FoMaKo
NDI/SDI/HDMI/USB/IP
4K PTZ CAMERA
User Manual
（V1.0）
FoMaKo
E-mail: support@fomako.net
Website: www.fomako.net Phone:
0086-18565635753
Address: 10F NiuLanQian Building,Minzhi,
longhua, shenzhen, China, 518000
Please feel free to contact us if you have any questions.
.
Please Note: Only NDi version cameras have NDi function, other version cameras don't have NDi function

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 12X and is the answer not in the manual?

Questions and answers

Related Manuals for FoMaKo 12X

Summary of Contents for FoMaKo 12X

  • Page 1 4K PTZ CAMERA User Manual （V1.0） FoMaKo E-mail: support@fomako.net Website: www.fomako.net Phone: 0086-18565635753 Address: 10F NiuLanQian Building,Minzhi, longhua, shenzhen, China, 518000 Please feel free to contact us if you have any questions. Please Note: Only NDi version cameras have NDi function, other version cameras don’t have NDi function...
  • Page 2 Focus Your Streaming www.fomako.net FoMaKo IP Streaming Camera Quick Start Dear Friend, Thanks for ordering FoMaKo cameras. To setup your streaming system easier, please read this quick start instruction first. Video Out Methods: (1) HDMI video output: - HDMI port to HDMI TV/monitor, to preview video and change camera setting by press “menu” on...
  • Page 3 We recommend to use Visca over IP control protocol, it is steady and work better. Let’s use FoMaKo KC608 Pro IP controller for example: FoMaKo KC608 Pro controllers are optimized for FoMaKo cameras, it is very easy to let them work together.

  • Page 4: Magnetic Interference

    FoMaKo - Focus Your Streaming www.fomako.net Attention This manual introduces functions, installations and operations for this product in details. Please read this manual carefully before installation and use. Precautions: This product can only be used in the specified conditions in order to avoid any damage to the camera: Do not expose the product to rain or moisture.

  • Page 5: Table Of Contents

    FoMaKo - Focus Your Streaming www.fomako.net Content 1. Quick Start .........................6 1.1. Product Overview ....................6 1.2. Power-on Self-test ....................6 1.2.1. Power on ...................... 6 1.2.2. Self-test ......................6 1.3. Video Outputs ....................... 6 1.3.1. IP Network Output ..................7 1.3.2. HDMI Output ....................7 1.3.3.
  • Page 6 FoMaKo - Focus Your Streaming www.fomako.net 4.2.5. Audio Configuration ..................27 4.2.6. Video configuration ..................27 4.2.7. Network configuration ................. 30 4.2.8. System Configuration .................. 32 4.2.9. Logout ....................... 33 5. Serial Communication Control ................... 33 5.1. VISCA protocol list ..................... 34 5.1.1.

  • Page 7: Quick Start

    FoMaKo - Focus Your Streaming www.fomako.net 1. Quick Start 1.1. Product Overview Product Overview: 1.Lens 6.1/4-20UNC Threaded Mounting Hole 11.Internet Interface 12.HDMI Output Interface 2.LED Display 7.DC12V Power Input Socket 3.Infrared Receiver 8.RS232 IN Interface 13.USB3.0 Output Interface 14.3G-SDI 4.POWER LED 9.RS232 OUT Interface...

  • Page 8: Ip Network Output

    FoMaKo - Focus Your Streaming www.fomako.net 1.3.1. IP Network Output a. Network connection: Shown as diagram 1.1 #11 b. Log in: You can reach the Web Interface by typing in the camera’s IP address(default 192.168.5.163) into a web browser. To log in, type in “admin” into the username and password fields. From the Web Interface, you can adjust many of your camera’s settings via this IP interface.
  • Page 9 FoMaKo - Focus Your Streaming www.fomako.net...
  • Page 10 FoMaKo - Focus Your Streaming www.fomako.net 2) Steps of ceiling mount...

  • Page 11: Product Overview

    FoMaKo - Focus Your Streaming www.fomako.net 2. Product Overview 2.1. Product Introduction 2.1.1. Dimension Figure2-1 Dimension 2.1.2. Accessory When you unpack your package, check that all the supplied accessories are included: Table 2-1 Power adapter User manual Supplied IR remote control USB 3.0 Video Cable...

