Page 2: Table Of Contents
Table of Contents T T a a b b l l e e o o f f C C o o n n t t e e n n t t s s Preface ................2 Fundamental Safety Instructions . -
Page 3: Preface
The HMI firmware, graphic display program, and recipe data can be updated using a U ● disc. When using the U disc with Inovance's PLC, the program on the PLC can be updated, which simplifies on‑site download and operations for multiple manufacturing devices. -
Page 4: Warranty Disclaimer
Scan the QR code on the equipment to acquire more. ● Scan the QR code below to install My Inovance app, where you can search for and ● download user guides. Warranty disclaimer Inovance provides warranty service within the warranty period (as specified in your order) for any fault or damage that is not caused by improper operation of the user. -
Page 5: Fundamental Safety Instructions
Use this equipment according to the designated environment requirements. Damage caused by improper use is not covered by warranty. Inovance shall take no responsibility for any personal injury or property damage caused by improper use. Safety levels and definitions : Indicates that failure to comply with the notice will result in death or severe personal injuries. - Page 6 Fundamental Safety Instructions Control system design Interlock circuits and other circuits such as emergency stop, conventional protection, ● forward and reverse rotation must be set outside the product; devices for preventing equipment damage (up, down and reciprocating movement limit) must be set outside the product.
- Page 7 Touch the HMI panel with hands only during use. Do not use tools to touch the HMI ● panel. Inovance assumes no responsibility for panel damage caused by excessive external force. Retired lithium batteries, LCD screens, capacitors and any other matters that may ●...
- Page 8 Fundamental Safety Instructions Battery The battery model must be correct. ● Do not throw the battery into a fire or heat oven. Do not crush or cut the battery. ● Do not expose the battery to extremely high temperatures. ● Do not swallow the battery to prevent the risk of chemical burns.
-
Page 9: Product Information
7: 7000 series Professionals The ordering data of the product is described in the following table. Model Description Product code IT7150P 01450247 IT7000 series 15‑inch touchscreen Technical Data Item Model: IT7150P 15" Display size 1024 x 768 Resolution Brightness (cd/㎡) Display color 24‑bit true color... - Page 10 Product Information Item Model: IT7150P Mounting hole dimensions (mm) 352 x 279 Enclosure color Silver Front housing: aluminum alloy; Rear cover: sheet Enclosure material metal Operating temperature ‑10°C to +55°C Storage temperature ‑20°C to +70°C Operating humidity 10% RH to 90% RH, without condensation Cooling method Natural ventilation Quad‑core Cortex A7 1.2 GHz...
-
Page 11: Mechanical Design
The HMI is designed to operate in a temperature range between ‑10℃ to +55℃ (14℉ to 131℉), exceeding of which may cause damage to the HMI components, malfunction, or function deterioration. For use in special environments, contact Inovance. Do not install the HMI in environments suffering from strong mechanical vibration. - Page 12 Mechanical Design 1. Put the HMI into the pre‑drilled mounting holes in the panel. 2. Snap the eight metal clips (delivered by default) from the back of the panel into the eight mounting holes on both sides of the HMI enclosure (step ① in the figure). 3.
-
Page 13: Electrical Design
Electrical Design Electrical Design Terminal Description Function Function description Name Name description 24 VDC power input, Ethernet +24V GND communication (delivered together Ethernet port (RJ45) used to Power port with a power ① ⑥ port access the PC or terminal used to connect to this PLC with LAN port power port) -
Page 14: Terminal Wiring
Electrical Design Function Function description Name Name description Communication port between HMI and PLC ON: normal Equipped with Power Blinking: unstable ④ DB9 male ⑨ COM2 serial indicator OFF: power is off communication port (RS232 interface) Communication port between HMI and PLC Flashing: Built‑in COM1 and... -
Page 15: Communication Port
‑ RS485‑ ‑ ‑ ‑ ‑ ‑ RS485+ Communication cable for DB9 female connector Inovance provides preformed communication cable options (model: IT5‑H2U‑CAB*, ordering No.: 15041140) for the DB9 female. (8‑pin DIN round connector) (DB9 male) 3 m cable ‑ ‑... - Page 16 Pin No. Signal ‑ RX‑ TX‑ Pin assignment TX‑ RX‑ Applicable Inovance H1U/H2U/H3U RS422 model and port communication port IT7150P Mitsubishi FX1N/2N/3U/3G RS422 communication port HMI user Set COM1 port to "RS422" in the HMI user program. program setting Select the same communication protocol and data formate for the HMI for use of the and PLC.
- Page 17 ‑ ‑ TX‑ Pin assignment RX‑ ‑ IT7150P Applicable Inovance H1U/H2U/H3U RS422 communication port model and port Mitsubishi FX1N/2N/3U/3G RS422 communication port HMI user In the HMI user project, set the COM2 port as "RS232"; program setting Select the same communication protocol and data formate for the HMI for use of the and PLC.
-
Page 18: Usb Interface
CGND Black Short ‑ Housing Grounding cable IT7150P Inovance Easy300/Easy500 Compatible HMI RS232/RS485 communication and port port ‑ HMI user In the HMI user project, set the COM2 port as "RS232"; program setting The HMI and PLC must have the same communication for use of the protocol and data format settings. - Page 19 Electrical Design Connected to multiple HMIs through Ethernet to form a networked communication. Communicate with PLC through Ethernet. Connected to HUB or Ethernet switch through a standard Ethernet cable to access the LAN, or connected to the Ethernet port of the PC directly through a dual interconnect network cable.
-
Page 20: Programming
IT7000 series HMI Software source For the latest version of the programming software InoTouchPAD independently developed by Inovance, contact your HMI supplier or visit http://en.inovance.cn/ to download the software. Recommended PC configurations CPU: Intel or AMD, 2.0 GHz or higher... -
Page 21: Touch Screen Calibration
Touch Screen Calibration Touch Screen Calibration If the touch screen does not respond or respond slowly, use the calibration program to calibrate the touch screen. Entering the calibration program Access the program through the system setup menu: After the HMI is powered on and the screen displays "Long press to enter the Setup screen", gently press the screen with your finger until the screen displays "Release to enter the Setup screen". - Page 22 *PS00017578A00*...
