected regularly to ensure consistent starting performance. • Make sure the generator is not running and cool; remove the Spark Plug Service cover on the top of the generator, then remove the spark plug cap covering the spark plug.
  • Page 16: Carburetor Adjustment

    AIR CLEANER MAINTENANCE & REPLACEMENT Clean the air filter after the first 25 hours of use. Following that point, clean or replace the air filter every 6 months or after each 50 hours of use. Clean or replace the filter more often when used in dusty conditions - always replace the air filter foam element every two years or 100 hours of use.
  • Page 17: Change Engine Oil

    CHANGE ENGINE OIL WARNING Use extreme caution when draining the oil after turning off the generator. During operation, the oil is very hot after the generator has been running. Direct exposure to hot engine oil may cause serious burns. • Place the generator on a stable and flat surface outdoors. It is recommended that the generator is started and run for several minutes to warm the oil temperature (never run the generator indoors or where exhaust can build up).
  • Page 18: Sediment Cup - Fuel Filter Screen

    Sediment Cup (Fuel Tank Filter Screen) - Maintenance WARNING Be aware of the environment around your generator before opening the fuel tank cap. Never open the fuel tank cap near a heat source, or where sparks or flames could be present, including smoking.
  • Page 19: Spark Arrestor

    Spark Arrestor - Inspection and Cleaning This inverter generator is equipped with a muffler attachment known as a spark arrestor. This is a device that traps or destroys hot exhaust particles to prevent fires. It’s crucial for safety, especially in areas with dry vegetation or where regulations require their use.
  • Page 20: Maintenance Schedule

    MAINTENANCE SCHEDULE Refer to the Maintenance Schedule table in Figure S. Use this table as a general guide to inspect and maintain the working condition of this generator; perform additional inspection and service as needed, or if you suspect servicing is necessary between scheduled maintenance intervals. FIGURE S Transportation and Storage TRANSPORTATION...
  • Page 21: Generator Storage

    GENERATOR STORAGE Proper storage is essential for readiness, for the next time that you plan to use the generator. Follow each storage recommendation to avoid starting problems, breakdown of old gasoline, and rust or corrosion of generator or engine parts. This section of the operator manual will cover: •...
  • Page 22 Long-Term Storage - Fuel Drainage The following are recommended procedures for long term storage (> 90 days) of the generator. • With the generator not running, make sure that the Multi-Switch is moved to the “OFF” position. • Open the fuel tank cap, remove the fuel sediment cup screen. Use a pump to empty remaining fuel into a storage tank for storage or proper disposal.
  • Page 23 Long-Term Storage - Engine/Oil Maintenance • With the right side cover removed from the generator: • Locate the engine oil dipstick. Unscrew the dipstick, and drain the engine oil. • Add new engine oil as explained in the ‘Change Engine Oil” procedure in this manual. •...
  • Page 24: Troubleshooting

    Troubleshooting...
  • Page 26: Technical Specifications

    Technical Specifications BNG2300iSAC Inverter Generator...
  • Page 27: Limited Warranty

    The Company responsibility under this warranty is limited to the replacement or repair, at a designated facility, of only the part or parts evaluated by BN Products-USA™ upon inspection to be defective in materials and quality. Any related part/parts determined by BN Products-USA™ to be defective will be either repaired or replaced free of charge.
  • Page 28: Model Description

    The BNG2300iSAC is a 2800 Watt (Max) / 2300 Watt (Rated), gasoline-powered inverter generator that is a great addition to our line of BN Products USA™ generators. The compact design and enclosed case make this unit a convenient and lightweight power plant, that quietly produces stable power for your job site or recreational needs.