  • Page 12: Product Features

     Ultra High-definition Image: Equipped with a 1/2.8-inch 8.42-megapixel high-quality image sensor, the maximum resolution can reach 3840*2160, with an output frame rate of up to 60 frames per second. Optical Zoom Lens: It has 12X/20X optical zoom lens for options. ...
  • Page 13 FoMaKo - Focus Your Streaming www.fomako.net Parameters Image Sensor 1/2.8 inch high quality HD CMOS sensor Effective Pixel 8.42M, 16: 9 HDMI: 3840*2160/1920*1080P60/59.94/50/30/29.97/25; 1280*720P60/59.94/50 SDI: 1920*1080P60/59.94/50/30/29.97/25; 1920*1080I60/50/59.94; 1280*720P60/59.94/ 50 USB: YUY2/NV12: 1920*1080/1280*720/1024*576/800*600/800*448/640*480/ 640*360/480*270/320*180P30/25/20/15/10/5fps H264/H265/MJPG: 3840*2160/1920*1080/1600*896/1280*720/1024*576/960*540/ Video Format 800*600/800*448/720*576/720*480/640*480/640*360/480*270/ 352*288/320*240@60/30/25/20/15/10/5fps LAN:...
  • Page 14 FoMaKo - Focus Your Streaming www.fomako.net Brightness, Contrast, Sharpness, Horizontal Flip, Vertical Flip, Black and White Video Adjustment Mode, Gamma Curve, Electronic Zoom, DCI, Ultra Low Light Mode >50dB Interface HDMI, SDI, LAN(POE+ support), USB3.0, A-IN, RS232-IN, Interface RS232-OUT, RS485, DC12V power supply Video output HDMI, SDI, LAN, USB3.0...

  • Page 15: Ndi Mode Introduce

    FoMaKo - Focus Your Streaming www.fomako.net -170° ～ +170° Tilt -30° ～ +90° Pan Speed 0.1° ～ 60°/s Tilt Speed 0.1° ～ 30°/s Preset Speed Pan:60°/s, Tilt:30°/s Preset Quantity User can set 255 presets (10 via IR remote control) Monocular Tracking...

  • Page 16: Interface Description

    FoMaKo - Focus Your Streaming www.fomako.net 2.5. Interface Description 2.5.1. External Interfaces This product's external interfaces include: HDMI interface, USB 3.0 interface, SDI interface, audio input interface, network interface, RS232 input/output, RS485 interface, and DC12V power input. The diagram of the external interfaces is shown in Figure 2-2.
  • Page 17 FoMaKo - Focus Your Streaming www.fomako.net Figure 2-3 2）RS-232 Mini-DIN 8-pin Definition Port Definition Data Terminal Ready Data Set Ready Transmit Data System Ground Receive Data System Ground IR OUT IR Commander Signal No Connection 3)RS232 (DB9) Port Definition Port...

  • Page 18: Remote Control

    FoMaKo - Focus Your Streaming www.fomako.net 4）VISCA networking shown as below: Camera cascade connection method Device 1 Device 2 1.DTR 1.DTR 2.DSR 2.DSR 3.TXD 3.TXD 4.GND 4.GND 5.RXD 5.RXD 6.GND 6.GND 7.IR OUT 7.OPEN 8. NC 8.OPEN 3. Remote Control 3.1.

  • Page 19: Zoom Control

    FoMaKo - Focus Your Streaming www.fomako.net 2. Camera Selection Select the camera address to control. 3. Focus Control Auto: auto focus mode Manual: manual focus mode Focus + (near):Press【FOCUS +】 key (Valid only in manual focus mode) Focus - (far): Press【FOCUS -】key (Valid only in manual focus...

  • Page 20: Pan/Tilt Control

    FoMaKo - Focus Your Streaming www.fomako.net F1: Turn off auto tracking F2: Turn on auto tracking F3: Switch auto tracking modes F4: Switch auto tracking to follow a different person 7. Pan/Tilt Control Up: press Down: press Left: press Right: press Back to middle position: press“【HOME】”...

  • Page 21: Key Combination

    FoMaKo - Focus Your Streaming www.fomako.net P/T Speed + :Remote Control Pan/Tilt Speed + P/T Speed - :Remote Control Pan/Tilt Speed - Zoom Speed + :Remote Control Zoom Speed + Zoom Speed - :Remote Control Zoom Speed - Preset Speed + :Remote Control Preset Speed +...
  • Page 22 FoMaKo - Focus Your Streaming www.fomako.net 【↑】 【↓】 ：Choose item 【←】 【→】 ：Modify values 2) English Menu...
  • Page 23 FoMaKo - Focus Your Streaming www.fomako.net...

  • Page 24: Network Connection

    FoMaKo - Focus Your Streaming www.fomako.net 4. Network Connection 4.1. Connection Method (Please check Quick Start) Direct Connection: Directly connect the device to the computer using a network cable. Connection to LAN: Connect the device to the Internet network, which can be done via a router or switch. The user can log in to the device through a browser.

  • Page 25: Camera Web Interface

    FoMaKo - Focus Your Streaming www.fomako.net Figure 4-2: Network Connection Normal Illustration 4.2. Camera Web Interface 4.2.1. Web Login (Please check Quick Start) 1）Client Login Enter the device IP address (default is 192.168.5.163) in the browser's address bar and press Enter to access the Web client login page.

  • Page 26: Monocular Tracking

    FoMaKo - Focus Your Streaming www.fomako.net General users can perform operations such as pan-tilt control, zooming, focusing, sound control, magnification, full screen, and setting, running, or deleting preset positions. General users can preview and log out, but cannot access configuration settings.

  • Page 27: Configuration

    FoMaKo - Focus Your Streaming www.fomako.net Tracking Intelligent × × ◎ ◎ ◎ Framing Notes: 1.◎: Configurable in this tracking mode. 2.×: Not configurable in this tracking mode. ①: Click to set the left boundary of the tracking area, then click [Set] to complete.

  • Page 28: Audio Configuration

    FoMaKo - Focus Your Streaming www.fomako.net There are the following options: Audio configuration, video configuration, network configuration, internet access configuration, system configuration, detailed description see the following table. Menu Explanation Audio Including audio compressing format, sampling frequency, sampling precision, configure compressing code rate settings etc.
  • Page 29 FoMaKo - Focus Your Streaming www.fomako.net Frame Rate (F / S): Set the video frame rate (primary / secondary stream default 25F / S, primary stream 5-60F/S optional, secondary stream 5-30F / S optional ). Key Frame Interval: Set the key frame interval (primary / secondary stream default 100F; Primary stream 1-300 optional.
  • Page 30 FoMaKo - Focus Your Streaming www.fomako.net (default 8, 0-15 optional) Gain: Set the gain. This setting is only effective when the exposure mode is set to manual. (Default 0, Range: 0-20 optional). Dynamic range: set the dynamic range (default off, 1-8 optional).

  • Page 31: Network Configuration

    FoMaKo - Focus Your Streaming www.fomako.net Low-Light Mode: Set Low-light mode (default off/on optional) e. Noise Reduction: 2D noise reduction, 3D noise reduction and dynamic dead pixel correction available. 2D Noise Reduction: Set 2D noise reduction level (default 3,1-7and auto optional).
  • Page 32 FoMaKo - Focus Your Streaming www.fomako.net RTMP Port: Set RTMP port (default 1935, 0-65535 optional). RTSP Port: Set RTSP port, the device will restart automatically after changed (default 554, 0-65535 optional). Visca Port: Set Visca port, the device will restart automatically after changed (default 1259，0-65535 optional).

  • Page 33: System Configuration

    FoMaKo - Focus Your Streaming www.fomako.net SRT password: Set SRT password SRT password length: Set the SRT password length (default 0, 16, 24, 32 optional) Click the "Save" button, and the prompt message "Parameters saved successfully! It will take effect after restarting!" will be displayed.

  • Page 34: Logout

    FoMaKo - Focus Your Streaming www.fomako.net  Note: Please note that usernames and passwords are case-sensitive.  Important Notes: If logged in as a regular user, you will not have configuration permissions and will only be able to preview or log out..

  • Page 35: Visca Protocol List

    FoMaKo - Focus Your Streaming www.fomako.net 5.1. VISCA protocol list 5.1.1. Tracking VISCA Serial Commands Main Function Function Command Command Description 0p: 0: Off 1: Real-time Tracking 8x 0A 01 32 00 00 Direct 2: Stage Tracking 02 0p FF...

  • Page 36: Camera Control Command

    FoMaKo - Focus Your Streaming www.fomako.net Error Messages Command packet Note Returned when the command format is different Syntax Error z0 60 02 FF or when a command with illegal command parameters is accepted. Indicates that two sockets are already being...
  • Page 37 FoMaKo - Focus Your Streaming www.fomako.net Command Function Command packet Note One Push 8x 01 04 38 04 FF 8x 01 04 47 0p 0q 0r 0s pqrs: Zoom Position CAM _Zoom Focus Direct 0t 0u 0v 0w FF tuvw: Focus Position...
  • Page 38 FoMaKo - Focus Your Streaming www.fomako.net Command Function Command packet Note 4200K 8x 01 04 35 1B FF 4300K 8x 01 04 35 1C FF 4400K 8x 01 04 35 1D FF 4500K 8x 01 04 35 08 FF 4600K...
  • Page 39 FoMaKo - Focus Your Streaming www.fomako.net Command Function Command packet Note 8x 01 04 03 02 FF Down 8x 01 04 03 03 FF Direct 8x 01 04 43 00 00 0p 0q FF pq: R Gain Reset 8x 01 04 04 00 FF...
  • Page 40 FoMaKo - Focus Your Streaming www.fomako.net Command Function Command packet Note Direct 8x 01 04 4E 00 00 0p 0q FF pq: ExpComp Position 8x 01 04 33 02 FF Back Light CAM_Back Light Compensation 8x 01 04 33 03 FF...
  • Page 41 FoMaKo - Focus Your Streaming www.fomako.net Command Function Command packet Note D:190% E:200% CAM_IDWrite 8x 01 04 22 0p 0q 0r 0s FF pqrs: Camera ID (=0000 to FFFF) 8x 01 06 08 02 FF IR_Receive IR(remote commander)receive On/Off 8x 01 06 08 03 FF...

  • Page 42: Inquiry Command

    FoMaKo - Focus Your Streaming www.fomako.net Command Function Command packet Note 8x 01 06 02 VV WW Absolute Position 0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z 8x 01 06 03 VV WW Relative Position 0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z...
  • Page 43 FoMaKo - Focus Your Streaming www.fomako.net Command Function Command packet Note y0 50 03 FF One Push mode y0 50 05 FF One Push Trigger y0 50 0C FF 2400K y0 50 0D FF 2500K y0 50 0E FF 2600K...
  • Page 44 FoMaKo - Focus Your Streaming www.fomako.net Command Function Command packet Note y0 50 27 FF 5600K y0 50 28 FF 5700K y0 50 29 FF 5800K y0 50 2A FF 5900K y0 50 0A FF 6000K y0 50 2B FF...
  • Page 45 FoMaKo - Focus Your Streaming www.fomako.net Command Function Command packet Note y0 50 03 FF CAM_WDRStrengthInq 8x 09 04 51 FF y0 50 00 00 00 0p FF p: WDR Strength CAM_NRLevel(2D) Inq 8x 09 04 53 FF y0 50 0p FF...

  • Page 46: Pelco-D Protocol Command List

    FoMaKo - Focus Your Streaming www.fomako.net Command Function Command packet Note 0A:1080P59.94 01:1080P50 06:1080P30 0D:1080P29.97 07:1080P25 04:720P60 0C:720P59.94 05:720P50 ww: Pan Max Speed zz: Tilt Pan-tiltMaxSpeedInq 8x 09 06 11 FF y0 50 ww zz FF Max Speed y0 50 0w 0w 0w 0w...

  • Page 47: Pelco-P Protocol Command List

    FoMaKo - Focus Your Streaming www.fomako.net Query Zoom 0xFF Address 0x00 0x55 0x00 0x00 Position Query Zoom Value High Value Low 0xFF Address 0x00 0x5D Position Response Byte Byte 5.3. Pelco-P Protocol Command List Function Byte1 Byte2 Byte3 Byte4 Byte5...

  • Page 48: Maintenance And Troubleshooting

    FoMaKo - Focus Your Streaming www.fomako.net 6. Maintenance and Troubleshooting 6.1. Camera Maintenance 1）Please disconnect power of camera if it is not in long-term use. Meanwhile, disconnect AC power adapter from AC socket. 2）To avoid scratch, use soft cloth or cotton to wipe off dust on camera case.
  • Page 49 Method Two: Use HDMI to USB video capture card 8）Can't transmit audio Please login the camera's webpage -> Configuration-> Audio configure -> Enable then Reboot the camera. you can also do something audio settings here. 9) Other unknown problems , please email us at: ivan@fomako.net...

  • Page 50: Example: Streaming To Facebook

    FoMaKo - Focus Your Streaming www.fomako.net We will help you to solve all the problems. 7. Example: Streaming to Facebook Step 1: First of all, please make sure the camera’s IP address is assigned by router, and input your PC’s DNS, if you don’t your pc’s DNS, you can also use Google NDS:...
  • Page 51 FoMaKo - Focus Your Streaming www.fomako.net...

  • Page 52: Example:streaming To Youtube

    FoMaKo - Focus Your Streaming www.fomako.net 8. Example:Streaming to Youtube Streaming to Youtube is similar as streaming to Facebook. Port Type: RTMP Host Port: 1935 Host Address = Youtube “Stream URL” Stream Name = Youtube “Stream Key” 9. Example: Streaming to Vmix...

  • Page 53: Copyright Statement

    FoMaKo - Focus Your Streaming www.fomako.net (2) Stream/SRT -> Choose VLC (3) Input camera’s RTSP URL: rtsp://192.168.0.100:554/live/av0 or simple RTSP URL: rtsp://192.168.0.100 Please change the IP address to your camera’s ip address. Then,press “OK”, it will stream to Vmix successfully.
